Stack type actuators series P

Stack type actuators series P
1 / 2Páginas

Excertos do catálogo

stock type actuator The series P of actuators are based on stack type actuators made by the multilayer technology. They come without a mechanical pre-load, but they still can withstand medium pressure forces. They should be used only in static applications. The piezo stack is encased in stainless steel housing with the top and bottom epoxide to eli- minate mechanical play. To protect the ceramic multilayer actuator, they are filled with flexible silicon rubber material. The multilayer stack actua- tor provides sub-millisecond response and sub- nanometer resolution. As an option, these actuators are available with strain gage sensors for motion control. This op- tion will increase the outside diameter by 2mm. The accuracy will be increased to <0.5%. Actuators should be fastened with screw or clamps on the bottom plate of the actuator. During the installation and use, it is important not to subject the actuator tip to non axial forces. Actuators without pre-load are not suitable for dynamic applications. product highlights: (larger motions available) • micro positioning • mirror adjustment • scanning microscopy • valve control • laser tuning info@piezosystem.com • http://www.piezosystem.de

Abrir o catálogo na página 1

technical details Please pay attention to our "note for mounting", which are available as download on our homepage. All rights reserved to change specifications as progress occurs without notice! info@piezosystem.com • http://www.piezosystem.de

Abrir o catálogo na página 2
