pressure data-logger PR2000

pressure data-logger PR2000
1 / 2Páginas

Excertos do catálogo

MADGE TECH WE BUILD DATA LOGGERS PRESSURE RECORDER W/LCD DISPLAY Large, backlit LCD display Front keypad w/lock feature High speed download Real-time operation User-selectable measurement units N.I.S.T. traceable calibration Min./max. & average statistics Programmable start/stop time Convenient status indicators User replaceable batteries Precision Pressure Recording Environmental studies Replace costly strip chart recorders PRESSURE RECORDER applications requiring display pressure readings convenient access to current data and recorder setup. battery levels, external power recording status are shown on Available on-screen data includes: statistics (min, max, average); recording status (start, stop and recording rate); display options (units, text size); and calibration information (date calibrated, date for recalibration). Statistics can be cleared at any time during logging. With 262,143 readings, the PR2000 has one of the largest memory capacities of any similar data recorder on the market. The non-volatile memory will retain recorded data, even if battery power is lost. N.I.S.T. traceable calibration is available for users needing to meet regulatory requirements. Creating permanent records, performing data calculations, and the graphing of data is quick and easy: Simply connect the interface cable to an available USB or serial port and, with a few clicks of the mouse, data is downloaded and ready for review or export to Excel File Edit View Communication Device Graph Window Help Summary ] Composite Graph Giaph | pate ] MadgeTech Data Recorder Software displays pressure and temperature data in an easy The Windows®-based software package allows the user to effortlessly collect, display and analyze data. A variety of powerful tools allow you to examine, export, and print professional looking data with just a click of the mouse. Click MadgeTech Software for more information or to 879 Maple Street • Contoocook, NH 03229

Abrir o catálogo na página 1

Pressure Sensor: Semiconductor strain gauge Calibrated Accuracy: 2% FSR, 0.25% @ 25°C typical Pressure Response Time: 0.1 ms (1 0 to 90% FSR) Text: Configurable channel text size Indicators: Power, status, memory Backlight: Configurable w/auto shut-off and contrast adjustment Start/Stop Time: Software programmable start time and date, up to six months in advance; Memory: 262,143 total readings; software configurable memory wrap Reading Rate: Calibration Date: Battery Type: Battery Life: Data Format: Time Accuracy: Computer Interface: 1 reading every 2 seconds to 1 every 24 hours Digital...

Abrir o catálogo na página 2
