CL-200A
1 / 5Páginas

Excertos do catálogo

Ideal for measuring color temperature Chroma Meter CL-200A Even measures new light sources such as LED lighting and organic EL lighting A compact, lightweight instrument act lightweight instrume h with a detachable receptor. Includes convenient, easy-to-use software.

Abrir o catálogo na página 1

De facto industry standard for measuring color temperature! Compact and easy to carry The CL-200A's compact body fits in your palm. Battery-powered so it can be taken along and used anywhere. Detachable receptor head The receptor head can be detached and then connected to the main body using a normal LAN cable*, making it easy to install the sensor in an inspection system. * Optional Adapter Units required for receptor head and main body Can also measure illuminance (JIS AA class) Application examples Data transfer using main body buttons When using the CL-200A with Data Management Software...

Abrir o catálogo na página 2

For accurate measurements of color temperature, use the CL-200A! Measurement accuracies of CL-200A and photographic color meter When measuring light sources with non-continuous spectrums such as LEDs, etc., accurate illumination color temperature is particularly required. The CL-200A can measure color temperature accurately. CL-200A The CL-200A has sensors that closely match the color-matching functions deﬁned by the CIE (International Commission on Illumination), enabling precise color measurement. The measurement results can be displayed in various color notations such as "Correlated...

Abrir o catálogo na página 3

General Reference Information Measurements in the LED manufacturing process Colors mix to create white light! When made from blue LED and phosphor The blue light emitted by the LED mixes with the yellow light emitted by the phosphor to create white light. Blue light emitted by LED element Yellow light emitted by phosphor Since the spectral emission distribution of the blue light emitted by the LED varies for each unit, variations in the resulting white light will occur. Since usually LED lamps use several LEDs, control of color mixing is necessary. Electrode LED element Phosphor General...

Abrir o catálogo na página 4

SYSTEM DIAGRAM Optional Receptor Head CL-200A* Receptor Head For CRT Measurement External Power <Standard accessories> <Optional accessories> *Not included as standard accessory in some areas. Main specifications of Chroma Meter CL-200A Model * 800 lx, Standard Illuminant A measured DIMENSIONS (Units:mm) With receptor head attached to main body With adapter unit attached to receptor head Main specifications of Data Management Software CL-S10w SAFETY PRECAUTIONS For correct use and for your safety, be sure to read the instruction manual before using the instrument. • Always connect the...

Abrir o catálogo na página 5
