YOUR CONNECTOR Required voltage? SQUICH®, screw, crimp surface mounting? With cover? With pegs

Choose CLASS for heavy-duty applications They can be used in aggressive industrial environments and wherever there is a need for heavy-duty applications. CLASS connectors are used in connections for electrical and electronic equipment, machines, control units, electric panels, control equipment and where a safe sectionable connection is required. A TR The CLASS series consists of inserts manufactured in type-approved thermoplastic resin UL 94 V-0 and silver or gold plated contacts. Coupling with metallic enclosures, complete with locking levers in reinforced thermoplastic or galvanised...

First, select the inserts... Connection type 1 Crimped Crimped female contacts - Silver-plated Crimped male contacts - Silver-plated

... then, the bulkhead mounting housings, BULKHEAD MOUNTING HYGIENIC T-TYPE/H Series In thermoplastic material (IP66/IP69 degree of protection) 1 LEVER Dimensions of inserts/ enclosures WITHOUT cover WITHOUT cover THIH 10 THIH 16 THIH 24 T-TYPE/C series for temperatures between -50 °C and +70 °C available on demand. BULKHEAD MOUNTING C-Type Series CLASS rotating lever (IP65/IP66 degree of protection) 1 LEVER Dimensions of inserts/ enclosures q 66.40 q 44.27 q 57.27 q 77.27 q 104.27 q 77.62 q 104.62 BULKHEAD MOUNTING WITH metal cover WITHOUT cover WITHOUT cover IL-BRID Series Soft closing,...

2j ... or the surface mounting housings, <#> Version CV/MV (IP65/IP66 degree of protection). 7)Also available: high constructions with pre-code CVAP/MVAP/C7AP/M7AP and Pg21, Pg29, M32, M40 threads. 8) Version C7/M7 (IP66/IP67 degree of protection). Degree of protection compliant with IEC 60529, when the connector is

... and finally, the coupling hoods. In thermoplastic material (IP66/IP69 degree of protection) FOR 1 LEVER Dimensions of inserts/ enclosures q 44.27 q 57.27 q 77.27 q 104.27 9) TMAO 10.25 TMAO 16.32 TMAO 24.32 M32 version also available. M40 version also available. For C-Type / IL-BRID / C7 Series With 2 or 4 pegs FOR 1 LEVIER Dimensions of inserts/ enclosures Pg q 49.1611) CZO 15 L q 66.1611) CZO 25 L q 66.4011) q 44.2711) CHO 06 L16 q 57.2711) CHO 10 L q 77.2711) CHO 16 L q 104.2711) CHO 24 L q 77.62 CHO 32 L q 104.62 CHO 48 L 11) Also available: high constructions with pre-code...

CLASS Inserts Series Full data sheets available at www.ilme.com CK - CKS - screw terminal - spring - screw terminal - spring CDA - CDC - CSAH Type of connection: - screw terminal - crimp - SQUICH® - spring without tools 16A - 500V - screw terminal - spring - crimp - spring high density - spring dual terminal - crimp - screw terminal - SQUICH® - screw terminal - screw terminal - spring - screw terminal MIXO - spring CHOOSE YOUR CONNECTOR
