GENSYS 2.0 CORE Core unit for all-in-one genset control and paralleling unit with integrated PLC • Rear mounted control and paralleling module • To use with the remote display module : RDM 2.0, programmable by equations • I/O flexibility • Isolated communication ports: RS485, 4 CAN bus, • SD card reader, Ethernet • Fully compatible with all speed governors and AVRs • Engineering services for specific applications The GENSYS 2.0 CORE is an easyto-use rear-mounted, control and paralleling module which can synchronize up to 32 generators. The modules are designed to work with independent remote display module RDM 2.0 which are connected through Ethernet. GENSYS 2.0 CORE is configured with CRE Config software or via its embedded Web site. INPUTS / OUTPUTS EXTENSION The kit GENSYS 2.0 CORE and RDM 2.0 packs all standard features of a classic GENSYS 2.0 and adds to it remote display possibilities. It is an extendable system that can be optimized to your space facility. The GENSYS 2.0 CORE module is a real PLC unit where equations and sequences can be programmed directly by the user with text editor software or Easy PLC software. The number of inputs/outputs that can be added is one of the most important on the market. Extension modules (DIN rail mounting) can be added on the CAN bus. This extends a large number and a large diversity of inputs/outputs up to 128 digital inputs, 64 digital outputs, 44 analog inputs, 32 analog outputs and CANopen standard module. MINIMUM OPTIONS The GENSYS 2.0 CORE is offered full features with a minimum of options to fit all types of application without expensive add-on packages. For specific needs, the following options are available: • Mains paralleling • Phase shift compensation (ie: Dyn11) added value EQUATIONS : Embed your knowledge! GENSYS 2.0 CORE integrates a real PLC unit in which user equations and sequences can be written using a simple text editor or graphically designed using the Eas

Abrir o catálogo na página 1

Thanks to its versatile connectivity the GENSYS family is compatible with peripheral devices: • Electronic engines: CAN bus J1939/MTU MDEC • Speed governors: ±10 VDC/Pulse kΩ/PWM 500Hz • AVR: 0-10 Pulse • PLC/HMI: Modbus RTU RS485/ Modbus TCP Ethernet • Power transducers: 4-20mA • CANopen I/O extensions (only for GENSYS 2.0 and GENSYS 2.0 CORE) • Mains: CAN inter-GENSYS • Analog load sharers: parallel lines INTER-UNIT ISOLATED CAN BUS The GENSYS 2.0 CORE features an isolated CANbus dedicated to intermodule communication (dead busbar management, static paralleling, kW and kVAR load...

Abrir o catálogo na página 2

GENSYS 2.0 CORE FEATURES Control and management • Manual and automatic engine control. • Automatic start/stop control depending on load demand. • Dead busbar management. • Isochronous or droop kW load sharing control (via CAN bus serial port, up to 32 generators) • Constant voltage (or droop) kVAR load sharing control (via CAN bus, up to 32 generators) • Power factor control when paralleling with mains. • kW control (base load or peak shaving) when paralleling with mains. Current, voltage and frequency • DC voltage power supply input: 8 to 40VDC, 600mA at 12VDC and 300mA at 24VDC. • AC...

Abrir o catálogo na página 3

From speed governor 4 mm2 wire -Alim Engine meas. 2 Engine meas. 2 + Oil pressure meas. + Mains Gen Breaker INClose Breaker Water temp meas + J4 /Oil press Bus / Mains I1 Spare Bus / Mains I1 + Spare input J6 Bus / Mains I2 Spare input J7Bus / Mains I2 + Spare input J8 Bus / Mains I3 Spare input J9 Bus / Mains I3 + Spare input J10 Bus / Mains L1 Mains Common Remote start/stop Water temp meas. - Spare input J12 Bus / Mains L3 Spare input J14 Spare input J15 Remote start/stop Spare J4 /Oil press Spare J5 /Water temp Spare input J6 Spare input J7 Spare input J8 Wiring example : 1 genset to...
