Materials Testing Product Information Specimen blanking machines for specimen preparation of metals Hydraulic specimen blanking machine type M-Cut 65 Hydraulic specimen blanking machine type RZ 100 Nowadays test pieces from steel sheet and metal foils are economically and accurately produced using speci- men Planking machines. The standards, e.g. ISO 6892, ASTM A 370, ... stipulate that the test results must not Pe influenced by any material change caused by strain-hardening at the test piece edge zone. Numerous structural examinations of steel sheet have shown that the strain-hardening zone along the cut- ting line is generally a maximum 10 % of test piece thickness. This is achieved by a low cutting speed and special blanking tool design and offers substantial eco- nomic advantages in the event of subsequent grinding. In this way high specimen quality is ensured. We offer following models: C-shape specimen blanking machines The open shape of specimen blanking machines and blanking tools (C-shape) also allows specimens to be taken from panels. If several blanking tools are used the roller table version of the table extension is recom- mended: So blanking tools not being used at that time can be put aside. With table extension, tool changes take about 20 seconds, offering significant time-savings where tool changes are frequent. The blanking machine M-Cut 65 (with a compressive force of 650 kN) is suitable for the material thicknesses 0.04 to 6 mm (depending on tensile strength and speci- O-shape specimen blanking machines The closed shape (O-shape) requires pre-cut strips 70 ... 80 mm wide. These specimen blanking machines are already equipped with a table extension. Blanking tools Blanking tools can be produced exactly to customers' requirements, an example being tools made from a spe- cial steel which were produced with additional guides to enable dumbbell specimens to be punched from foils with a thickness of 0.04 mm and a tensile strength of 2,150 MPa. Depending on the strength of the material, duced with the tools, which can then be re-sharpened. • Fast, cost-efficient production of tensile specimens • No specialists required - anyone can operate the machine after a brief training period • Manufacture of very high-quality specimens by finishing with a specimen grinding machine • Robust, easily maintained machines • Long edge life of the blanking tools and possibility of repeated resharpening

Zw/ck # Roell Materials Testing Product Information Specimen blanking machines for specimen preparation of metals Item number Piston stroke Weight approx. Hydraulic power pack (inclusive) Working pressure Flow capacity Weight approx. Power supply Noise emission Option table extension to M-Cut 65 Table extension for total of 2 blanking tools - For a quick change of the blanking tools Table extension for total of 5 blanking tools - To put aside blanking tools that are not in use Item number The table extension for M-Cut 65 enables a quick change of blanking For all specimen blanking machines we...

Materials Testing Product Information Specimen blanking machines for specimen preparation of metals Blanking tools to M-Cut 65 Item number Blanking tool for EN 10002/ISO 6892 specimen type 2, sheet thickness 0.2... 1.2 mm stamping allowance each side 0.2 mm, sength 250 mm, width 30 mm, radius 20 mm Blanking tool for EN 10002/ISO 6892 specimen type 2, sheet thickness 1.2...3 mm, stamping allowance each side 0.2 mm, length 250 mm, width 30 mm, radius 20 mm Sheet thickness Stamping allowance (each side) Item number Sheet thickness Stamping allowance (each side) Item number
