ENCLOSURES CONTAINERS Օ CASES CUSTOM FABRICATION >

Zero is the leading manufacturer of quality, deep-drawn aluminum and plastic cases and enclosures. We offerover 32,000 pre-tooled sizes and can develop any custom design according to your specifications. Zero is the only case manufacturer to offer full in-house modification services - eliminating the need for multiple vendors when ful- filling alteration, assembly, accessory and cosmetic requirements. Deep draw is the process of gripping a sheet of aluminum (or brass, copper, cold rolled steel or mu metal)between a pressure pad and a draw ring. Hundreds of tons of pressure is then exerted onto...

Aluminum General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6Rectangular and Square Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-29Round Housings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30-37Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38-47Nutplates...

High Strength-to-Weight Ratio Aluminum alloys are known for their strength and light weight, especially when heat-treated to T6 condition. Extraordinary Resistance to Corrosion Aluminum is highly resistant to nearly all substances that cause corrosion and weathering. Endurance Against Stress, Tearing and Cracking Aluminum offers a much better fracture toughness than most other materials used in enclosures, including resis- tance to breakage and fractures. Sustaining Cold Temperatures Instead of becoming more fragile and brittle in cold weather, the tensile strength of aluminum actually increases,...

CAUTION: Pattern AA Nutplate patterns arerestricted to minimum sizes due to space on basic enclosures as fol- lows: Recommended for boxes under 1.62Ք wide > Pattern BB Not recommended for boxes under 1.75 x 2.87Ԕ Pattern CC Not recommended for boxes under2.00 x 2.50Ԕ Pattern DD Not recommended for boxes under 1.44 x 2.44Ԕ Pattern EE Not recommended for boxes under 1.75 x 2.87Ԕ Pattern FF Not recommended for boxes under 2.00 x 3.00Ԕ Pattern GG Not recommended for boxes under 1.75 x 3.75Ԕ Pattern HH Not recommended for boxes under 2.12 x 3.00Ԕ Pattern JJ Not recommended for boxes under 2.00 x 4.00Ԕ...

On all boxes under 1.62width use pattern AA only. 49 > NOTE: All nutplates are located oncenter lines or located .25Ԕ from radii points of tangency with the exception of pattern HH and JJ. The typical location of HH and JJ is as shown in pattern HH. >

.125 .120 WASHER WITH SEAL ZP20733 GASKETNEOPRENE (MIL-R-6855 CLASS II GRADE 30) .06 THICKNESS GASKET IS SHIPPED LOOSE >

Custom Modifications Custom cases are not only practical,but are often critical for the protection and performance of the equipment they contain. Zero specializes in cre- ative solutions for custom needs. We use thirteen state-of-the-art net- worked CAD-based design systems that enable our engineers to develop intelligent and truly functional custom solutions that meet and exceed the most stringent specifications, includ- ing all military specs. Our extensive field experience and in-house mechanical test capabilities make us the indisputable leader in case design. > Trumpf TLC 1005 Laser The...

Zero Manufacturing offers precisionminiature enclosures in aluminum, brass, copper, cold-rolled steel and mu metal. Zero can modify each miniatureenclosure in-house so that the prod- uct we provide is the perfect product to suit your needs. We offer a com- plete range of alteration, assembly, accessorizing, finish, marking and testing services. Please refer to the Modifications section in this catalog 52 for more details. 53 >

Note: Most parts listed in this catalogalso may be manufactured from Nickel, Silver, Cupro Nickel, and Copper. However, actual use is dependent upon the part requested. For additional information, please contact Zero Manufacturing directly.4.When you have completed a PartNumber, the number should appear as follows: ZMR Series ZMS Series , andpage 59 for Zero Circular , pages56-58 for Zero Manufacturing Rectangular ZMCSeries ).2.To the Series Number, add thenumber representingMaximum Depth of the part.Maximum Depth is found in column 3 for ZMS and ZMR Series parts and in column 2 for ZMC Series...

Alloy: An aluminum alloy is a metal that is a mixture of aluminum and one or more other elements. 1100: 99% pure aluminum. 3003: Aluminum/manganese alloy. 6061: Aluminum/manganese/silicon alloy. Artificial Aging: Anodizing: Electrochemically converting the surface of aluminum from metallic aluminum to aluminum oxide (alumina) by making aluminum the anode in a plating-type electrochemical cell. It is used not only for added protection, but also in conjunction with dying and sealing to create decorative effects. Speeding up the natural aging cycle by heating the metal for a short time. CF: Flush...

Reflectivity: RFI: Radio frequency interference. The ability of a surface to mirror or reflect radiant energy. The reflectance of aluminum is exceptionally high. Seamless Construction: An exceptional attribute of deep drawn shells. Deep drawn shells haveno seam. Solution Heat Treating: A strengthening thermal treatment in which certain aluminum alloys areheated to a relatively high temperature and then held (soaked) for varying times. A rapid quench or natural aging follows the heating period. Strain Harden: Secondary Aluminum: Tempering through strain. Same as work harden. Metal recovered aluminum...
