Aigtek High Voltage Power Amplifier ATA-4011C

Product catalog summary

Introduction
The ATA-4011C is a single-channel high-voltage power amplifier designed for amplifying both AC and DC signals. It offers a maximum output voltage of 160Vp-p (±80Vp) and a maximum output power of 169.6 Wp, suitable for high-voltage power loads. The amplifier features digitally adjustable voltage gain and compatibility with mainstream signal generators, ensuring user-friendly operation and seamless signal amplification.

Specifications

Output Type: Single-ended Output
Bandwidth: DC~1.2MHz
Maximum Output Voltage: 160Vp-p (±80Vp)
Maximum Output Current: 0.75Ap (DC~50Hz), 2.12Ap, 1.5Arms (>50Hz)
Maximum Output Power: 169.6Wp
Voltage Gain: x0~50 (0.1 step/1 step)
Slew Rate: ≥ 426V/μs
Input Impedance: 50Ω/100kΩ
Output Impedance: 0.25Ω+0.6μH
Protection: Short Circuit, Over Voltage, Over Temperature
Power Supply Voltage: AC110~240V, 50/60Hz
Operating Temperature: 0°C ~ 45°C
Dimensions: 440*149*454mm (W*H*D)

Features
The amplifier includes an LCD panel display for dynamic status and parameter monitoring, digitally adjustable voltage gain with coarse and fine adjustment modes, and selectable input impedance for matching various signal sources. It also provides comprehensive protection features and is equipped with a BNC output interface.

Applications
The ATA-4011C is suitable for applications such as Nondestructive Testing (NDT), Soft Magnetic Material Testing, Transformer Testing, and various Semiconductor Testing.

Accessories
The product comes with a power cable, BNC cables, BNC-to-alligator clip cable, USB cable, fuse, user manual, usage guide, product qualification certificate, calibration certificate, and packing list.

Catalog excerpts

Aigtek High Voltage Power Amplifier ATA-4011C-1

Xi'an Aigtek Electronic Technology Co., Ltd. ATA-4011C High Voltage Power Amplifier  Maximum Output Voltage: 160Vp-p (±80 Vp)  Maximum Output Power: 169.6Wp  Bandwidth (-3dB): DC~1.2MHz  Slew Rate: ≥426V/μs INTRODUCTION The ATA-4011C is an ideal single-channel high-voltage power amplifier capable of amplifying both AC and DC signals. The device delivers a maximum output voltage of 160Vp-p (±80Vp) and a maximum output power of 169.6 Wp, making it suitable for driving high-voltage power loads. The digitally adjustable voltage gain allows precise tuning, with one-click saving of common settings, offering a simple and user-friendly operation. It is compatible with mainstream signal generators for seamless signal amplification.The wide-range power supply accommodates different regional power standards worldwide. LCD PANEL DISPLAY The LCD panel display dynamically shows the device status and parameters, offering a clear and intuitive interface. VOLTAGE GAIN The voltage gain is digitally adjustable from x0 to x50, with two modes: coarse adjustment (1 step) and fine adjustment (0.1 step). Combined with the LCD panel display, it enables quick and precise adjustment to the desired voltage value. INPUT The input uses a BNC interface with selectable impedance of 50Ω or 100kΩ, perfectly matching both high and low impedance signal sources. OUTPUT The output uses a BNC interface with a maximum output voltage of 160 Vp-p (±80 Vp) and a maximum output current of 2.12 Ap. Applications Nondestructive Testing (NDT) Soft Magnetic Material Testing Transformer Testing Various Semiconductor Testing

Open the catalog to page 1
