Wheel Loader XC906EV

Product catalog summary

Technical Specifications for the XC906EV Wheel Loader

1. Technical Performance Parameters

Rated bucket capacity: 0.2 m³
Rated load: 500 kg
Operating mass: 1400 kg
Dumping height: 1750 mm
Dumping reach: 510 mm
Wheelbase: 1560 mm
Tread: 880 mm
Overall dimensions: 3720 mm (length) x 2230 mm (height) x 1100 mm (bucket width)
Max. breakout force: 18 kN
Max. traction force: 12 kN
Turning radius: 2950 mm
Boom lifting time: ≤4.5 s
Fastest three cycle time: ≤10.5 s
Battery: 8/12 kWh
Hydraulic motor power: 3 kW
Traveling motor power: 3 kW x 2
Tire type: 23X8.5-12
Travel speed: 0-13 km/h (forward and reverse)

2. Performance Features and Configuration

Developed by XCMG's Earthmoving Machinery Division with a focus on new energy power.
Features include dual-sealing connections, national standard batteries, and a large-angle rear-side opening hood for maintenance.
All vehicle pins and hydraulic components undergo treatments for enhanced durability and resistance.
Structural components use high-grade steel plates (Q355B or higher).
Hydraulic system designed for efficiency with large-bore valves and ergonomic layout.
Electrical system optimized for dustproof, waterproof, and anti-vibration performance.
Working device ensures effective loading and unloading with a large transmission angle.

3. Main Component Configuration

Hydraulic motor: IM151040Y
Traveling motor: IM150802S
Drive axle: XC906EV.3.1.1
Distribution valve: DLF10D0302J160XX
Battery: DLF10D0302J160XX

Catalog excerpts

Technical Specifications for the XC906EV Wheel Loader 一、 Technical Performance Parameters Table 二、 Performance Features and Configuration Description 三、 Main Component Configurat

Open the catalog to page 1

2. XC906EV Loader Performance Features and Configuration Description XC906EV Wheel Loader is a new product independently developed by XCMG's Earthmoving Machinery Division. Configuration: 8/12 + triple-motor + dry axle + dual-circuit pump + 0.2 m³ bucket; The steering system features an articulated frame with full hydraulic steering, while the working device adopts a single rocker arm reversed "Z"-bar six-linkage mechanism. Product Features: (1)Dual-sealing connections utilizing 24°cone + sealing ring provide superior sealing

Open the catalog to page 3

performance and enhanced reliability. Tubing is centrally routed with optimized pathways. (2) Equipped with national standard batteries and supports national standard AC slow charging. (3)Adopts a large-angle rear-side opening hood, facilitating maintenance operations. (4)All vehicle pins undergo quenching and tempering treatment, with a surface hardness of ≥50HRC. (5)The hydraulic oil tank and fuel tank undergo pickling and phosphating treatment to ensure the cleanliness of hydraulic oil and fuel. (6)All vehicle fasteners are treated with Dacromet technology, providing strong rust resistance....

Open the catalog to page 4

facilitate subsequent filter replacement and hydraulic oil tank cleaning. 1. For the hinge-passing pipelines in the machine’s overall hydraulic system, an S-shaped routing method is adopted. This layout ensures the pipelines are neat and aesthetically pleasing, avoids interference, increases the hose bending radius, and improves both the service life of the pipelines and the machine’s maintainability. 2. For pipelines involved in moving components such as the boom and bucket, flexible hoses with smaller bending radius are used. The hoses are reasonably arranged, and their bending radius are designed...

Open the catalog to page 5
