RFL-P200 / RFL-P300 Pulsed Fiber Laser User Guide Wuhan Raycus Fiber Laser Technologies Co., Ltd.

Wuhan Raycus Fiber Laser Technologies Co., Ltd.

Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P200/ RFL-P300

Wuhan Raycus Fiber Laser Technologies Co., Ltd. Thank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly. 1.2 Laser Safety Grade According to the European Community standards EN 60825-1, clause 9, this series of lasers are classified as a high power Class 4. This product emits invisible laser radiation at wavelength...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. Table 1: Safety identification AVOID EXPOSURE-VISIBLE AND/OR INVISIBLE LASER RADIATION IS EMITTED FROM THIS APERTURE Chinese Lable MAX.AVERAGE OUTPUT POWER:200W MAX.PEAK OUTPUT POWER:150kW WAVELENGTH RANGE: 1000-1200nm PULSE DURATION:70-130ns PULSE REPETITION RATE: 1 0-50kHz DANGER—VISIBLE AND/OR INVISIBLE LASER RADIATION AVOID EYE OR SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION CLASS 4 LASER PRODUCT MAX.AVERAGE OUTPUT POWER:1mW WAVELENGTH RANGE:600-700nm VISIBLE LASER RADIATION DO NOT STARE INTO BEAM OR EXPOSE USERS OF TELESCOPIC OPTICS CLASS...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. 6: Laser Radiation Hazard 1.4 Optical Safety Any dust on the end of the collimator assembly can burn the lens and damage the laser device. CAUTION: DO NOT emit when the protective cap is not removed, otherwise the lens or crystal will be damaged. a) Ensure the product is grounded through the PE line of the AC power cord. The grounding must be firm and reliable. 1.6 Other Safety Rules a) Do not directly view the laser output head when laser emitting. Avoid using the laser in a dark environment. b) Do not use fiber lasers in dark environments. c)...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. Raycus pulse fiber laser is designed for industrial and scientific research applications with high pump conversion efficiency, low power consumption and excellent beam quality. It is compact and ready to use. It can be used as a stand-alone unit or easily inserted into user’s apparatus. Main Features: > Uniform distribution of stop energy > High reliability, long-life > Maintenance free operation > High photoelectric efficiency Applications: Please refer to package accessoriesare in the packing box. Raycus fiber laser is delivered in a package,...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. pull the output cable when unpacking the device; and avoid any collision to the head of laser output. CAUTION: The fiber optic cable and output head are precise optic instrument, ANY vibration or impact to the output head, and twist or excessive bend to the cable will damage the instrument. The operation conditions are listed as the following table: Table 2: The Operation Environment Conditions for the Laser a) Make sure the product is properly grounded before use. b) The laser output head is connected with fiber optic cable. Please inspect the...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. a) Make sure that the correct voltage of 220V AC is used. Failure to connectly connect power supply will damage the device. b) The output laser is collimated by the collimating lens, it is important to keep the collimating lens clean, otherwise it will damage the device. c) Please cap the output head when it is not in use. Do not touch the output lens at any time.Use appropriate lens paper to clean it if necessary. d) Safety keep the cap when using the laser. To avoid dust, make sure the opening direction of the cap is put down. e) Failure to follow...

Wuhan Raycus Fiber Laser Technologies Co., Ltd.

Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P200/ RFL-P300 3 Installation 3.1 Dimensions Figure 2 shows dimensions of the product.

Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P200/ RFL-P300 Figure 2: Dimensions of 200W Product (unit:mm) The output head is QCS, the following figure 3 show the details of the QCS output head. Figure 3 QCS Output head (unit: mm) CAUTION: a) Keep the protective cap properly, prevent it from contamination; Or the aperture will be contaminated when capped. b) Make sure the aperture and the cavity of the processing head is clean.

Wuhan Raycus Fiber Laser Technologies Co., Ltd. \Raycus 3.2 Cooling Requirements Table 4 Cooling Requirements Temperaturesettingof cooling water:25 + 0.5°C Requirements on Cooling Water: a) Purified water should be used. b) In order to prevent the growth of mould that may lead to blockage, adding alcohol solution to about 10% of the total volume is recommended. c) If ambient temperature is between -10 C and 0 C, we recommend to use 30% alcohol(volume ratio), and replace it every 2 months. d) If ambient temperature is below -10 C , the chiller with both heating and cooling functions must be used,...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. a) Place the product in an appropriate position, immobilize it if necessary. b) Check if the power supply has the correct voltage (220V AC±10% , 50/60Hz), and the earth line is connected, make sure it is firm and reliable. c) Connect the power cable and control cable to the product when power supply is OFF. d) Clamp the water pipes ontopipe connector, run the chiller to check if there is any leakage in the water circulation. e) Check the output head and clean it before installation. This procedure must be performed by Raycus personnel or person...

Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P200/ RFL-P300 CAUTION: All the cables can only be connected when power supply is off. Hot plug may damage the device. CAUTION: a) Ensure that there are no fiber bends in radius less than 30cm when the product is installed. Avoid excessive twisting and tight bends during the robotic arm movements. b) Tight bends will damage the laser delivery system. CAUTION: c) Keep the protective cap properly, prevent it from contamination; Or the aperture will be contaminated when capped. d) Make sure the aperture and the cavity of the processing...
