Product catalog summary

Company Overview: Woertz AG, a family-owned business established in 1928, is based in Muttenz, Switzerland, with a branch in Hölstein. The company employs approximately 220 people and specializes in manufacturing circuitry accessories, installation systems, and electronic control systems. Woertz is ISO 9001 and ISO 14001 certified, focusing on security, user-friendliness, and ease of handling in their products.

Product Range: Woertz offers a variety of products including terminals, junction boxes, grounding products, surge protection devices, flat cable installation systems, floor ducts, electronic modules, and interfaces. Circuitry accessories and electronic control systems are produced at the headquarters, while duct and double floor systems are manufactured in Hölstein.

Insulating Materials: The insulating bodies of terminals are made from polyamide 66, known for its hardness, rigidity, scuff resistance, and thermal endurance. It is self-extinguishing, halogen-free, and approved by leading certification institutions, capable of withstanding temperatures up to 100°C and reinforced with fiberglass for higher temperature applications.

Connection Types: Woertz provides various terminal types, including screw connections with or without springs, and branching terminals for through conductors. These terminals are corrosion-resistant and suitable for marine systems and hazardous locations.

Nominal Cross-Section: Terminals can connect multiple conductors of the terminal's nominal cross-section, accommodating solid, rigid stranded, and flexible conductors.

Earthing and PEN Conductor Subdivision: The document emphasizes the subdivision of the PEN conductor in distribution systems, using neutral disconnecting terminals and bare earthing terminals to ensure safety and compliance with electrical standards.

Terminal Series Overview: The catalog includes various terminal series for mounting rails according to EN 60715 TH 35, such as basic terminals, enclosed and bare earthing terminals, disconnecting terminals, and fuse terminals, each designed to meet specific demands and heavy-duty applications.

Technical Specifications Overview:

Voltage and Current Ratings: Terminal blocks have voltage ratings from 250V to 800V and current ratings from 6.3A to 269A, depending on type and configuration.
Connecting Capacity: Terminals support wire sizes from 0.5 mm² to 120 mm², accommodating both solid and stranded conductors.
Clamping Mechanism: Clamping screws are made of nickel-plated brass, with options for slotted and socket screws. Clamping torque values are provided for electric screwdrivers.
Material Composition: Components are constructed from materials such as nickel-plated brass, stainless steel, and PA 66 for insulation.

Accessories and Marking:

Marking Accessories: Various labeling options are available to ensure clear identification of terminals.
End Barriers and Stoppers: Provided to ensure safety and proper termination of connections.

Special Features and Recommendations:

Disconnecting Terminals: Include knife disconnecting mechanisms for safe operation with additional springs to prevent loosening.
Fuse Terminals: Options with and without LED indicators for fuse status, supporting fuses up to 6.3A.
Branching Terminals: Designed for main and branch connections, including sliding covers and available in various sizes and ratings.
Safety Precautions: Advises against handling plugs or knives when live and considering heat generation in fuse terminals during installations.

Installation and Usage:

Connection Instructions: Detailed steps for connecting conductors, including unscrewing clamping screws and inserting conductors before securing them.
Protection Against Contact: Accessories available to ensure safe handling and operation of terminals.

Technical Specifications:
- Wire gauge: 4-12 AWG
- Voltage and current ratings: 500V/32A, 300V/20A
- Colors: Grey, Blue, Green and Yellow (insulated earthing conductor)
- Article numbers: 30902GR, 30902BL, 30902E

Technical Data:
- Connecting capacity: 3.2 x 5 mm
- Clamping screws: M3
- Central thread: M3
- Strip insulation: 10 mm
- Packing unit: 100 pcs

Accessories:
- Test adaptors: 80070, 2737
- Marking accessories: 3957/., 3958/., RB/6x9
- End barriers, partitions, stoppers: 30912, 30922, 2765, 2754
- Insulated cross-connections for 2, 3, 4, 5, or 10 terminals
- Terminal covers for 4, 5, 6, 7, or 8 terminals

Earthing Terminals:
- Bare earthing terminal made of pickled brass
- Screws and springs of stainless steel
- Connection between mounting rail and terminal protected against loosening

Partially Enclosed Earthing Terminal:
- Clamping units of nickel-plated brass
- Screws, springs, and earthing base of stainless steel
- 3-figure marking on both sides

Two-step Terminals:
- Clamping units and connecting bars of nickel-plated brass
- Screws of stainless steel
- Lower and upper levels vertically shifted

Small Screw Terminal:
- Clamping units and connecting bar of nickel-plated brass
- Screws of stainless steel
- For insulated, recessed, and separable cross-connections

Wire-wrap Terminal:
- With a screw terminal 1.5 mm2 and a wire-wrap pin 1x1 mm of nickel-plated brass
- Screw of stainless steel

Accessories Overview:
- End barriers and partitions
- Stoppers
- Insulated cross-connections
- Cross-junction racks
- Rails and accessories
- Angled support brackets for rails
- Terminal covers and accessories
- Test plugs
- Marking accessories

Branching Terminals:
- Made of steatite for high temperature and humidity resistance
- Ratings: 2.5 mm2 (660V, 24A), 6 mm2 (660V, 41A), 10 mm2 (660V, 57A)
- Suitable for outdoor switchboxes, casings, tunnels, and streetlamp posts

Catalog excerpts

Screw t terminals f for D DIN35 r rail E EN60715 T TH 3 35 Series C Compactpages 1 1.1.16 t to 1 1.1.37 > Series C Comfort p pages 1 1.1.38 t to 1 1.1.56 > Screw t terminals f for D DIN15 r rail E EN 6 60715 T TH 1 15 Terminal s seriespages 1 1.1.108 t to 1 1.1.115 > Screw t terminals f for W Woertz r rail 4 4050A Terminal s seriespages 1 1.1.124 t to 1 1.1.132 >

Open the catalog to page 3

The Woertz company was founded in 1928; our head office is in Muttenz near Basle, Switzerland.We are a family business with about 220 employees known as a quality manufacturer of circuitry accessories,installation systems and electronic control systems.Our goals are:- security, - user-friendliness, - and easy handling of our products. We are certified according to ISO 9001 and ISO 14001. Our range of products includes:- terminals, junction boxes, grounding products, surge protection devices, anchor channels andanchoring studs- flat cable installation systems - floor ducts, double floor systems,...

Open the catalog to page 4

The insulating body of our terminals is made of polyamide 66. Even if this polyamide is subjected to a constant temperature of 100C, it fulfills the electri-cal, mechanical and chemical properties required in terminals. The typical features of polyamide 66 are hardness, rigidity, scuff resistance and thermal en-durance.Fuse terminals and fuse plugs, where constant temperatures of over 100аC can occur, are made of polyamide 66 reinforced with fibreglass.Polyamide 66 is hardly combustible, self-extinguishing and halogen-free (when a fire breaks out, there cant be any emanation of toxic gas combustion,which,...

Open the catalog to page 6

without a additional s spring To connect one or more conductors with a clamping unit.Clamping unit of nickel-plated brass. Screws of stainless steel. Connecting bars of nickel-plated copper alloy. Corrosion resistant, also suitable for marine systems. Approved for hazardous locations. > with a additional s spring t to p prevent w wires f from w working l loose To connect one or more conductors with a clamping unit.Clamping unit of nickel-plated brass. Screws and springs of stainless steel. Connecting bars of nickel-plated copper alloy. Corrosion resistant, also suitable for marine systems, for...

Open the catalog to page 7

2 No. 3838, 3839Bare earthing terminals 10-120 mm Terminals for polar conductor4-70mm > 2 Label carrier for group marking No. 3459Neutral disconnecting terminal 25, 63, 100 and 160ABranching terminals 10-120mm Detachable neutral connectors 20, 25 and 63AEnclosed earthing terminals 4-35 mm > 2 2 2 Busbars10x2 or 10x3 mm > PEPEN Supply 3P+PENnon-through For feed lines Terminals for busbar 10-35mm Stopper No. 3418Transparent cover Supportingstud Transparent c cover A Art. N No.30050 Length: 114 mmWidth: 90 mmWith 2 holes for sealable screwsDistance between holes: 100 mm With warning to protect against...

Open the catalog to page 10

Junction boxes:series 2079K...see page 4.1.5 > 1.1.11 size="-1">

Open the catalog to page 11

Basic terminals 2.5-16 mm > 2 2 2 series 3450pages 1.1.16 - 1.1.17Enclosed earthing terminals4-16 mm series 30544/.Vpages 1.1.18 - 1.1.19 Bare earthing terminals 4-16 mm series 30371pages 1.1.20 Return terminals2.5 mm > 2 2 2 2 series 30903pages 1.1.21 - 1.1.22 Three-step installation terminals, 4 mm series 30810pages 1.1.23 X-/Y-terminals 2.5-4 mm series 3430pages 1.1.24 - 1.1.25 Two-step earthing terminal4 mm series 3430/4Vpage 1.1.26 Three-step terminals for proximity switches , 2.5 mm > 2 2 2 series 30431pages 1.1.27 - 1.1.28 Two-step terminal withdisconnecting function 2.5 mm series 30403pages...

Open the catalog to page 12

Terminals for stringent demands 2.5-70 mm > 2 2 2 series 3436pages 1.1.43 - 1.1.45 Disconnecting terminals 2.5 mm series 3424pages 1.1.38 - 1.1.40Enclosed earthing terminalsfor stringent demands4-70 mm series 3436Vpages 1.1.41 - 1.1.42 Bare earthing terminals 4-16 mm > 2 2 2 series 3472pages 1.1.46 - 1.1.47 Fuse terminals 10 mm series 30124pages 1.1.48 - 1.1.49 Neutral disconnectingterminals, 4-16 mm > 2 , series 30168pages 1.1.50 - 1.1.52 Universal test terminal 10 mm series 30146page 1.1.53 > 2 series 30176pages 1.1.54 - 1.1.56 Longitudinal, lateraldisconnecting terminals2.5/10 mm > 1.1.13...

Open the catalog to page 13

Branching terminals 2.5-120 mm > 2 2 series 30840pages 1.1.57 - 1.1.59Bare earthing terminals 2.5-120 mm series 30380pages 1.1.60 - 1.1.62 Neutral disconnectingterminals 10-50 mm >

Open the catalog to page 14

Basic terminals 2.5-16mm > 2 . . . . . . . . . . . . . . . . .1.1.16-1.1.17Enclosed earthing terminals 4-16mm > 2 . . . . . . . . . .1.1.18-1.1.19Bare earthing terminals 4-16mm > 2 . . . . . . . . . . . . . . . . .1.1.20Y-terminals 2.5+4mm > 2 . . . . . . . . . . . . . . . . . . . . . . .1.1.21X-terminals 2.5mm > 2 . . . . . . . . . . . . . . . . . . . . . . . . .1.1.22Return terminals (2 connections on the same side) 2.5mm > 2 .1.1.23Two-step terminals 2.5-6mm > 2 . . . . . . . . . . . . . . .1.1.24-1.1.25Two-step earthing terminal 4mm > 2 . . . . . . . . . . . . . . . . .1.1.26Three-step installation...

Open the catalog to page 15

PA 6 66 4 > 6 6 > 7 10 > 8 -Metal body and clamping unit of nickel-plated brass-Screws, springs and earthing part of stainless steel-4-figure marking on both sides -Ex terminals also available(see Ex flyer) > 35 39 42 48 48 48 Article n numbers Ratings UL467 Short-Time Current TestFor terminals for polar conductor 1.5-4 mm > 2 24-12 AWGAWG12, 470A during 4s.30150/3450 2.5-6 mm > 2 24-10 AWGAWG10, 750A during 4s.3452/6 4-10 mm > 2 24-6 AWGAWG6, 1530A during 6s.3452/10 green/yellow 30544/4V 30544/6V 30544/10V Technical d data Connecting capacitymmClamping screws Strip insulationmm Clamping couple...

Open the catalog to page 18

PA 6 66 16 > 13 -Metal body and clamping unit of nickel-plated brass-Screws, springs and earthing part of stainless steel-4-figure marking on both sides -Ex terminals also available(see Ex flyer) > 42 54 Article n numbers Ratings UL467 Short-Time Current TestFor terminals for polar conductor 6-16 mm > 2 14-4 AWGAWG4, 2450A during 6s.3452/16 green/yellow 30544/16V > Technical d data Connecting capacitymmClamping screws Central thread Strip insulationmm Clamping couple for electric screw-driverNm Packing unitpcs 7.5 x 6.5M5 M4132.125 Accessories s see p pages 1 1.1.71 t to 1 1.1.107 Marking accessories...

Open the catalog to page 19
