Decentralised power distribution for flexible installations Օ Very short mounting procedures Extension facility i 1 Cabling Systems Quick connection technique 5.2 woertzQ works wel

Description of the system Easy and reliable. Connection without Box with screw any to°' Insulating tape connection i Supply or screw-type branching Security Easy calculable costs Օ Low fire load Reverse polarity protection Օ Riskless investment Low error rate Time saving Օ Piercing technology: insulation has not to be stripped Possibility of pre-wiring Օ Saves connection time Flexibility Loads may be connected at any point of the cable Օ Connecting boxes may be displaced as wanted Extension possible at any time Օ Easy restructuring of the installation Highly adaptable to existing space

Overview Lighting Sockets Appliances, air conditioning, blinds, actuators Bus lines Current supply Machines Motors Boxes for supply and branching (Connecting boxes) Field cables ecoline P3 3G2.5mm2 p. 5.2.10 „Ï „Ï „Ï ecobus power 5G2.5mm2 p. 5.2.18 „Ï „Ï „Ï „Ï • ecobus data 2x1.5mm2 p. 5.2.28 „Ï ecobus combi 5G2.5mm2+2x1.5mm2 p. 5.2.34 „Ï „Ï „Ï „Ï „Ï • multibus 4x1.5mm2 p. 5.2.58 „Ï ecofil i 7G2.5mm2 p. 5.2.66 • „Ï „Ï „Ï „Ï ecofil 5G4mm2 p. 5.2.72 „Ï „Ï „Ï „Ï „Ï Power cables ecobus power 5G10mm2 p. 5.2.78 • „Ï „Ï „Ï „Ï „Ï ecofil i 5G16mm2 p. 5.2.84 • „Ï „Ï „Ï „Ï „Ï „Ï appropriate use •...

Branching boxes Accessories 5.2.7

Introduction Modern buildings are complex systems which must bring together a variety of requirements under one roof. Conventional technical installations are all too often incompatible with the varied demands placed on modern buildings: Clients and investors demand economy and energy efficiency, while tenants want maximum flexibility, and installation engineers systems that can be easily adapted to different requirements. Even at the project planning and implementation stages, the right approach has to be selected. Installations with flat cables leave nothing to chance. General advantages...

omparison stallations To your advantage! On the diagrams below a traditional installation has been compared to a modern ecobus flat cable installation. The decentral layout of sensors and actuators as well as the use of plug-type connectors enable the length of cable to be considerably reduced; installation and setting into operation will be realized in a very short space of time which necessarily means cost-saving. Conventional installation Flat cable installation Traditional installation Usual flat cable installation KNX flat cable installation with decentral actuators Subdistribution...

ecoline P3 3G2.5mm2 The efficiency of this system is related to its great flexibility and extension facility, anywhere, anytime. Connecting box 3x2.5mm2, No. 49687. Direct connection of loads at any point of the cable. Օ Flat cable connected by means of pointed screws - no need to strip the insulation Connection of a round cable up to 3x2.5mm2 or of a second flat cable by means of screws. Օ Suitable for the supply of flat cable or for the branching from flat cable For rational installations it is recommended to use an electric screwdriver (Please observe the tightening torques!)...

Mounting procdure of the connector No. 49695 (no need to strip the insulation - cannot be used for the supply of the cable!) Position the base of the connector and screw it on to its support if required. Position the asymmetric flat cable (right position is shown by the groove in one narrow side of the cable sheath). Is the flat cable not in the right position, it cannot be inserted into the base. ii i闗i 1 Cut the outgoing round cable to the desired length, dismantle it and introduce the leads. Tighten up the screws. Snap together the upper part and the base. The overcurrent protection...

ecoline P3 3G2.5mm2 CM iI Flat cable 3G2.5mm2 -easy installation -narrow, flexible -asymmetric flat cable to avoid reverse polarity Flat cable of PVC L+N+PE Flat cable halogen-free L+N+PE No. 49685 113 297 807 49686 113 307 807 with black strips 49685/SM 49686/SM Technical data ^^^^ ^^^^^^^^^^^^ ^^^^^^^^^^^^^^^^^^^^^ ^^^^^^ Sheath PVC, oil resisting Polyethylene Compound Colour of the sheath light grey1 light grey2 Dimensions 16.5x6mm 16.5x6mm Weight 185g/m 185g/m Fire load 0.583kWh/m 0.579kWh/m No. of leads x cross-section 3x2.5mm2 3x2.5mm2 Copper conductors Insulation of the leads Colour...

ecoline P3 3G2.5mm2 Connecting box to flat cables No. 49685 and 49686 -for branching round or flat cable -reverse polarity protection Connecting box 3x2.5mm2 for supply and branching no need to strip the insulation No. Technical data Weight Dimensions LxWxH Fire load Plastic parts Metal parts No. of leads x cross-section Connecting capacity Pointed screws Clamping screws Cross-section Rated voltage Max. rated current Packing unit Degree of protection 49687 150 701 407 45g 55x33x33mm 0.24kWh light grey / transparent, halogen-free corrosion-resistant 3x2.5mm2 0 3.75mm tightening torque 0.7Nm,...

ecoline P3 3G2.5mm2 Connector 3x2.5mm2 for branching no need to strip the insulation No. 49695 150 701 457 Technical data Weight Dimensions LxWxH Fire load Plastic parts Metal parts No. of leads x cross-section Connecting capacity Clamping screws Cross-section Rated voltage Max. rated current Packing unit Degree of protection Accessories 85g 90x30x34mm 0.36kWh light grey / transparent, halogen-free corrosion-resistant 3x2.5mm2 0 3.75mm tightening torque 0.7Nm, Phillips-head screwdriver No. 1 2.5mm2 250V 16A 10 pce. IP20 see page Connector for branching with pre-wired Wieland connector...

Accessories Cable end pice 49689 120 900 207 Of polycarbonate, halogen-free, transparent Dimensions: 45x24.5x9mm Weight: 6g Fire load: 0.06kWh Packing unit: 20 pce. Note: Before mounting the cable, first strip it at both ends for a distance of 19mm so that the specified creepage distance will be observed. m ii Clamp for screw fixing 49693 120 008 607 Of polyamide 66, halogen-free, grey Dimensions: 31x10x8.5mm Weight: 0.95g Fire load: 0.01kWh Packing unit: 100 pce. Cable stripping tool 49690 983 050 127 This tool offers the advantage of stripping neatly and easily the cable without damaging...
