Pen Beam
Pen Beam
The WISTRA PEN-BEAM is an innovative shoring beam system designed for use in commercial vehicles. It is available in both aluminum and steel versions and features a gas pressure spring for consistent pressure across its telescopic range. The system is customizable to fit various vehicle dimensions and lashing track types, with optional PVC coating for added protection.
Functionality
The PEN-BEAM is designed for ergonomic use, retracting to a length shorter than the vehicle's interior dimensions. It unlocks with slight pressure, allowing the telescopic tube to extend into the lashing track with constant pressure, minimizing vehicle body damage.
Technical Specifications for Heavy Commercial Vehicles
- Steel Version: 42 mm support tube diameter, pin version type 44 for 20/25/34 mm hole diameter, 500 daN BC blocking force, suitable for 2,480 mm vehicle interior dimensions.
- Aluminum Version: 42 mm support tube diameter, pin version type 44 for 20/25/34 mm hole diameter, 400 daN BC blocking force, suitable for 2,480 mm vehicle interior dimensions.
- Steel with PVC Coating: Same specifications as the steel version with added PVC coating.
- Aluminum with PVC Coating: Same specifications as the aluminum version with added PVC coating.
Technical Specifications for Light Commercial Vehicles
- Aluminum Version: 35 mm support tube diameter, pin version type 09 for 20 mm round hole and airline lashing track, 150 daN BC blocking force, suitable for 2,250 mm vehicle interior dimensions.
- Aluminum with PVC Cover: Same specifications as the aluminum version with added PVC cover.
Contact Information
For more information, contact UAB “Wistra Cargo Control” in Klaipeda or WISTRA GmbH in Selmsdorf. Visit their website at www.wistra.eu or their Facebook page for updates.
Catalog excerpts
Innovative shoring beam systems by WISTRA WISTRA PEN-BEAM made of aluminum or steel Functionality The WISTRA PEN-BEAM is equipped with an innovative gas pressure spring and defined pressure on the vehicle body over the entire telescope range. The special snap-in function in the telescopic tube is for ergonomic use. All PEN-BEAM variants can optionally be equipped with PVC coating. In addition, all versions can be customized according to the interior vehicle dimensions and the type of lashing track. When retracted and locked the WISTRA PEN-BEAM is shorter than the inside dimensions of the vehicle...
Open the catalog to page 2
Innovative shoring beam systems by WISTRA > 42 mm support tube diameter > pin version type 44 for 20/25/34 mm hole diameter > 500 daN BC blocking force with even surface load > for a vehicle interior dimension of 2,480 mm (+/- 25 mm) Technical specifications > aluminum version > 42 mm support tube diameter > pin version type 44 for 20/25/34 mm hole diameter > 400 daN BC blocking force with even surface load > for a vehicle interior dimension of 2,480 mm (+/- 25 mm) Technical specifications > steel version with black PVC coating > 42 mm support tube diameter > pin version type 44 for 20/25/34...
Open the catalog to page 3
UAB "Wistra Cargo Control” Pramones 8 LT-94102, Klaipeda Tel.: +370 61024943 Tel.: +370 69565282 E-mail: [email protected] Innovative shoring beam systems by WISTRA > 35 mm support tube diameter > pin version type 09 for 20 mm round hole and airline lashing track > 150 daN BC blocking force with even surface load > version for shortening with enclosed end pin > for a vehicle interior dimension of 2,250 mm (+/- 25 mm) > with black PVC cover > 35 mm support tube diameter > pin version type 09 for 20 mm round hole and airline lashing track > 150 daN BC blocking force with even surface load > version...
