7" ARM A53 EL HMI Panel PC W07IM3S-ELT1

7" ARM A53 EL HMI Panel PC W07IM3S-ELT1

Product catalog summary

Key Features
The document describes a 7-inch display with a resolution of 1024 x 600 and a P-Cap multi-touch screen for intuitive interaction. It is powered by an ARM A53 Quad-Core 2.0GHz CPU, runs on Android 11, and supports both Android and Linux operating systems. Connectivity options include 1 x USB, 1 x Micro USB, 1 x RS485, and 1 x RJ45 (LAN).

Introduction
The Winmate EL Series HMI is designed for industrial automation and control applications, offering display sizes from 4.3" to 15.6". These HMIs feature high-resolution screens and P-Cap multi-touch technology, powered by ARM A53 Quad-Core or NXP i.MX6 Dual-Core processors. They support Android and Linux operating systems, have a fanless design, low power consumption, IP65-rated front panel protection, and comprehensive connectivity options.

Specifications

Display: 7.0 inches, 1024x600 resolution, 1000:1 contrast ratio, 320 nits brightness, 75-degree viewing angles.
System: ARM A53 Quad-Core 2.0GHz processor, 4GB LPDDR4 memory, 32GB eMMC storage, Android 11 (upgradeable to Android 13), optional Linux Yocto and Ubuntu Server.
Mechanical: Dimensions 185 x 128 x 46 mm, weight 0.6 kg, panel and VESA mount, plastic housing, fanless design.
Environment: Operating humidity 10% to 90% RH, temperature range -20°C to 50°C, storage temperature -25°C to 70°C, IP65 front rating.
Certification: CE, FCC.
IO Ports: 1 x USB 2.0 Type A, 1 x Micro USB 2.0 OTG, 1 x RS485, 1 x LAN RJ45 connector, 1 x LED indicator for storage.
Power: 12V~24V with 3-Pin Terminal Block, optional 12V 36W adapter.
Control: 1 x Reset Button.

Notes
The document includes a simplified drawing, and specifications are subject to change without notice. For customized or optional I/O diagrams, contact the Winmate Sales Team.
