27” 4K UHD Chassis Defence Display M270TF-MIL

27” 4K UHD Chassis Defence Display M270TF-MIL

Product catalog summary

Key Features
The Winmate 27" 4K UHD Chassis Defence Display offers a native resolution of 3840 x 2160, providing exceptional clarity for video display and on-site applications. It features a thin, compact design with an impact-resistant screen, optional AR glass, and PCAP touch. The fanless and ventless design ensures easy cleaning and compatibility with existing imaging systems.

Introduction
The Winmate 4K UHD Chassis Defence Display Series is designed for demanding defense and industrial applications, available in 27” and 32” sizes. It offers detailed visuals with optional AR glass or PCAP touch for enhanced interactivity. The display's reliability and ease of maintenance make it ideal for video display, control rooms, and on-site operations.

Specifications
Display: 27.0 inches, 3840x2160 resolution, 1000:1 contrast ratio, 400 nits brightness (700 nits optional), 1.07 billion colors, 89-degree viewing angles.
Environment: Operating humidity 10% to 95% RH, operating temperature 0~50°C, storage temperature -10°C~60°C. Optional TEMPEST and NATO compliance.
Compliance: MIL-STD 461G and MIL-STD 810H standards, with optional NATO STANAG compliance.
Certification: CE, FCC.
IO Ports: Optional USB for touch screen, RS232 for remote control, VGA, DVI, Display Port 1.2, optional HDMI 2.0, optional audio line in.
Mechanical: Dimensions 643.2 x 408.1 x 48 mm, VESA mount, metal housing with aluminum bezel, fanless design.
Power: 24V DC input.

Notes
The document includes a simplified drawing, and some components are not marked in detail. Specifications are subject to change without notice. For customized or optional I/O diagrams, contact the Winmate Sales Team.

Catalog excerpts

27” 4K UHD Chassis Defence Display M270TF-MIL-1

M270TF-MIL27” 4K UHD Chassis Defence Display KEY FEATURES INTRODUCTION ■ 27" Display with UHD 4K (3840 x 2160) native resolution for video display and other on-site applications ■ Thin and compact design with impact resistant screen ■ AR glass, PCAP touch optional ■ Fanless and ventless design, easy-to-clean ■ Compatible with existing imaging systems Winmate 4K UHD Chassis Defence Display Series delivers exceptional clarity and durability for demanding defense and industrial applications. Available in 27” and 32” sizes, these displays feature native 4K UHD resolution for detailed visuals and optional AR glass or PCAP touch for enhanced interactivity. With a thin, impact-resistant design, fanless operation, and compatibility with existing imaging systems, they ensure reliability and ease of maintenance, making them ideal for video display, control rooms, and on-site operations. Display Touch / Glass AR Glass Resolution 3840x2160 Projected Capacitive Multi Touch Screen (Optional) Size 27.0 inches Contrast Ratio 1000:1 Panel Brightness 400 nits Display Color 1.07B Colors View Angles Active Area Environment Operating Humidity 10% to 95% RH Operating Temperature 0~50°C Storage Temperature -10°C~60°C TEMPEST USA: NSA NSTISSAM TEMPEST/1-92 (optional) NATO: NATO SDIP-27 (optional) Compliance USA: MIL-STD-810H (default): Vibration Method 514.6 Humidity Method 507.6 Transit Drop Method516.6 NATO (optional): Vibration Test STANAG 4370/AECTP-401 Shock STANAG 4370/AECTP-402 Procedure I Drop and Topple Test STANAG 4370/AECTP-404 IO Ports USB Port 1 x USB for Touch Screen (Optional) Serial Port 1 x RS232 for Remote Control (Optional) No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.250729.250820

Open the catalog to page 1

27” 4K UHD Chassis Defence Display M270TF-MIL-2

Video 1 x VGA Audio 1 x Audio Line In (Optional) Dimension 643.2 x 408.1 x 48 mm Mounting VESA mount Enclosure Metal Housing with Aluminum Bezel Cooling System Fanless Design Accessory User Manual(Hardcopy) Optional Accessory USB cable for Touch (Optional) VESA Mounting Screws (M4 x10 /M4 x 12) Power Convert Cable Dual Link DVI Cable 1.8M (Male to Male) COM Cable 1.8M (Male to Female) DIMENSIONS UNIT:MM NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. If you require an external test report, Winmate will charge an NRE fee. 3. Please contact our sales representative...

Open the catalog to page 2
