24" Intel® Core™ i5-7200U Defence Console Rack Panel PCs W24IK3S-RKS1ML

Product catalog summary

Key Features
The document describes a 24” high-resolution TFT LCD Defence Console Rack Panel PC featuring an Intel® Core™ i5-7200U 2.5 GHz processor. It is designed with anti-corrosion housing and is fanless, compliant with MIL-STD-810G/F and MIL-STD-461E/F standards. The device supports flush rack/rack mount mechanical design (9U) and includes convenient on-screen display controls. It operates on AC 110~240 V power input by default, with an optional isolation DC 9~36 V power input. A built-in light sensor allows for automatic brightness control, and it uses a defence-grade power connector (MIL-DTL-38999/1).

Introduction
The Winmate Defence Console Rack Panel PC Series is engineered for mission-critical applications in defense and industrial settings. Available in sizes from 15" to 32", these systems incorporate Intel® processors, fanless anti-corrosion housing, and projective touch screens. They are compliant with MIL-STD-810G/F and MIL-STD-461E/F/G standards, ensuring reliability in extreme conditions. The rack-mount (8U) design, on-screen display controls, and optional isolation DC power input make them suitable for command centers, control rooms, and rugged field deployments.

Specifications
Display: 24.0 inches, 1920x1200 resolution, 1000:1 contrast ratio, 300 nits brightness, 89-degree viewing angles, AR protection glass, optional resistive touch.
System: Intel Core i5-7300U 2.6GHz processor, up to 16GB DDR4 memory, up to 512GB SSD storage, dual Intel® Ethernet controllers, TPM 2.0 security, optional Windows 10 IoT Enterprise or Linux Ubuntu 20.04 OS, optional WLAN and BT support.
Environment: Operating humidity 10% to 95% RH, operating temperature 0~50°C, storage temperature -10°C~60°C.
Compliance: MIL-STD 461E/F/G, MIL-STD 810G/H, CE, FCC certifications.
Mechanical: Dimensions 609.5 x 399.3 x 76.2 mm, rack/panel/VESA mount, metal housing with aluminum bezel, fanless design.
IO Ports: 2 x USB 3.0, 1 x RS232/422/485, optional HDMI, 2 x RJ45 LAN.
Power: AC 100~240V, optional DC 9~36V.
Control: 8-key OSD control pad for power, brightness, and other settings.

Notes
The document includes a simplified drawing, and some components are not detailed. Specifications are subject to change without notice. For customized or optional I/O diagrams, contact the Winmate Sales Team.

Catalog excerpts

24" Intel® Core™ i5-7200U Defence Console Rack Panel PCs W24IK3S-RKS1ML-1

W24IK3SRKS1ML 24" Intel® Core™ i57200U Defence Console Rack Panel PCs 24” 1920 x 1200 High Resolution TFT LCD,Defence Console Rack Panel PCs Intel® Core™ i57200U 2.5 GHz Processor AntiCorrosion Housing / Fanless Compliant with MILSTD810G/F , MILSTD461E/F Flush Rack / Rack Mount Mechanical Design (9U) Convenient OnScreen Display Controls AC 110~240 V Power input default Isolation DC 9~36 V Power input (Optional) Builtin Light Sensor for auto brightness control Defence Grade Power Connector (MILDTL38999/1) Winmate Defence Console Rack Panel PC Series is a robust solution designed for missioncritical applications in defense and industrial environments. Available in sizes from 15" to 32", these systems feature Intel® processors, fanless anti corrosion housing, and projective touch screens for seamless operation. With MIL STD810G/F and MILSTD461E/F/G compliance, they ensure reliability in extreme conditions. The rackmount (8U) design, onscreen display controls, and optional isolation DC power input provide versatility, making them ideal for command centers, control rooms, and rugged field deployments. SPECIFICATIONS Display Resolution Contrast Ratio Panel Brightness View Angles Active Area Touch / Glass AR Protection Glass 5 Wires Resistive Touch (Optional) 5 Wire Resistive with EMI Mesh Filter (Optional) EMI Glass (Optional) System Specification Processor Ethernet controller 2 x Intel® Ethernet Controller Operating System Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 20.04 (Optional) Support (Optional) Support (Optional) Operating Humidity Operating Temperature Storage Temperature Vibration Method 514.6 Humidity Method 507.5 Transit Drop Method516.6 Compliance No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) RE101 / RE102 MILSTD 461E/F/G Tel: +886285110288 CE101 / CE102 Website: www.winmate.com CS118 with EMI Glass / Touch(Optional) RS10

Open the catalog to page 1

24" Intel® Core™ i5-7200U Defence Console Rack Panel PCs W24IK3S-RKS1ML-2

with EMI Glass / Touch(Optional) Dimension Enclosure Metal Housing with Aluminum Bezel Mounting Rack Mount / Panel Mount / VESA Mount Cooling System Fanless Design Video 1 x HDMI (Optional) Accessory User Manual (Hardcopy) CD-ROM with Driver Utility Power Cord MIL-DTL-38999/1 Serial Port Power Rating AC 100~240V, Universal, ±10% Power, Brightness DOWN, Brightness UP, Night, Day, Auto / Manual, Reset, Lock DIMENSIONS UNIT:MM NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All...

Open the catalog to page 2
