24" Intel® Core™ i5-1235U IP69K Stainless P Series Panel PC W24IAD3S-SPA269-P1

1 / 2 PagesView full catalog

24" Intel® Core™ i5-1235U IP69K Stainless P Series Panel PC W24IAD3S-SPA269-P1

Product catalog summary

Key Features:

12th Generation Intel® Core™ i5-1235U processor with speeds up to 4.40 GHz.
Fanless cooling system for silent operation.
Constructed with SUS316/AISI 316 stainless steel, ideal for food and chemical industries.
Full IP69K waterproof enclosure for high-pressure cleaning resistance.
True flat, edge-to-edge design for easy cleaning.
Waterproof sealed conduit pipe for cable protection.
Supports VESA mount and optional Yoke mount stand.
Glove/Rain mode and optional optical bonding for enhanced usability.

Introduction:

The Winmate IP69K Stainless P Series Panel PC is engineered for hygiene-critical environments, such as food and chemical industries. It combines durability and performance with a fanless cooling system and stainless steel housing, ensuring reliability in harsh conditions. The design facilitates easy cleaning and withstands high-pressure cleaning, with mounting options and usability features like Glove/Rain mode.

Specifications:

Display: 24-inch screen with 1920x1080 resolution, 3000:1 contrast ratio, and 250 nits brightness.
System: Intel® Core™ i5-1235U processor, 8GB memory (expandable), and SSD storage options up to 4TB.
Connectivity: 2x USB3.2 Gen1x1, 1x RS232/422/485, 1x HDMI 1.4, 2x Giga LAN RJ45.
Environment: Operating temperature from 0°C to 45°C, storage temperature from -20°C to 60°C, and IP69K rating.
Certification: CE, FCC certified.

Mechanical and Accessories:

Dimensions: 620 x 390 x 56 mm.
Includes waterproof conduits, power adapter, and various adapters and cables.
Optional accessories include a Yoke mount stand kit.

Notes:

Specifications are subject to change without notice.
Contact sales for further product information or customized options.

Catalog excerpts

24" Intel® Core™ i5-1235U IP69K Stainless P Series Panel PC W24IAD3S-SPA269-P1-1

W24IAD3S-SPA269-P124” Intel® Core™ i5-1235U IP69K Stainless P Series Panel PC INTRODUCTION Winmate IP69K Stainless P Series Panel PC is designed for extreme hygiene-critical environments such as food and chemical industries. Featuring 12th Gen Intel® Core™ processors, a fanless cooling system, and SUS316 stainless steel housing, this series ensures durability and performance under harsh conditions. Its full IP69K waterproof enclosure, sealed conduit pipe for cable protection, and edge-to-edge true flat design make it easy to clean and resistant to high-pressure cleaning. With VESA and optional yoke mounting, it supports Glove/Rain mode and optical bonding for enhanced usability and clarity. KEY FEATURES ■ 12th Generation Intel® Core™ i5-1235U 3.3GHz(up to 4.40 GHz) ■ Fanless cooling system ■ SUS316 / AISI 316 stainless steel for food and chemical industries ■ Full IP69K waterproof enclosure ■ A true flat, easy-to-clean front surface with edge-to-edge design ■ Waterproof sealed conduit pipe for cable protection ■ Support VESA mount, and optional Yoke mount stand ■ Support Glove/ Rain mode ■ Optical bonding (optional) Display Resolution 1920x1080 Size 24.0 inches Contrast Ratio 3000:1 Panel Brightness 250.0 nits View Angles 89,89,89,89 Active Area 527.04x296.46 mm Touch / Glass Projected Capacitive Multi Touch Screen System Specification Processor Intel® Core™ i5-1235U 3.3GHz(up to 4.40 GHz) Memory 8GB(Default) (Default) Storage 128GB SSD(Default) (Default) Ethernet controller 2 x Intel® Ethernet Controller 1 x SATA III for 2.5" SSD/HDD up to 2TB (Optional) Security TPM 2.0 Operating System Windows 11 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04(Do not support Wake on Touch) (Optional) MechanicalodiNMATC No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.260420.250811

Open the catalog to page 1

24" Intel® Core™ i5-1235U IP69K Stainless P Series Panel PC W24IAD3S-SPA269-P1-2

Dimension 620 x 390 x 56 mm Mounting VESA mount (Default) Yoke mount (Optional) Enclosure Stainless Housing Cooling System Fanless Design Operating Humidity 10% to 90% RH, Non-Condensing Operating Temperature 0°C to 45°C Storage Temperature -20°C to 60°C IP rating IP69K USB Port 2 x USB3.2 Gen1x1 (Type-A) Serial Port 1 x RS232/422/485 (Default RS232) Video 1 x HDMI 1.4 LAN 2 x Giga LAN RJ45 Connector Indicator 1 x LED Indicator on power button Button 1 x Power Button Accessory 1 x Waterproof Conduit 1.5m Optional Accessory 1 x Open wire cable for phoenix connector 1 x Waterproof Conduit 0.3m...

Open the catalog to page 2
