24" Intel® Core™ i5-1135G7 IP69K Stainless PCAP Chassis Panel PC W24IT3S-SPA269
1 /2Pages

Catalog excerpts

W24IT3S-SPA26924” Intel® Core™ i5-1135G7 IP69K Stainless PCAP Chassis Panel PC INTRODUCTION Winmate IP69K Stainless PCAP Chassis Panel PC Series offers robust solutions for demanding environments, featuring Intel® processors and sizes ranging from 10.4" to 24". Designed with SUS 316/AISI 316 stainless steel, these PCs are ideal for food, beverage, and chemical industries. The full IP69K waterproof enclosure, true-flat PCAP touch screen, and edge-to-edge design ensure durability, hygiene, and easy cleaning. Equipped with versatile I/Os, waterproof ports, and support for VESA/YOKE mounts, these panel PCs provide superior performance in wet, dusty, and extreme conditions, including Glove and Rain modes. KEY FEATURES ■ 24", 1920 x 1080 P-cap touch with flat design ■ 11th Generation Intel® Core™ i5-1135G7 2.4GHz (up to 4.2GHz) ■ SUS 316/ AISI 316 stainless steel for food and chemical industries ■ Full IP69K waterproof enclosure ■ A true flat, easy-to-clean front surface with edge-to-edge design ■ Waterproof ports with adapter cables for external connectivity ■ Support VESA/ YOKE mount ■ Support Glove/ Rain mode ■ Optical bonding (optional) Display Resolution 1920x1080 Size 24.0 inches Contrast Ratio 3000:1 Panel Brightness 250.0 nits View Angles 89,89,89,89 Active Area 527.04x296.46 mm Touch / Glass Projected Capacitive Multi Touch Screen System Specification WLAN Support (Optional) BT Support (Optional) Processor Intel Core i5-1135G7 2.4GHz (up to 4.2GHz) Memory 4GB(Default) (Default) Storage 128GB SSD(Default) (Default) Ethernet controller 2 x Intel® Ethernet Controller No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.260420.250811

Open the catalog to page 1

24" Intel® Core™ i5-1135G7 IP69K Stainless PCAP Chassis Panel PC W24IT3S-SPA269-2

1 x SATA III for 2.5" SSD/HDD up to 2TB (Optional) Security TPM 2.0 Operating System Windows 11 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04(Do not support Wake on Touch) (Optional) Enclosure Stainless Housing Mounting Cooling System VESA mount (Default) Yoke mount (Optional) Fanless Design Operating Temperature IP rating 1x M12 Waterproof Connector for 2 x USB2.0 Serial Port 1 x M12 waterproof connector for RS232 1 x Waterproof Giga LAN RJ45 Connector Indicator 1 x LED Indicator for power Button 1 x Power Button Accessory 100~240V AC to DC Adapter with waterproof connector Power Cord...
