24" Intel® Core™ i5-1135G7 Defence Console Rack Panel PC W24IT3S-MLA2FP

Product catalog summary

Key Features
The Winmate Defence Console Rack Panel PC features an Intel® Core™ i5-1135G7 processor with speeds up to 4.2GHz. It is designed with anti-corrosion housing and a fanless system, ensuring durability and quiet operation. The device includes a projective touch screen and complies with military standards MIL-STD-810G/F and MIL-STD-461E/F. It supports both AC and optional DC power inputs and includes a built-in light sensor for automatic brightness control.

Introduction
This series is engineered for mission-critical applications in defense and industrial settings, available in sizes from 15" to 32". It is suitable for command centers, control rooms, and rugged field deployments due to its robust design and compliance with military standards.

Specifications
Display: 24-inch screen with a resolution of 1920x1080, a contrast ratio of 3000:1, and brightness of 250 nits. It features a projected capacitive multi-touch screen.
System: The default processor is Intel Core i5-1135G7, with an optional upgrade to i5-1145G7. Memory options range from 4GB to 32GB, and storage from 128GB to 2TB. It includes TPM 2.0 for security and supports various operating systems including Windows 11 IoT Enterprise and Linux Ubuntu 22.04.
Environment: Operates in humidity levels from 10% to 95% RH and temperatures from 0 to 50°C. It meets various military standards for vibration, drop, and TEMPEST compliance.
Compliance: Certified with CE and FCC, and compliant with MIL-STD 461G and MIL-STD 810H standards.

IO Ports
Includes 2 USB 3.2 Gen 1 ports, 1 RS232 serial port, optional HDMI, and 2 RJ-45 LAN ports.

Mechanical
Dimensions are 635.2 x 430.9 x 66 mm, with VESA and optional rack mounting. The enclosure is made of metal with an aluminum bezel, and the cooling system is fanless.

Power
The device supports AC 100~240V power input by default, with an optional DC 9~36V input.

Control
Features a 6-key OSD control pad for power, brightness, and menu navigation.

Notes
Specifications are subject to change without notice, and for customized options, contact the Winmate sales team.

Catalog excerpts

24" Intel® Core™ i5-1135G7 Defence Console Rack Panel PC W24IT3S-MLA2FP-1

W24IT3SMLA2FP 24" Intel® Core™ i51135G7 Defence Console Rack Panel PC Intel® Core™ i51135G7 2.4 GHz (turbo to 4.2GHz) Processor AntiCorrosion Housing / Fanless Projective Touch Compliant with MILSTD810G/F , MILSTD461E/F Flush Rack / Rack Mount Mechanical Design (8U) Convenient OnScreen Display Controls AC 110~240 V Power input default Isolation DC 9~36 V Power input (Optional) Builtin Light Sensor for auto brightness control Winmate Defence Console Rack Panel PC Series is a robust solution designed for missioncritical applications in defense and industrial environments. Available in sizes from 15" to 32", these systems feature Intel® processors, fanless anti corrosion housing, and projective touch screens for seamless operation. With MIL STD810G/F and MILSTD461E/F/G compliance, they ensure reliability in extreme conditions. The rackmount (8U) design, onscreen display controls, and optional isolation DC power input provide versatility, making them ideal for command centers, control rooms, and rugged field deployments. SPECIFICATIONS Display Resolution Contrast Ratio Panel Brightness View Angles Active Area Touch / Glass Projected Capacitive Multi Touch Screen (Default) PCAP with With ITO Film (Optional) System Specification Processor Intel Core i51135G7 2.4GHz (up to 4.2GHz) (Default) Intel Core i51145G7 2.6GHz (up to 4.4GHz) (Optional) 4GB (Default) 8GB (Optional) 16GB (Optional) 32GB (Optional) Ethernet controller 2 x Intel® Ethernet Controller Operating System Windows 11 IoT Enterprise SAC (64 bit) (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04 (Optional) Operating Humidity Operating Temperature Storage Temperature NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP 401–Procedure I (optional) Drop NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP 404– Procedure II (Optional) No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Tel: +886285110288 Compliance Website: www.winmate.com USA: MILSTD461G: CE101, CE102, RE101, RE102, CS118 (default) MILSTD 461G CS101, CS114, CS115, CS116, RS101, RS103 (optional) USA: NSA NSTISSAM TEMPEST/192 (optional) NATO: NATO SDIP27 (optional)

Open the catalog to page 1

24" Intel® Core™ i5-1135G7 Defence Console Rack Panel PC W24IT3S-MLA2FP-2

Environment Operating Humidity Operating Temperature Storage Temperature USA: MILSTD810H Method 514.8 – Procedure I NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP 401–Procedure I (optional) USA: NSA NSTISSAM TEMPEST/192 (optional) NATO: NATO SDIP27 (optional) USA: MILSTD810H (default): Vibration Method 514.6 Humidity Method 507.6 Transit Drop Method516.6 NATO: STANAG 4370/AECTP400 Edition 3 Method AECTP 404– Procedure II (Optional) NATO (optional): Vibration Test STANAG 4370/AECTP401 Shock STANAG 4370/AECTP402 Procedure I Drop and Topple Test STANAG 4370/AECTP404 Certification Certification...
