17" PCAP Rack Mount Defence Display R17L100-MLA1FP

17" PCAP Rack Mount Defence Display R17L100-MLA1FP

Product catalog summary

Key Features
The document outlines the features of a 17-inch PCAP Rack Mount Defence Display with a resolution of 1280 x 1024. It is compliant with MIL-STD 810G and MIL-STD 461E standards, ensuring durability in harsh environments. The display supports VESA mount and includes a PCAP multi-touch screen. It features a defence-grade power connector (MIL-DTL-38999/1) and offers universal AC/DC power options.

Introduction
The Winmate PCAP Rack Mount Defence Display Series is designed for mission-critical applications, offering robust performance and reliability. Available in sizes from 15" to 32", these displays are ideal for military and industrial use, providing resolutions up to 1920x1080 and convenient on-screen display controls.

Specifications

Display: 17-inch size, 1280x1024 resolution, 1000:1 contrast ratio, 350 nits brightness, 16.7M colors, and wide viewing angles.
Environment: Operating humidity of 10% to 95% RH, operating temperature from -20°C to 60°C, and storage temperature from -30°C to 70°C. Optional TEMPEST and NATO compliance.
Compliance: Meets MIL-STD 461G and MIL-STD 810H standards, with optional NATO STANAG compliance.
Certification: CE and FCC certified.
IO Ports: Includes USB for touch screen, VGA, 5 BNC, and DVI-D ports.
Mechanical: Dimensions are 482.6 x 399.3 x 79.6 mm, with VESA and optional rack mount. Features a metal housing with aluminum bezel and fanless design.
Power: AC 100~240V, Universal, ±10%; DC 9~36V, ±10% (Optional).
Control: Includes power, brightness, menu, day/night mode, LED indicator, and ambient light sensor buttons.

Note
The product described is a standard model. For customized or optional I/O configurations, contact the Winmate Sales Team.

Catalog excerpts

17" PCAP Rack Mount Defence Display R17L100-MLA1FP-1

R17L100MLA1FP 17" PCAP Rack Mount Defence Display 17", 1280 x 1024 resolution Compliant MILSTD 810G/ MILSTD 461E Rack mount mechanical design, supports VESA mount PCAP multitouch screen Defencegrade power connector (MILDTL38999/1) AC 100~240V, Universal, ±10%; DC 9~36V, ±10% (Optional) Convenient onscreen display controls Winmate PCAP Rack Mount Defence Display Series delivers robust performance and reliability for missioncritical applications. Available in sizes from 15" to 32", these displays feature PCAP multitouch screens, compliant with MILSTD 810G and MILSTD 461E for durability in harsh environments. The rack mount design with VESA compatibility ensures seamless integration, while the defencegrade power connector (MILDTL38999/1) enhances safety. Ideal for military and industrial use, the series offers resolutions up to 1920x1080, universal AC/DC power options, and convenient onscreen display controls. SPECIFICATIONS Display Resolution Contrast Ratio Panel Brightness Display Color View Angles Active Area Touch / Glass Projected Capacitive Multi Touch Screen PCAP with With ITO Film (Optional) Operating Humidity Operating Temperature Storage Temperature USA: NSA NSTISSAM TEMPEST/192 (optional) NATO: NATO SDIP27 (optional) USA: MILSTD810H (default): Vibration Method 514.6 Humidity Method 507.6 Transit Drop Method516.6 NATO (optional): Vibration Test STANAG 4370/AECTP401 Shock STANAG 4370/AECTP402 Procedure I Drop and Topple Test STANAG 4370/AECTP404 Certification Certification VESA mount Rack mount (Optional) Cooling System Fanless Design Mechanical No. 18, Zhongxing S. St., Sanchong Dist., New Taipei 482.6 x 399.3 x 79.6City mm241017 , Taiwan (R.O.C.) Dimension Tel: +886285110288 Website: www.winmate.com Metal Housing with Aluminum Bezel En

Open the catalog to page 1

17" PCAP Rack Mount Defence Display R17L100-MLA1FP-2

Dimension 482.6 x 399.3 x 79.6 mm Mounting VESA mount Rack mount (Optional) Enclosure Metal Housing with Aluminum Bezel Cooling System Fanless Design Accessory 1 x User Manual(Hardcopy) 1 x Power Cord MIL-DTL-38999/1 1 x VGA Cable 1 x DVI Cable Power Rating AC 100~240V, Universal, ±10% Button 1 x "Power" key to power on the device. 1 x "+" key to increase screen brightness. 1 x "-" key to decrease screen brightness. 1 x "Menu" key can Automatically or manually adjusts brightness of the display screen 1 x Day / Night Mode button 1 x LED indicator brightness adjustment button 1 x Ambient Light...

Open the catalog to page 2
