17" Intel® Pentium® N4200 Chassis Panel PC R17IP7T-CHM1

Product catalog summary

Key Features:
- Intel® Pentium® N4200 Apollo Lake Processor at 1.10 GHz.
- Flexible storage options with one 2.5-inch HDD and one SSD socket.
- Multiple I/O ports including 2 Serial Ports and 4 USB 3.0 Ports.
- 12 V DC Power input.
- DisplayPort support for 4096 x 2160 @ 60 Hz and HDMI support for 3840 x 2160 @ 30 Hz.

Introduction:
The Winmate Chassis Panel PC Series is designed for industrial applications, offering robust and versatile solutions in sizes from 7" to 24". These PCs are built for reliability with a wide range of operating systems, advanced display interfaces, and front IP65 protection. They are suitable for control rooms, kiosks, and factory automation, featuring a rugged design and a wide operating temperature range for durability in challenging environments.

Specifications:
Display:
- Resolution: 1280x1024
- Size: 17.0 inches
- Contrast Ratio: 1000:1
- Panel Brightness: 350.0 nits
- View Angles: 85,85,80,80
- Active Area: 337.920x270.336 mm
- Optional Resistive Touch Screen or Protection Glass without Touch Function.
System Specification:
- Processor: Intel Pentium N4200 1.1GHz (up to 2.5GHz)
- Memory: Dual-channel (non-ECC) SO-DIMM RAM, up to 16GB
- Storage: 128GB SSD (Default), options for 256GB, 512GB, 1TB, and 2 x SATA III for 2.5" SSD/HDD (Optional)
- Ethernet: 2 x Intel® Ethernet Controller
- Security: TPM 2.0
- Operating System: Windows 10 IoT Enterprise (64 bit) or Linux Ubuntu 20.04 (Optional)
- Optional WLAN and BT Support.
Mechanical:
- Dimensions: 394 x 332 x 74 mm
- Weight: 6.3 kg
- Mounting: VESA mount
- Enclosure: Metal Housing
- Cooling System: Fanless Design.
Environment:
- Operating Humidity: 10% to 90% RH, Non-Condensing
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -10°C to 60°C.
Certification:
- CE, FCC.
IO Ports:
- Power Input: 1 x 12V DC, Din4 pin connector
- USB Port: 4 x USB3.2 Gen1x1 (Type-A)
- Serial Port: 1 x RS232/422/485 (Default RS232), 1 x RS232
- Video: 1 x DP1.2 (Default), 1 x HDMI 1.4 (Optional), 1 x VGA (Optional)
- Audio: 1 x Mic in, 1 x Line out, 2 x Speaker
- Expansion Port: 1 x M.2 2242 B-key Slot (for SATA III SSD), 1 x M.2 2230 E-Key Slot (for Wi-Fi module), 1 x PCIe 2.0 (x1) slot
- LAN: 2 x Giga LAN RJ45 Connector
- Indicator: 1 x LED Indicator for power, 1 x LED Indicator for storage
- Brightness Knob: 1 x Brightness Adjustment Knob.
Control:
- Button: 1 x Power Button, 1 x Reset Button.
Accessory:
- 100~240V AC to DC Adapter, Power Cord, VESA screws.
Power:
- Power Rating: 12V DC Adapter 12V 84W.

Notes:
- This is a simplified drawing and some components are not marked in detail.
- The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information.
- All specifications are subject to change without prior notice.
