15.6" Multi-Touch Color Healthcare Display W15L100-PTA3-ME

Product catalog summary

Key Features

15.6" 1920 x 1080 Multi-Touch Color Healthcare Display
Projected Capacitive Multi-touch technology
VGA and HDMI input options
Stylish design with antimicrobial housing
Front IP65 protection for enhanced durability

Introduction

The Winmate Multi-Touch Color Surgical Display Series is designed for medical applications, offering sizes from 15.6" to 32" with resolutions up to 3840 x 2160. These displays feature Projected Capacitive Multi-Touch (PCAP) technology and antimicrobial housing, ensuring precision and hygiene in surgical settings. They are equipped with front IP65 protection, fanless and ventless designs, and versatile connectivity options, making them suitable for operating rooms, diagnostics, and clinical environments.

Specifications

Display: 1920x1080 resolution, 15.6 inches, 800:1 contrast ratio, 400 nits brightness, 262K colors, 85-degree viewing angles, Projected Capacitive Multi-Touch Screen (AG)
Environment: Operating humidity 10% to 90% RH, non-condensing; Operating temperature 0°C to 40°C; Storage temperature -20°C to 60°C
Certification: IEC/EN 60601-1, IEC 60601-1-2:2014/AMD:2020, IEC60601-1-6 + IEC62366, EN 60601-1-2:2015/A1:2021, EN55032/35, FCC Part15B, ICE-003, ISO14971, RoHS-2, REACH, WEEE compliant
IO Ports: 1 x USB for Touch Screen, 1 x USB Type-C (Optional), 1 x VGA, 1 x HDMI (Optional), 1 x Audio Line In, 2 x Speaker (Optional)
Mechanical: Dimensions 388 x 233 x 40 mm, Weight 1.6 kg, VESA mount, Plastic enclosure, Fanless design
Accessory: Includes VGA cable, HDMI cable, AC to DC Adapter, Power Cord, Manual, VESA screws
Power: 12V DC in, USB Type-C Alt mode (Optional)
Control: 7 Keys: Enter, Exit, Right, Left, Up, Down, Power

Notes

This is a simplified drawing; some components are not marked in detail.
Contact sales for further product information.
Specifications are subject to change without notice.
For customized or optional I/O diagrams, contact the Winmate Sales Team.

Catalog excerpts

15.6" Multi-Touch Color Healthcare Display W15L100-PTA3-ME-1

W15L100PTA3ME 15.6" MultiTouch Color Healthcare Display 15.6" 1920 x 1080 MultiTouch Color Healthcare Display Projected Capacitive Multitouch VGA input and HDMI input Stylish and elegant design Housing with antimicrobial properties Front IP65 MultiTouch Color Healthcare Display Winmate MultiTouch Color Surgical Display Series offers advanced display solutions tailored for medical applications, available in sizes ranging from 15.6" to 32". With native resolutions up to 3840 x 2160, Projected Capacitive MultiTouch (PCAP) technology, and antimicrobial housing, these displays ensure precision and hygiene in surgical settings. Featuring front IP65 protection, fanless and ventless designs, and versatile connectivity options including VGA, HDMI, and DP, this series is ideal for operating rooms, diagnostics, and clinical environments requiring reliability and clarity. SPECIFICATIONS Display Resolution Contrast Ratio Panel Brightness Display Color View Angles Active Area Touch / Glass Projected Capacitive Multi Touch Screen (AG) Operating Humidity Operating Temperature Storage Temperature Certification Certification 1 x USB for Touch Screen 1 x USB TypeC (Alt mode 5V/3A) (Optional) 1 x Audio Line In 2 x Speaker (Optional) Mechanical Dimension VESA mount Cooling System Fanless Design No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Tel: +886285110288 1 x VGA cable Accessory Website: www.winmate.com 1 x HDMI cable 100~240V AC to DC Adapter Power Cord

Open the catalog to page 1

15.6" Multi-Touch Color Healthcare Display W15L100-PTA3-ME-2

Mounting VESA mount Enclosure Plastic Cooling System Fanless Design 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product) USB Type-C Alt mode (5V/3A) (Optional) Button 7 Keys: Enter, Exit, Right, Left, Up, Down, Power NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O,...

Open the catalog to page 2
