14.9” Intel® Pentium® N6415 Marine Dashboard Panel PC W15IE3S-MRB1FP
1 /2Pages
14.9” Intel® Pentium® N6415 Marine Dashboard Panel PC W15IE3S-MRB1FP
1 /2Pages
Catalog excerpts
W15IE3S-MRB1FP 14.9” Intel® Pentium® N6415 Marine Dashboard Panel PC INTRODUCTION C€F© ■ Intel® Elkhart Lake Pentium® N6415 processor dashboard panel PC ■ 14.9” 1920 x 720 wide viewing angle with PCAP touch ■ 9~36V DC Power input acceptable Winmate Marine Dashboard Panel PC Series combines durability and performance for maritime applications, offering sizes from 10.1" to 14.9". Featuring Intel® Elkhart Lake Pentium® processors, wide viewing angle displays, and PCAP touch technology, these panel PCs ensure precise operation and optimal visibility. With a robust 9~36V DC power input, they are built to withstand harsh marine environments. Ideal for navigation and control systems, this series delivers reliability and efficiency for demanding marine operations. Display Type Projected Capacitive Multi Touch Panel Brightness 950.0 nits System Specification Processor Storage Security Environment Operating Humidity 5% to 95% IO Ports USB Port Video Mechanical Resolution Contrast Ratio View Angles Ethernet controller 2 x 2.5 Giga LAN RJ45 Connector Operating System Windows 11 IoT Enterprise LTSC (64 bit) (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) IP rating IP66 (Front Side) 2 x USB3.2 Gen1x1 (Type-A) 1 x HDMI 2.0 (Optional) No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Website: www.winmate.com
Open the catalog to page 1
Mounting Cooling System 400.1 x 187.6 x 59 mm VESA mount/Panel mount Fanless Design Enclosure Metal Driver CD & User Manual AC to DC Adapter 12V/ 50W Power Cord 3 pin Terminal Block to DC Jack VJINMATE Power 9V~36V DC In Terminal Block Power Rating NOTE 1 .This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is a standard model.For diagrams that contain customized or optional I/ O, please...
