12.1" Panel Mount High Brightness Display R12T600-PML1HB

Product catalog summary

Key Features
- 12.1" Panel Mount High Brightness Display with 800 x 600 resolution.
- Supports VGA and HDMI input.
- Offers both panel and VESA mounting options.
- High brightness for visibility in bright environments.

Introduction
The Winmate Panel Mount Display Series is designed for industrial and commercial applications, offering durability and versatility. Available in sizes from 5.7" to 32", these displays provide high brightness up to 1300 nits, ensuring excellent visibility. They support VGA and HDMI interfaces and offer panel and VESA mount options for easy integration. Customizable for specific needs, they are ideal for factory automation, kiosks, and control rooms.

Specifications
Display
- Resolution: 800x600
- Size: 12.1 inches
- Contrast Ratio: 700:1
- Brightness: 1000 nits
- Display Color: 16.2M Colors
- View Angles: 80,80,75,65
- Active Area: 246x184.5 mm
- Touch Options: Resistive Touch Screen, Protection Glass (optional), SAW Touch (optional)

Environment
- Operating Humidity: 10% to 90% RH, Non-Condensing
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -10°C to 60°C

Certification
- CE, FCC

IO Ports
- USB: 1 x USB for Touch Screen
- Video: 1 x VGA, 1 x HDMI (optional), 1 x DVI (optional)
- Audio: Audio line in (3.5mm) (optional), 2 x Speaker (optional)

Mechanical
- Dimension: 324 x 274 x 43 mm
- Weight: 2.3 kg
- Mounting: VESA mount, Panel mount (optional)
- Enclosure: Metal Housing with Aluminum Bezel
- Cooling System: Fanless Design
- Cut out: 303 x 222 mm

Accessory
- Includes VGA cable, HDMI cable, AC to DC Adapter, Power Cord, Manual, VESA screws
- Optional Remote Controller

Power
- Power Rating: 12V DC in, 24V DC in (optional)

Control
- 5 Keys: -, +, Power, Esc, Enter

Notes
- Simplified drawing; some components not detailed.
- Contact sales for further product information.
- Specifications subject to change without notice.
- Standard model shown; contact for customized options.

For more information, visit the Winmate website or contact their sales team.

Catalog excerpts

12.1" Panel Mount High Brightness Display R12T600-PML1HB-1

R12T600-PML1HB 12.1" Panel Mount High Brightness Display C€F© KEY FEATURES INTRODUCTION ■ 12.1", 800 x 600 Panel Mount High Brightness Display Winmate Panel Mount Display Series combines durability and versatility for industrial and commercial applications. Available in sizes from 5.7" to 32", these wide displays feature high brightness up to 1300 nits for excellent visibility, even in bright environments. With VGA and HDMI interfaces, panel mount, and VESA mount options, they ensure seamless integration with various systems. Customizable to meet specific requirements, this display series is ideal for factory automation, kiosks, and control rooms, offering reliable performance and adaptability. Display Resolution Contrast Ratio Display Color Active Area Panel Brightness View Angles Touch / Glass 12.1 inches 1000.0 nits 80,80,75,65 Resistive Touch Screen Protection Glass w/o Touch Function (Optional) SAW Touch (Surface Acoustic Wave) (Optional) Environment Operating Humidity 10% to 90% RH, Non-Condensing Operating Temperature 0°C to 50°C IO Ports USB Port 1 x USB for Touch Screen Video 1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional) Audio Audio line in (3.5mm) (Optional) Enclosure Metal Housing with Aluminum Bezel Mounting VESA mount Panel mount (Optional) No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.240625.250616

Open the catalog to page 1

12.1" Panel Mount High Brightness Display R12T600-PML1HB-2

Cooling System Fanless Design Cut out 303 x 222 mm Accessory 1 x VGA cable Optional Accessory Remote Controller (Optional,Varies by product) 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product) Button 5 Keys: - , + , Power , Esc , Enter odd O VGA © HDMI © Power Input © OSD Control Panel NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is...
