10.4" Rear Mount Wide Temperature Industrial LCD Monitor R10L100-RMA1WT

Product catalog summary

Key Features
- 10.4-inch, 800 x 600 resolution industrial LCD monitor
- VGA and HDMI input
- Rear and VESA mount compatibility
- Wide operating temperature range of -20 to 60°C

Introduction
The Winmate Rear Mount Display Series provides durable and versatile display solutions for industrial applications. These displays are available in sizes ranging from 6" to 19" and offer sunlight-readable high-brightness options. They support a wide operating temperature range and flexible mounting options, including rear and VESA mounts. The displays feature VGA and HDMI inputs, with optional resistive touch or cover glass, ensuring intuitive operation and seamless integration into various industrial environments.

Specifications
Display:
- Resolution: 800x600
- Size: 10.4 inches
- Contrast Ratio: 700:1
- Panel Brightness: 400 nits
- Display Color: 16.2M Colors
- View Angles: 80,80,70,60
- Active Area: 211.2x158.4 mm
- Touch/Glass: Resistive Touch Screen, Protection Glass without Touch Function (Optional), SAW Touch (Optional)
Environment:
- Operating Humidity: 30% to 90% (non-condensing)
- Operating Temperature: -20 to 60°C
- Storage Temperature: -25 to 65°C
Certification: CE, FCC
IO Ports:
- USB Port: 1 x USB for Touch Screen
- Video: 1 x VGA, 1 x HDMI (Optional), 1 x DVI (Optional)
- Audio: Audio line in (3.5mm) (Optional), 2 x Speaker (Optional)
Mechanical:
- Dimension: 300 x 220 x 50 mm
- Mounting: VESA Mount/Panel Mount
- Enclosure: Metal
- Cooling System: Fanless Design
Accessory:
- 1 x VGA cable
- 1 x HDMI cable
- 100~240V AC to DC Adapter
- Power Cord
- Manual
- VESA screws (Varies by product)
- Optional Accessory: Remote Controller (Optional, Varies by product)
Power: 12V DC input
Control: 5 Keys: -, +, Power, Esc, Enter

Notes
1. This is a simplified drawing and some components are not marked in detail.
2. Please contact our sales representative for further product information.
3. All specifications are subject to change without prior notice.
4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information.

Catalog excerpts

10.4" Rear Mount Wide Temperature Industrial LCD Monitor R10L100-RMA1WT-1

R10L100-RMA1WT 10.4" Rear Mount Wide Temperature Industrial LCD Monitor Winmate Rear Mount Display Series offers durable and versatile display solutions for industrial applications. Available in sizes from 6" to 19", these rectangular displays feature sunlight-readable high-brightness options, wide operating temperature ranges (-20~60°C), and flexible mounting with rear and VESA mount compatibility. With VGA and HDMI inputs and optional resistive touch or cover glass, these displays ensure intuitive operation and seamless integration into control systems, kiosks, and other industrial environments. Display Resolution Contrast Ratio Display Color Active Area Panel Brightness View Angles Touch / Glass 10.4 inches 400 nits 80,80,70,60 Resistive Touch Screen Protection Glass w/o Touch Function (Optional) SAW Touch (Surface Acoustic Wave) (Optional) Environment Operating Humidity 30% to 90% (non-condensing) Operating Temperature -20~60°C IO Ports USB Port 1 x USB for Touch Screen Video 1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional) Audio Audio line in (3.5mm) (Optional) Mechanical 300 x 220 x 50 mm Mounting VESA Mount/ Panel Mount Metal Cooling System Fanless Design Dimension Enclosure Accessory 1 x VGA cable Optional Accessory Remote Controller (Optional,Varies by product) No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.211026.250617

Open the catalog to page 1

10.4" Rear Mount Wide Temperature Industrial LCD Monitor R10L100-RMA1WT-2

1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product) Power Rating 12V DC input Button 5 Keys: - , + , Power , Esc , Enter DIMENSIONS UNIT:MM NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information. O VGA 0 HDMI 0...

Open the catalog to page 2
