10.4" Intel® Core™ i5-1235U Open Frame Panel PC R10IAD3S-OFT2

Product catalog summary

Key Features
The document describes a 10.4” Open Frame PC with a resolution of 1024 x 768, powered by a 12th Gen Intel® Core™ i5-1235U processor. It supports up to 32GB of DDR5 memory and features integrated dual 2.5 Gigabit Ethernet, multiple I/Os including 2 x USB 3.2 Gen2x1, and 2 x Serial Ports. The device operates on a 12 V DC power input.

Introduction
The Winmate Open Frame Panel PC Series is designed for industrial applications, offering sizes from 5.7" to 24". These PCs support multiple operating systems and advanced processors, featuring resistive and PCAP touch options for precise operation. The open-frame design facilitates easy installation in cabinets or kiosks, suitable for factory automation, retail, and digital signage.

Specifications

Display: 10.4 inches, 1024x768 resolution, 1000:1 contrast ratio, 500 nits brightness, 88-degree viewing angles.
System: Intel® Core™ i5-1235U processor, up to 32GB memory, storage options from 128GB to 4TB SSD, dual Intel® Ethernet controllers, TPM 2.0 security, and optional operating systems including Windows 11 and Linux Ubuntu.
Mechanical: Dimensions are 260 x 215 x 51 mm, weighing 1.9 kg, with mounting options including open frame, panel mount, and VESA mount. The enclosure is metal with a fanless cooling system.
Environment: Operating humidity is 10% to 90% RH, non-condensing, with an operating temperature range of 0°C to 50°C and storage temperature from -10°C to 60°C.
Certification: CE, FCC certified.
IO Ports: Includes 1 x 12V DC power input, 2 x USB3.2 Gen2x1, 2 x serial ports, optional HDMI 2.0, 2 x speakers, and expansion ports for NVME SSD and Wi-Fi module.
Control: Features a power button, reset button, and brightness adjustment knob.
Power: Rated at 12V DC with a 120W adapter.

Notes
The document notes that the drawing is simplified and some components are not detailed. Specifications are subject to change without notice, and for customized or optional I/O diagrams, contact the Winmate Sales Team.

Catalog excerpts

10.4" Intel® Core™ i5-1235U Open Frame Panel PC R10IAD3S-OFT2-1

R10IAD3S-OFT2 10.4” Intel® Core™ i5-1235U Open Frame Panel PC INTRODUCTION C€F© ■ 10.4” 1024 x 768 Resolution Open Frame PC ■ 12th Gen Intel® Core™ i5-1235U processor ■ Integrated Dual 2.5 Gigabit Ethernet ■ Multiple I/Os, 2 x USB 3.2 Gen2x1,2 x Serial Ports Winmate Open Frame Panel PC Series delivers versatility and performance for diverse industrial applications. Available in sizes from 5.7" to 24", these wide, rectangular panel PCs support multiple operating systems and advanced processors for seamless integration. Featuring resistive and PCAP touch options, they offer precise and intuitive operation. The open-frame design ensures easy installation into cabinets or kiosks, making them ideal for factory automation, retail, and interactive digital signage. Resolution Contrast Ratio View Angles Touch / Glass Resistive Touch Screen (Optional) Protection Glass Without Touch Function (Optional) Panel Brightness 500.0 nits Ethernet controller System Specification WLAN Support (Optional) Processor Intel® Core™ i5-1235U 3.3GHz(up to 4.40 GHz) Storage 128GB SSD(Default) (Default) 1 x SATA III for 2.5" SSD/HDD up to 2TB (Optional) Security TPM 2.0 Support (Optional) 2 x Intel® Ethernet Controller Operating System Windows 11 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04(Do not support Wake on Touch) (Optional) Enclosure Metal Housing Mounting Open frame (Default) Panel mount (Optional) VESA mount (Optional) Cooling System Fanless Design No. 18, Zhongxing S. St., Sanchong Dpt. ,New Taipei City 241017 , Taiwan (R.O.C.) Tel: +886-2-8511-0288 Website: www.winmate.com

Open the catalog to page 1

10.4" Intel® Core™ i5-1235U Open Frame Panel PC R10IAD3S-OFT2-2

Operating Humidity Storage Temperature VJINMATE IO Ports Power Input Serial Port M.2 2280 M-Key Slot (for NVME SSD) M.2 2230 E-KeySlot (for Wi-Fi Module) LED Indicator for power LED Indicator for storage Brightness Knob 1 x Brightness Adjustment Knob Button 1 x Power Button Power Cord VESA screws DIMENSIONS UNIT:MM NOTE _260_ 1 .This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is a...
