10.1” Intel® Core™ i5-1235U Rugged Robotic Controller G101AD-A

Product catalog summary

Key Features
The document describes a 10.1” 1920 x 1200 IPS LED Panel with direct optical bonding, powered by an Intel® Core™ i5-1235U processor. It is designed to be all-weather, dust, and water-resistant (IP65), with MIL-grade drop, shock, and vibration protection. It supports WIFI, Bluetooth, and optional 4G/5G connectivity, and includes a removable battery.

Introduction
Winmate's Rugged Handheld Robotic Controller Series is designed for robotics, defense, public safety, and industrial automation. Available in sizes from 5.5" to 10.1", these controllers support Windows, Android, and Linux, offering flexibility for various applications. They feature IP65-rated water and dust resistance, MIL-grade shock and vibration protection, PCAP touchscreens, Intel or ARM processors, Wi-Fi, Bluetooth, and optional 4G connectivity.

Specifications

Display: 10.1 inches, 1920x1200 resolution, 800:1 contrast ratio, 800 nits brightness, optical bonding for sunlight viewability, projected capacitive multi-touch with AG+AF touch treatment.
System: Intel® Core™ i5-1235U processor (3.3GHz up to 4.40 GHz), 8GB RAM (up to 32GB), 128GB storage (up to 2TB SSD), TPM 2.0 security, supports Windows 10/11 IoT Enterprise LTSC and Linux Ubuntu 22.04.
Connectivity: WLAN, Bluetooth, optional 4G LTE and 5G, GPS/GLONASS.
Mechanical: Dimensions 317.75 x 188.87 x 35.8 mm, weight 1.6kg, fan cooling system.
IO Ports: USB 3.0 (Type-A and Type-C), optional micro HDMI output, 2x speakers, M10 LAN connector (mutually exclusive with Microhard RF Module).
Environment: Operating humidity 10% to 90% RH, operating temperature -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode), storage temperature -30°C to 70°C, MIL-STD-810H shock and vibration, IP65 rating.
Certification: CE, FCC.
Control: Left and right side controls include toggle switches, joysticks, roller switches, and buttons.
Power: 10.9 V, 6700 mAh Li-Ion removable battery, 10.5 hours operating time, 19V DC power rating.
Accessories: Includes a 120W adapter, M10 push-pull power cable, LAN, and power cord. Optional Microhard pMDDL2450 (mutually exclusive with LAN).

Notes
The document includes a simplified drawing, and some components are not marked in detail. Specifications are subject to change without notice. For more information, contact the Winmate Sales Team.

Catalog excerpts

10.1” Intel® Core™ i5-1235U Rugged Robotic Controller G101AD-A-1

G101ADA 10.1” Intel® Core™ i51235U Rugged Robotic Controller 10.1” 1920 x 1200 IPS LED Panel with direct optical bonding Intel® Core™ i51235U processor Allweather, dust, and waterresistant design (IP65). MIL grade drop, Shock and vibration Supports WIFI, BT and optional 4G/5G With one removable battery Winmate's Rugged Handheld Robotic Controller Series is a versatile and durable solution tailored for robotics, defense, public safety, and industrial automation. Available in sizes from 5.5" to 10.1", these controllers support Windows, Android, and Linux, providing flexibility for various applications. Featuring IP65rated water and dust resistance, along with MILgrade shock and vibration protection, they are built for allweather reliability. With PCAP touchscreens, Intel or ARM processors, WiFi, BT, and optional 4G connectivity, these robotic controllers deliver robust performance in demanding environments. SPECIFICATIONS Display Resolution Contrast Ratio Panel Brightness View Angles Optical Bonding for Sunlight Viewability Projected Capacitive Multi Touch AG+AF touch treatment Trusted Platform Module (TPM) 2.0 Operating System Windows 10 IoT Enterprise LTSC (64 bit) Windows 11 IoT Enterprise LTSC (64 bit) (Optional) Linux Ubuntu 22.04 (Optional) System Specification Mechanical Dimension Cooling System 1 x micro HDMI output(Optional) 1 x M10 LAN Connector (Mutually exclusive with Microhard RF Module) Operating Humidity Operating Temperature 20°C to 60°C (AC mode), 10°C to 50°C (Battery mode) Storage Temperature MILSTD810H Method 514.8 Procedure I Vibration No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Tel: +886285110288 Certification Website: www.winmate.com CE, FCC

Open the catalog to page 1

10.1” Intel® Core™ i5-1235U Rugged Robotic Controller G101AD-A-2

Operating Temperature -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode) Shock MIL-STD-810H Method 516.8 Procedure I Operating Humidity 10% to 90% RH, non-condensing Vibration MIL-STD-810H Method 514.8 Procedure I Button Left Side: 1 x Two Band Toggle Switch 1 x Joystick 1 x Roller switch 4 x Buttons Right Side: 1 x Two Band Toggle Switch 1 x Joystick 1 x Roller switch Battery Operating Time Standard Battery : 10.5hrs Battery 10.9 V, typ. 6700 mAh Lilon Removable Battery (3S2P) Accessory 1 x Adapter 120W Optional Accessory Microhard pMDDL2450 (Mutually exclusive with LAN) 1 x M10 Push-pull...
