Winmate, Inc.
10.1" Chassis Display W10L100-CHA1

10.1" Chassis Display W10L100-CHA1

Product catalog summary

Key Features
The Winmate 10.1" Chassis Display features a resolution of 1920 x 1200, VGA and HDMI inputs, and a VESA mount for easy installation. It is designed for industrial and commercial applications, offering durability and versatility.

Introduction
The Winmate Chassis Display Series provides robust display solutions suitable for control rooms, kiosks, and manufacturing environments. Available in sizes from 6" to 32", these displays support VGA and HDMI inputs and offer optional high brightness up to 1500 nits for enhanced visibility.

Specifications

Display: 10.1 inches, 1920x1200 resolution, 800:1 contrast ratio, 800 nits brightness, 16.7M colors, 85-degree viewing angles.
Touch/Glass Options: Resistive Touch Screen, Protection Glass without Touch, SAW Touch (optional).
Environment: Operating humidity 10% to 90% RH, temperature range 0°C to 50°C, storage temperature -10°C to 60°C.
Certification: CE, FCC.
IO Ports: 1 x USB for touch screen (optional), 1 x VGA, 1 x HDMI (optional), audio line in (3.5mm) (optional), 2 x speakers (optional).
Mechanical: Dimensions 250.5 x 168.4 x 39 mm, weight 1.4 kg, metal enclosure, fanless design.
Power: 12V DC in, 24V DC in (optional).
Control: 5 keys: -, +, Power, Esc, Enter.

Accessories
Includes VGA cable, HDMI cable, AC to DC adapter, power cord, manual, and VESA screws. Optional remote controller available.

Notes
The document includes a simplified drawing, and specifications are subject to change without notice. For customized options, contact the Winmate Sales Team.

Catalog excerpts

Winmate Chassis Display Series offers durable and versatile display solutions for industrial and commercial applications. Available in sizes from 6" to 32", these wide, rectangular displays feature VGA and HDMI inputs, VESA mounting options, and optional high brightness up to 1500 nits for enhanced visibility. Designed for easy installation, they are ideal for control rooms, kiosks, and manufacturing environments, delivering reliable performance and seamless integration into various systems. Display Touch / Glass Resistive Touch Screen Protection Glass w/o Touch Function (Optional) SAW Touch (Surface Acoustic Wave) (Optional) Panel Brightness 800.0 nits Contrast Ratio Display Color Active Area Environment Operating Humidity 10% to 90% RH, Non-Condensing Operating Temperature 0°C to 50°C Enclosure Metal USB Port 1 x USB for Touch Screen (Optional) Audio Audio line in (3.5mm) (Optional) Mounting VESA mount Cooling System Fanless Design AccessoryU/iNMATE No. 18, Zhongxing S. St., Sanchong Dist., New Taipei City 241017 , Taiwan (R.O.C.) Revised:V.250917.250611

Open the catalog to page 1

Accessory 1 x VGA cable Optional Accessory Remote Controller (Optional,Varies by product) 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product) Button 5 Keys: - , + , Power , Esc , Enter NOTE 1. This is a simplified drawing and some components are not marked in detail. 2. Please contact our sales representative if you need further product information. 3. All specifications are subject to change without prior notice. 4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales...

Open the catalog to page 2
