Overview: The document provides detailed specifications and pricing for various PILZ® laboratory heating mantles and accessories, valid until March 31, 2013. It includes information on different series of heating mantles, their features, and associated controllers.

Device Features: The document describes the features of the WRT2000X and WRT2010X table-top controllers, which include an ON/OFF switch, digital temperature display for actual and setpoint temperatures, integrated start and stop button, and terminal blocks for signal contacts and sensors. The WRT2000X also offers an option for a serial interface RS232 or a second analogue output.

Technical Specifications: Both controllers have dimensions of 205 × 80 × 188 mm, a nominal voltage of 230 V, and a nominal current of 10 A. They include built-in thermal fuse protection, a power input of less than 4.5 VA, and are designed to operate in ambient temperatures ranging from 0 to 70 °C. The protection standard is IP 30, and they are classified under safety class I.

Temperature Sensors: The document details various temperature sensors, including thermocouple tape and rod sensors, with specifications such as sensor length, type, maximum temperature (Tmax), and price. It emphasizes the importance of correct installation and connection to prevent overheating and ensure accurate temperature measurement.

Heating Tapes and Cords: Information is provided on different types of heating tapes and cords, including their structure, technical data, and pricing. The heating tapes are designed for high operating temperatures and are available in various lengths and power ratings.

Safety Instructions: The document stresses the importance of following operating instructions to ensure safe and trouble-free operation of PILZ® heating mantles. It highlights the need for temperature controllers to prevent overheating and the importance of monitoring the operation to avoid risks to persons or the environment. The document also outlines the safety principles and the necessity of technical measures to protect users from potential hazards.

Safety Measures and Standards: PILZ® heating mantles prioritize safety through constructional and technical measures, adhering to the Low Voltage Directive 2006/95/EC. They include a built-in residual current device (RCD) to prevent dangerous electric currents. If the RCD trips, the mantle must be checked by a qualified electrician before reuse.

Inspection and Maintenance: Regular inspections are mandated by BGV A3 and VDE 0702 standards, with a recommended interval of 6 months for portable equipment. Inspections include visual checks and testing the effectiveness of protective measures against electric shock.

General Terms and Conditions: Company Winkler's terms include conditions for contract formation, delivery, and liability. Contracts are confirmed in writing, and deviations require written confirmation. Delivery times depend on the timely provision of necessary documents by the purchaser.

Liability and Warranty: Defects must be reported within 6 months of delivery. Company Winkler offers remedies or replacements for verified defects. Liability is limited for defects due to natural wear, incorrect handling, or external influences.

Pricing and Payment: Prices exclude additional costs like freight and insurance. Payment is due within 30 days of invoice, with a 2% discount for payments within 10 days. Default in payment incurs interest charges.

Ownership and Resale: Ownership of goods remains with the seller until full payment. The purchaser may resell goods within regular business operations, maintaining the seller's ownership rights.

Tools and Equipment: Tools made by Company Winkler remain their property. Tools provided by the purchaser are subject to safekeeping rules, with the right to scrap after 5 years of inactivity.

Liability for Customer's Material: Company Winkler is liable for damage to customer-supplied materials only in cases of gross negligence, limited to 10% of the manufacturing value. Stored materials are insured against burglary, robbery, and fire.
