Overview: The document provides comprehensive technical specifications and options for Winkler's heated hoses, designed for transporting liquid and viscous media while maintaining temperature. These hoses are applicable across various industries, including chemical, pharmaceutical, food, machine construction, and medical technology.

Specifications: The heated hoses are available in multiple types, each with specific configurations. The document details codes for different hose types, lengths, nominal diameters, and inner hose materials, along with sensor types and operating voltages.

Technical Features: The hoses feature robust construction with PTFE insulated heating cables and protective conductor braiding. They come with different outer jackets, such as polyamide, galvanized steel, and stainless steel braiding, to meet various mechanical load requirements.

Applications: Suitable for both fixed installations and dynamic applications, including outdoor use, these hoses handle different pressure levels and are equipped with temperature sensors for precise control.

Quality Assurance: Winkler emphasizes high-quality materials and rigorous testing, including triple testing during production, to ensure safety and reliability. The company is ISO 9001:2008 certified and adheres to ATEX standards.

Customization and Service: Winkler offers customization options to tailor products to specific project requirements, positioning itself as a service provider and development partner with complete solutions and technical support.

Technical Data: Detailed technical data is provided for different hose series, including dimensions, bend radiuses, maximum operating temperatures, and power ratings. Maximum lengths for different operating voltages are also specified.

Conclusion: Winkler's heated hoses are versatile and reliable solutions for maintaining the temperature of transported media, focusing on quality and customization to meet demanding industrial requirements.

Additional Series Overview: The document also covers various series of heated hoses, including WSGG, WSGS, WSRS, WSA, and WEX8, designed for transporting liquids, gases, and viscous substances in industrial applications, including explosive environments.

Options and Features: Protective hoses with various braiding options, multiple fitting options, and integrated temperature sensors are available, especially for ATEX-rated environments.

Accessories: Includes fixation supports, terminal enclosures, and temperature control units designed for explosive atmospheres, ensuring secure installation and cable management.

Technical Specifications: The document outlines specifications for sealing cones, threads, and hoses according to standards like JIC, DIN, and BSP, with detailed tables of dimensions and materials.

Pressure Ratings: Tables provide static, dynamic, and burst operating pressures for different hose types at various temperatures, based on nominal diameter and working temperature.

Operating Voltages and Sensors: Options for operating voltages and temperature sensors, including Pt 100 and thermocouples, are listed, with details on pin assignments and sensor combinations.

Controllers: Descriptions of controllers with features like microprocessor control and LED displays, designed for industrial environments with various switching capacities.

Important Notes: Emphasizes correct sensor placement, especially outdoors, and the need for appropriate protection and insulation in varying ambient temperatures.

Accessories and Spare Parts Overview: Specifications for accessories and spare parts, including plugs, couplings, sockets, silicon caps, and foam hoses, with details on article numbers, voltage, current rating, IP rating, connection type, and temperature range.

Company Overview: Winkler GmbH specializes in electric heating solutions for industrial and laboratory applications, emphasizing high-quality materials and customized manufacturing, with a strong presence in Austria and France.

Contact Information: Winkler GmbH, Englerstrasse 24, D-69126 Heidelberg, Germany. Phone: +49-6221-3646-0, Email: [email protected], Website: www.winkler.eu
