Introduction
Wilden's Pro-Flo X™ Air Distribution System (ADS) has been recognized with Plant Engineering's Product of the Year award. This system, featuring the Efficiency Management System (EMS™) technology, provides unprecedented operational flexibility and efficiency for pump users.

Features & Benefits

Available in all metal construction sizes from 13mm (1/2”) to 76mm (3”).
Polypropylene options available in 38mm (1-1/2”) and 51mm (2”).
Includes EMS for enhanced efficiency management.
Groundable and ATEX compliant for safety.
Superior anti-freezing capabilities and flow rates.
Lube-free operation for ease of maintenance.
Longest Mean Time Between Repair (M.T.B.R.) for reliability.
Offers superior cost of ownership and efficiency.

Testing Conditions
All tests were conducted using water at 305 meters (1,000 feet) above sea level with a 0.3 meter (1 foot) suction lift on the pump inlet. Metal wetted path and ADS were used, with measurements taken using a thermal mass air flow meter and a calibrated load cell for fluid measurement.

Competitive Testing Results

For 51mm (2”) pumps, Wilden PX8 showed significant SCFM savings compared to competitors ARO® and Warren Rupp®.
At EMS setting 2.0, Wilden achieved 53 gpm at 28.1 SCFM, saving 16% SCFM compared to ARO®.
At EMS setting 2.8, Wilden achieved 72 gpm at 39.5 SCFM, saving 33% SCFM compared to Warren Rupp®.
For higher flow rates, Wilden PX8 at EMS setting 3.3 achieved 160 gpm at 94.0 SCFM, saving 22% SCFM compared to ARO®.
At EMS setting 2.5, Wilden achieved 131 gpm at 63.3 SCFM, saving 55% SCFM compared to Warren Rupp®.

Conclusion
The Pro-Flo X™ ADS by Wilden is the world's first energy-conscious Air-Operated Double-Diaphragm Pump (AODDP), offering significant efficiency improvements and cost savings over competitors.
