Chemical Transfer Pumps

Product catalog summary

Introduction
This document provides technical specifications and features of Wilden Chemical Transfer Pumps, highlighting their performance, materials, and air distribution system.

Features and Benefits

Superior containment ensures safe handling of chemicals.
Pumps are portable and submersible, offering flexibility in various environments.
ATEX models are available for use in explosive atmospheres.

Performance Specifications

Maximum flow rate of 784 lpm (207 gpm) for plastic models and 1021 lpm (270 gpm) for metal models.
Maximum suction lift: Wet 9.8 m (32’) and Dry 6.6 m (21.6’) for plastic models; Wet 9.5 m (31.2’) and Dry 7.6 m (25’) for metal models.
Maximum size solids: 12.7 mm (1/2”) for plastic models and 76.0 mm (3”) for metal models.

Technical Data

Available sizes range from 6 mm (1/4”) to 76 mm (3”).
Materials include Polypropylene, PVDF, PFA for plastic models, and Aluminum, Ductile Iron, Stainless Steel, Alloy C for metal models.
Elastomers options: Buna-N, Neoprene, EPDM, Viton®, Wil-Flex™, Saniflex™, Polyurethane, PTFE.

Air Distribution System (ADS)

Most efficient air distribution system with superior flow rates and anti-freezing capabilities.
Variable control for discharge flow rates and air consumption.
Reliable on/off functionality.
