Wind Turbines brochure.pdf - 1

Communication Solutionsfor Wind Turbines >

Open the catalog to page 1
Wind Turbines brochure.pdf - 3

Ethernet is the most common data communication standard used to-day. Westermo offers a wide product range, from unmanaged switches up to the fastest redundant ring switch on the market, regarding link recovery. Serial adapters, which make it possible to connect older equipment with a serial interface to an existing Ethernet network. We have both wireless solutions (WLAN) as well as products using SHDSL technique, that offers a high-speed connection on a copper cable. Our routers secure remote connection to an Ethernet network. For some reason it may not be possible to use a copper or a fi...

Open the catalog to page 3
Wind Turbines brochure.pdf - 5

Application This is a similar installation to the one on the left. It requires more Ethernet ports and the client wanted to use SNMP, so the solution was to use our Lynx-series. > 6 x TX Products L307-F1-MM-LC2ED-20 > 5 x TXISDNPSTN GSM SerialFibre Ethernet > 5www.westermo.com size="-1">

Open the catalog to page 5
Wind Turbines brochure.pdf - 6

Application This is a small windmill park with up to 7 towers. A fi ber optic star network is used from a centre to each tower. Either single or multimode cable is used depending on distances to the towers. A remote connection to the system is also possible, where the GSM modem provides the possibility to automatically send an SMS message in case of any link failure. > 4 x TX ISDNPSTN GSM Products U / R200-F7-MM-LC2SDW-541 / 532GDW-11ED-20 > 3 x TX SMS Alarm SerialFibre Ethernet > 6www.westermo.com size="-1">

Open the catalog to page 6
Wind Turbines brochure.pdf - 7

Application In this installation all the towers are connected via a redundant fi ber optic ring. The R200 offers the possibility to have up to 200 switches in one ring. The R200 series is used because the installation requires three fi ber optic ports in each tower. To obtain higher reliability, all switches on ground level are supported with dual power supplies. Products > 4 x TX5 x TX R200-F3-MM-LC2SDW-541 > NormalPowerSource UPS SerialFibre Ethernet > 7www.westermo.com size="-1">

Open the catalog to page 7
Wind Turbines brochure.pdf - 8

Application This is an offshore instal-lation where seven towers are connected in two dif- ferent multidrop connec-tions. The tower furthest away is equipped with a camera directed back- wards towards the other towers for supervision. For effi cient use of band-width, all data concerning control of the towers is on VLAN 1 and the video data is on VLAN 2. In this installation copper cable is used for communication between the top and bottom of each tower. Products L408-F2-SM-LC15L406 / SDW-550 > VLAN 1 VLAN 1VLAN 1 VLAN 2 VLAN 2 VLAN 2 SerialFibre Ethernet > 8www.westermo.com size="-1">

Open the catalog to page 8
Wind Turbines brochure.pdf - 10

Bridge Link The backbone ring switches can be mounted in a cabinet and connec- tion between the switches is done with copper cables to create a redundant ring. The software is the same in all switches. The functionality is decided by confi guration of the switch to act either as a focal point or ring member and also in the sub rings to identify which ports should act as a primary and secondary connection to the backbone. SerialFibre Ethernet > 10www.westermo.com size="-1">

Open the catalog to page 10
Wind Turbines brochure.pdf - 12

Bridge Link Any failure in hardware (switches) or at any fi ber optic link will be seen as a single faultӔ and the data traffi c will be rerouted to the secondary switch/link. Using the R200 assures link recovery within 30 ms independently of the number of switches in the ring or network load. > Redundant BackboneCopper or Fibre Optic Cable<30 ms recovery at Link Failure Primary Secondary Redundant Sub-ring<30 ms recovery at Link Failure SerialFibre Ethernet > 12www.westermo.com size="-1">

Open the catalog to page 12
Wind Turbines brochure.pdf - 14

Order information Lynx Type of connector and distance of the transceiverMultimode, Singlemode or BIDI transceiverNumber of fibre ports (1 or 2)Total number of ports (6, 7 or 8)Environmental approvals0 = Industrial 1 = Marine 2 = Rail 3 = SA, Substation4 = MilitaryLevel of functionality1 = Harsh environments 3 = Redundant Ring 4 = High Security ApplicationsLxxx = 10 / 100 MbitL1xxx = 10 / 100 / 1000 Mbit 14www.westermo.com >

Open the catalog to page 14
Wind Turbines brochure.pdf - 15

Type of connector and distance of the transceiverMultimode, Singlemode or BIDI transceiverNumber of fibre ports (1 - 8)U = UnmanagedR = RingT = Time SyncronisationModel > Type of connector and distance of the transceiver > Multimode, Singlemode or BIDI transceiver Order information U / R / T200 / SDW 550 = 5 TX ports541 = 4 TX and 1 FX532 = 3 TX and 2 FXModel >

Open the catalog to page 15
Wind Turbines brochure.pdf - 16

SUBSIDIARIES United Kingdom France > Westermo Data Communications LtdTalisman Business Centre Duncan Road, Park Gate, Southampton. SO31 7GA Phone: +44(0)1489 580 585Fax: +44(0)1489 580 586sales@westermo.co.uk www.westermo.co.uk Westermo Data Communications S.A.R.L. Bat. A, 9 Chemin de Chilly FR-91160 Champlan. France Tl : +33 1 69 10 21 00 Fax : +33 1 69 10 21 01 infos@westermo.frwww.westermo.fr Germany Norway > Westermo Data Communications GmbH Goethe Strasse 67 DE-68753 Waghusel. Germany Tel: +49(0)7254 95400-0 Fax: +49(0)7254-95400-9info@westermo.dewww.westermo.de Westermo OnTime...

Open the catalog to page 16
