Top Performance in 2D and 3D
44Pages

{{requestButtons}}

Catalog excerpts

Top Performance in 2D and 3D - 1

weCat3D 2D/3D Profile Sensors and ShapeDrive 3D Sensors

Open the catalog to page 1
Top Performance in 2D and 3D - 2

weCat3D 2D/3D Profile Sensors weCat3D MLSL1 weCat3D MLSL2 weCat3D MLWL2 weCat3D MLWL1 ShapeDrive 3D Sensors ShapeDrive MLAS ShapeDrive MLBS Interfaces and Software A World Full of Applications

Open the catalog to page 2
Top Performance in 2D and 3D - 4

weCat3D. Dominance in 82 Models With more than 30 years of experience and over 20,000 installed solutions, wenglorMEL is a pioneer in the field of two and three-dimensional object measurement. The 2D/3D sensors project a laser line onto the object to be measured and then record it by means of an integrated camera. Two and three-dimensional surface and volume profiles can thus be calculated with the help of point clouds – quickly and accurately. With 82 innovative variants, the weCat3D series offers maximum individualized solutions for your multi-dimensional application. At the same time,...

Open the catalog to page 4
Top Performance in 2D and 3D - 5

Laser Line with Triangulation Angle The Functional Principle Integrated Camera Triangulation Angle

Open the catalog to page 5
Top Performance in 2D and 3D - 6

weCat3D: Diversity. Integration. Performance. Solution. Interfaces & Software • GigE Vision standard, e.g. for incorporation into HALCON or LabVIEW without controller • 2 performance classes: MLSL and MLWL • More than 82 weCat3D models • Program library made available for interfacing with external software • 16 different measuring ranges • Free, downloadable Software Development Kit (SDK) for all weCat3D sensors (including 32 and 64-bit DLL, description and examples) • 4 selectable laser classes (1, 2M, 3R, 3B) • 3 selectable types of light (red, blue, UV) • Future-proof thanks to RS-422...

Open the catalog to page 6
Top Performance in 2D and 3D - 7

Operation & Support • Optimized algorithms – for black and glossy surfaces • Intuitive OLED display • 3.6 to 12 million measuring points per second • Multilingual operation • Real-time signal processing by means of integrated FPGA technology • Highly flexible thanks to adaptable protective discs and cooling units • 4 configurable inputs/outputs • Integrated web server for configuration and analysis • Worldwide support • Highly reliable even with changing colors and extraneous light • Leasing option for weCat3D sensors • Integrated CPU without additional controller • Free VisionApp Demo for...

Open the catalog to page 7
Top Performance in 2D and 3D - 8

weCat3D MLSL1 Intelligence in the Tightest of Spaces weCat3D MLSL1 offers maximized capabilities in the tightest of spaces. The 12 models included in this product series are distinguished by innovative features such as CMOS technology, integrated CPU, high resolution and measuring rate (4000 Hz), intuitive display, excellent measuring accuracy, ultramodern interfaces such as Gigabit Ethernet and much more. A total of 4 measuring ranges are available. Working range Z Measuring range Z Measuring range X Resolution Z Resolution X Laser class 1M / red light Laser class 2M / red light Laser...

Open the catalog to page 8
Top Performance in 2D and 3D - 9

Accessories • Connection technology • Mounting system • Control unit / IPC • Software • Cooling unit • Protective disc retainer • Protective disc set Working Range Z | Measuring Range X

Open the catalog to page 9
Top Performance in 2D and 3D - 10

weCat3D MLSL1 1 Compact, Lightweight Design (92×36×64 mm / 300 g), also suitable for robot applications as a rugged IP67 variant. 5 7 Read-out of up to 3.6 million measuring points per second via M12×1 plug with Ethernet TCP/IP from 100 Mbit/s to 1 Gbit/s. 10 Very precise resolution (Z) of down to 3.3 µm thanks to the CMOS camera with noise suppression and high-performan

Open the catalog to page 10
Top Performance in 2D and 3D - 11

2 The weCat3D series can be integrated via it’s program library or GigE Vision without an additional controller. 3 Integrated electronic system without additional controller including interferenceproof profile evaluating algorithms. 4 Specially developed laser line modules with red or blue light, ideal for applications involving metals, as well as organic and semitransparent materials. 5 Optional, adaptable protective discs and cooling units make implementation possible in a diverse range of applications, Standard M12×1 plug with 4 configurable I/Os and even in extreme environments....

Open the catalog to page 11
Top Performance in 2D and 3D - 12

weCat3D MLSL2 More Diversity, Better Performance The weCat3D MLSL2 series is distinguished by large measuring ranges of up to 1350 mm in the X direction, increased laser power for quick and robust profile detection and additional, external 24 V laser shutdown for classes 3R and 3B. As is the case with the entire MLSL series, the ten models with two measuring ranges are based on innovative features such as CMOS technology, integrated CPU, a fast measuring rate (4000 Hz), intuitive display, very good measuring accuracy, ultramodern interfaces such as Gigabit Ethernet and much more. Working...

Open the catalog to page 12
Top Performance in 2D and 3D - 13

Accessories • Connection technology • Mounting system • Control unit / IPC • Software • Cooling unit • Protective disc retainer • Protective disc set Working Range Z | Measuring Range X

Open the catalog to page 13
Top Performance in 2D and 3D - 14

weCat3D MLSL2 1 Compact, Lightweight Design (200×67×38 mm / 550 g), also suitable for robot applications as a rugged IP 67 variant. 6 Standard M12×1 plug with 4 configurable I/Os and connection option for HTL or RS-422/TTL encoder. 9 CMOS camera with highly precise resolution for measuring range X with more than 1200 measuring High-performance optics for measuring range X points as a linearized height profile.

Open the catalog to page 14
Top Performance in 2D and 3D - 15

2 The weCat3D series can be integrated via it’s program library or GigE Vision without an additional controller. 3 Integrated electronic system without additional controller including interferenceproof profile evaluating algorithms. 4 Specially developed laser line modules with red or blue light, ideal for applications involving metals, as well as organic and semitransparent materials. 5 Optional, adaptable protective discs and cooling units make implementation possible in a diverse range of applications, even in extreme environments. Real-time signal processing by Read-out of up to 3.6...

Open the catalog to page 15
Top Performance in 2D and 3D - 16

weCat3D MLWL2 Compact High-Performance The weCat3D MLWL2 delivers high-performance in every respect. Combined with a compact housing, this product series provides the right mixture of top performance and a space-saving design. Specially developed optics permit an impressive Z working range of up to 2500 mm and measuring ranges in the X direction from 65 to 1300 mm - with up to 12 million measuring points per second. Working range Z Measuring range Z Measuring range X Resolution Z Resolution X Laser class 1M / red light Laser class 2M / red light Laser class 2M / blue light Laser class 3R /...

Open the catalog to page 16
