Even in the present High-tech ageӔ problems due to friction and wear are a matter of course in a lot of in- dustrial sectors. Extensive repairs, longer downtimes, shorter maintenance intervals and lower serviceable lives of plant and equipment are the consequence and cause enormous costs each year. It is therefore important to already fulfil the require- ments for long-term operational dependability of plant and equipment in the development and construction phase.During the technical design of movable plant and equip-ment elements, the lubricant should be viewed as being a calculable functional...

tar machines Օ hot-air fans sintering plants Օ convertersClassification acc. to DIN 51 502: KPL 2 R -20Colour: dark brown NLGI class: 2 Temperature range: -25C to +190аC (briefly up to 200C) Areas of use: Allround high-temperature grease for the long-term lubrication of rolling and sliding bearings at all sliding speeds permissible for grease lubrication. Suitable for: Е rolling and sliding bearings joints Օ levers sliding guides Օ spindles spline shafts Technical product information, a type selection table as well as basic information about ՓTribology can be found on the following pages.Constant...

2 Areas of use: on-board cranes and lifting gears, offshore components Օ busbars and distributors skip and trailer units Օ shipyard supplier components for all rolling and sliding bearings in water pumps, water turbines, lock gates, car washesClassification in accordance with DIN 51 502: KPL 1-2E -25Colour: beige NLGI Class: 1-2 Temperature range: - 25հC to +80C Conforms to: Federal German Armed Forces TL 9150-0066; NATO Spec. G-460 Areas of use: Suitable for: Е rolling and sliding bearing assemblies in industry and construction articulated blocks of articulated shafts and universal joints Օ...

Areas of use: filling and packing machines Օ machines in the textile and clothing industry electrical and precision mechanical units and also machine elements in dairies, breweries, large abattoirs, catering kitchens etc.Classification in accordance with DIN 51 502: KLF 2K -30Colour: white NLGI Class: 2 Temperature range: - 30հC to +120C Conforms to: NSF H2; LMBG Section 31 and Section 5 Suitable for: Е roller and sliding bearings pivoted bearings Օ levers, sliding guides spindles Օ spline shafts camshafts, open gears Օ worm gears > Areas of use: all lubrication points in the brewery and beverages...

Abreviation (DIN 51502):KPL 2 R -20KF 2 K Ֆ20KPL 1-2 E -25KPHC 1P -40KLF 2K -30Consistency assignment (DIN 51818):NLGI-Klasse 2NLGI-Klasse 2NLGI-Klasse 1-2NLGI-Klasse 1NLGI-Klasse 2Base: > Aluminium complex soap / mineral oilLi/Ca soap / MoS 2 / mineral oilSpec. calcium soap / mineral oilAluminium complex soap / polyalphaolefineLithium soap / mineral oil Colour:darkbrownblackbeigeyellowish-whitewhiteVKA Test(DIN 51 350):Welding load:2400 N3200 N3400 N1800 N3600 NGoods load:2200 N3000 N3200 N1700 N3400 NSpherical cap value (1 Min / 1000 N)2,0 mm0,5 mm0,7 mm0,6 mm 0,8 mmSpeed identifying value...

Lubricating greaseIdentifying letterSymbolLubricating greases for rolling and sliding bearings and sliding surfaces in ac-cordance with DIN 51825 Consistency identifying number (NLGI classes in accordance with DIN 51818)Worked penetration determined based on DIN ISO 2137 units > 1) 1) For lubricating greases based on mineral oilLubricating greases for closed gears in accordance with DIN 51826 > 355 to 385 Lubricating greases for open gears, gearing (adhesive lubricants without bitumen) > 265 to 295 220 to 250 Lubricating greases for sliding bearings and seals ղ) > 175 to 205 Lubricating greases...

Additive to lubricants, corrosion protection and maintenance products to achieve certain properties. > Chemical transformation of substances due to the effects of heat, light and oxygen throughout the running time. > Carrier fluid for pastes, greases, oils. > The lubricating oil contained in the lubricating grease is separated from the soap frame. The bleeding of the grease at the lubricating point can mean that the grease is not sufficiently operatively stable and/or temperature resistance. Arises if the lubricating film is penetrated or destroyed during the friction action. The pair of materials...

Oil separation as a percentage of weight is measured in accordance with DIN 51817 whereby the lubricating grease to be inspected is admitted with pressure and temperature. > Oxidation is a combustion process. The addition of oxygen to certain elements or molecules occurs in this process. In the case of hydro-carbons jellification, the formation of lacquer, polymers, corrosive radicals etc. arise. Measurable variable for the stipulation of the consistency (ductility) of lubricating greases. In the case of lubricating fats it is the distance which a cone of a certain dimensions penetrates vertically...

ACM - > Acrylate rubber ++++++++++CR - > Chloroprene rubber +++++CSM - > Chlorosulfonated PE rubber ++++++++++EPDM - > Ethylene propylene diene rubber ----------FKM - > Fluorocaoutchoc ++++++++++NBR - > Nitrile butadiene rubber ++++++++++NR - > Natural rubber 0--------SBR - > Styrene butadiene rubber 0--------SQM/MVQ - > Silicone rubber ++++++++++ > ++ resistant + resistant to a limited extent 0 not tested, preliminary trials or resistance tests are recommended not resistant ABS > - ABS copolymeride ++++++++++CA > - Cellulose acetate ++++++++++EPS > - Expanded polystyrene ++++++++++PA > - Polyamide...

Optimum results with WEICON Allround Lubricant high performance greases can only be achieved following the com- plete removal of grease residues. However, in practice the complete removal of such grease residues is not always possible. In this case you must check whether the WEICON product envisaged for use is always compatible with the grease that is still present. This test must be carried out on the basis of the main components of the grease (basic oil and thickener). Both main components must be miscible (compatible). > Basic oilMineral oil > (AL-M, AL-W, AL-F,AL-T) Polyalpha-olefine > (AL-H)...
