MVW-01 - Medium Voltage Variable Frequency Drive

MVW-01 - Medium Voltage Variable Frequency Drive
1 / 16Pages

Catalog excerpts

MVW-01 - Medium Voltage Variable Frequency Drive - 1

Motors | Automation | Energy | Transmission & Distribution | Coatings MVW01 Medium Voltage Frequency Inverter

MVW-01 - Medium Voltage Variable Frequency Drive - 2

www.weg.net MVW01 - Medium Voltage Frequency Inverter WEG is a traditional supplier of solutions in speed variation, manufacturing all the parts of a system: Input switchgear, transformer(dry-type or oil-type), frequency inverter and electric motor. The MVW01 is designed to control medium voltage induction motors. It features unique innovations, combining hardware robustness with simplicity, reliability and safety in a compact solution with few components and state-of-the-art generation technology. MVW01 follows the same programming philosophy of the WEG low voltage inverter line,...

Open the catalog to page 2

MVW-01 - Medium Voltage Variable Frequency Drive - 3

www.weg.net Characteristics Software for Drives Programming S uperDrive is a programming software for the MVW01 drives. The software incorporates functions such as: parameters upload and download, drive operation and monitoring, off-line programming, and trace function. SuperDrive is a Windows compatible software (Windows 95, Windows 98, Windows ME, Windows NT Workstation 4.0, Windows 2000 Professional, Windows XP and Windows 7). The Drive-PC communication uses a RS-232 or a RS-485 interface. Trace Function g Registration and graphical view of MVW01 variables g Simulates an oscilloscope...

Open the catalog to page 3

MVW-01 - Medium Voltage Variable Frequency Drive - 4

■ Cooling monitoring through pressure sensor Rectifier Bridge ■ High power factor (>0.95) ■ Monitoring - fiber optic 36 Pulse rectifier bridge is available for 6kV-6.9kV models only Withdrawable IGBT Arms ■ Withdrawable power arms ■ Gate drivers / feedbacks / monitoring - fiber optic ■ Simple control connections ■ Plug in power connections ■ Simple and fast replacement 4 | MVW01 - Medium Voltage Frequency Inverter

Open the catalog to page 4

MVW-01 - Medium Voltage Variable Frequency Drive - 5

■ No need for special care for maintenance Fiber optic interface ■ Fiber optic connection between control and power sections: gate drivers; feedbacks,temperature monitoring, ■ Graphical: sequential access to the parameters or groups through the access keys of the display functions ■ Same HMI standard of the low voltage ■ Parameterization follows the same philosophy Mechanical Lock ■ Mechanical lock for the power sections Electro-mechanical interlocking with the main circuit breaker ■ Unable to open power sections with the main circuit breaker energized MVW01 - Medium Voltage Frequency...

Open the catalog to page 5

MVW-01 - Medium Voltage Variable Frequency Drive - 6

www.weg.net Applications Chemical, Petrochemical, Oil and Gas Pumps Fans / Exhausters Compressors Mixers / Agitators Cement and Mining Ovens Fans / Exhausters Conveyors Mills Steel and Metallurgy Pumps Fans / Exhausters Steel Mill Winders Sugar and Chemical Sugarcane mill Fans Exhausters Preparation Pulp and Paper Pumps Fans Exhausters Refiners Plastic and Rubber Banburys® Extruders Water & Waste Water Management Pumps 6 MVW01 - Medium Voltage Frequency Inverter Pumps The variable frequency drive can vary the pump flow by adjusting the motor speed. In such a way, not only the improvement on...

Open the catalog to page 6

MVW-01 - Medium Voltage Variable Frequency Drive - 7

www.weg.net Product Code 1 MVW01 2 C 3 0070 4 T 5 6900 6 P 7 O 8 - 9 - 10 - 11 - 12 DN 13 - 14 - 15 Z 7 - Optional kits 1 - WEG Medium Voltage Frequency Inverter O blank MVW01 With optional kits Standard 2 - MVW01 Model C (blank) 8 - Enclosure protection degree Compact Standard 3 - Output rated current (constant torque - CT 2300 V 0120 = 120 A 0140 = 140 A 0165 = 165 A 0175 = 175 A 0210 = 210 A 0250 = 250 A 0280 = 280 A 0386 = 386 A 0450 = 450 A 0490 = 490 A 0560 = 560 A 0733 = 733 A 0880 = 880 A 0931 = 931 A 1064 = 1064 A 3300 V 0085 = 85 A (*1) 0100 = 100 A (*1) 0112 = 112 A (*1) 0138 =...

Open the catalog to page 7

MVW-01 - Medium Voltage Variable Frequency Drive - 10

10 | MVW01 - Medium Voltage Frequency Inverter

Open the catalog to page 10

MVW-01 - Medium Voltage Variable Frequency Drive - 11

www.weg.net Dimensions and Weights Size D Weight: 4500 Kg Size E Weight: 5000 Kg MVW01 - Medium Voltage Frequency Inverter 11

Open the catalog to page 11

MVW-01 - Medium Voltage Variable Frequency Drive - 12

12 | MVW01 - Medium Voltage Frequency Inverter

Open the catalog to page 12

MVW-01 - Medium Voltage Variable Frequency Drive - 13

Technical Characteristics MVW01 - Medium Voltage Frequency Inverter | 13

Open the catalog to page 13

MVW-01 - Medium Voltage Variable Frequency Drive - 14

www.weg.net Technical Characteristics Electromagnetic compatibility Compliances / Standards EMC directive 89 / 336 / EEC – industrial environment CEI Standard - IEC 61800-3 (EMC – Emisson and Immunity) Adjustable Speed Electrical Power Drive System CEI - IEC 61800 Part 4 – General Requirements Part 5 – Safety Requirements Start / Stop, General Functions Programming Commands Increase / Decrease Speed JOG, FWD/VER and Local/Remote Speed Reference (rpm) Drive Status Output Frequency (Hz) Status of Digital Inputs DC Link Voltage (V) Status of Digital Outputs Motor Torque (%) Status of Relay...

Open the catalog to page 14

MVW-01 - Medium Voltage Variable Frequency Drive - 15

www.weg.net Block Diagram Up to 36 kV Input Switchgear Main circuit breaker Phase Shifiting Transformer Transformer Ability to setup with 12, 18, 24 or 36 pulses Note: 36 Pulse rectifier bridge is available for 6 kV - 6.9 kV models only MVW01 - Medium voltage frequency inverter Medium voltage induction motor 2.3 kV, 3.3 kV, 4.16 kV, 6 kV-6.3 kV, 6.6 kV-6.9 kV MVW01 - Medium Voltage Frequency Inverter 15

Open the catalog to page 15

MVW-01 - Medium Voltage Variable Frequency Drive - 16
