Polycarbonate bowls and sight dome, being transparent and tough, are ideal for use with Filters and Lubricators. They are suitable for use in normal industrial environments, but should not be located in areas where they could be subjected to direct sunlight, an impact blow, nor temperatures outside of the rated range. As with most plastics, some chemicals can cause damage. Polycarbonate bowls and sight dome should not be exposed to chlorinated hydro-carbons, ketones, esters and certain alcohols. They should not be used in air systems where compressors are lubricated with fire-resistant fluids...

Compressed Air Treatment QIX Modular FRL System General Information QIX Modular FRL System Quick Insert Xchange Pressure Switch Particulate Filters Porting Block Shut-Off Valves Pressure Gauges Automatic Float Drain QIX is the Premium FRL System for the Demanding, High Performance Manufacturer Regulators (R20) Accurate high-flow regulators are equipped with positive snap lock, push / pull adjusting knobs for easy operation. Bayonet style spring cage is removed with only the push of a button. Piston and o-ring is replaceable in seconds, using standard pliers. Addressing the needs of the production-oriented...

F20 & F21 QIX Particulate & Coalescing Filters Features Manual Drain • Unique Interchangeable QIX Inserts Allow One Module to Accommodate 5 Port Sizes 1/4", 3/8", 1/2", 3/4", 1" Automatic Drain • For Heavy Duty Applications with Minimum Pressure Drop Requirement • Excellent Water Removal Efficiency • Available in Both Particulate (F20) and Coalescing (F21) Configurations • Metal Bowl with Sightgauge Standard • Manual Drain Standard. Automatic Float Drain Optional • High Flow - 180 SCFM for 3/4" & 1" Sizes (F20) 20 SCFM (F21 Coalescing) inches (mm) * 1/4 thru 3/4 Inch Port Insert Size ** 1 Inch...

QIX Series Particulate & Coalescing Filters Technical Specifications – F20, F21 Technical Information F20 Flow Chart 1/4" Pressure Drop - PSIG Flow Characteristics F20 Standard 40 Micron Filter 0 F21 Flow: 20 SCFM @ 100 PSIG Pneumatic Division Richland, Michigan www.parker.com/watts

R20 & R21 QIX Regulators Features • Unique Interchangeable QIX Inserts Allow One Module to Accommodate 5 Port Sizes 1/4", 3/8", 1/2", 3/4", 1" • Piston Operated for High Flow Performance • Secondary Aspiration Plus Balanced Poppet Provides Quick Response and Accurate Pressure Regulation • High Flow: 250 SCFM for 3/4" & 1" Port Sizes R20 Features • Push-to-Lock, Pull-to-Adjust, Remove-forTamper-Resistant Knob Feature B R21 Features • Heavy Duty Tee Handle Adjustment R21 inches (mm) * 1/4 thru 3/4 Inch Port Insert Size ** 1 Inch Port Insert Size Ordering Information Adjustment Type 20 Knob 21 Tee-Handle...

Technical Specifications – R20, R21 Technical Information Flow Characteristics Secondary Pressure - PSIG REGULATOR PRESSURE ADJUSTMENT – The working range of knob adjustment is designed to permit outlet pressures within their full range. Pressure adjustment beyond this range is also possible because the knob is not a limiting device. This is a common characteristic of most industrial regulators, and limiting devices may be obtained only by special design. For best performance, regulated pressure should always be set by increasing the pressure up to the desired setting. Product rupture can cause...

• Unique Interchangeable QIX Inserts Allow One Module to Accommodate 5 Port Sizes 1/4", 3/8", 1/2", 3/4", 1" D • High Flow Venturi and By-pass Valve to Minimize Pressure Drop and Ensure Consistant Lubrication at All Rated Flows • Excellent Water Removal Efficiency • Tamper Resistant Removable Drip Control Knob • Manual Drain Standard • High Flow: 250 SCFM for 3/4" & 1" Port Sizes inches (mm) * 1/4 thru 3/4 Inch Port Insert Size ** 1 Inch Port Insert Size Ordering Information Port Threads — NPT G* BSPP * f ordering BSPP I Port Inserts Separately - Order “-00” Unit Port Size H Button Head Fill...

Technical Specifications – L20 Technical Information 1/4" Pressure Drop - PSIG Flow Characteristics L20 Supply Pressure 100 PSIG Pneumatic Division Richland, Michigan www.parker.com/watts

QIX Filter / Regulators 1/4, 3/8, 1/2, 3/4 & 1 Inch Ports • Unique Interchangeable QIX Inserts Allow One Module to Accommodate 5 Port Sizes 1/4", 3/8", 1/2", 3/4", 1" • Piston Operated Regulator for High Flow Performance C • Excellent Water Removal Efficiency • Secondary Aspiration Plus Balanced Poppet Provides Quick Response and Accurate Pressure Regulatorion • Excellent Water Removal Efficiency B • Manual Drain Standard • Automatic Drain Optional • Panel Mountable • High Flow: 250 SCFM for 3/4" & 1" Port Sizes B21 B20 Features • Push-to-Lock, Pull-to-Adjust, Remove-for-Tamper Resistant Knob...

QIX Series Filter / Regulators Technical Specifications – B20, B21 Technical Information Flow Characteristics B20 / B21 Supply Pressure 100 PSIG Product rupture can cause serious injury. Do not connect regulator to bottled gas. Do not exceed maximum primary pressure rating. Pressure Drop - PSIG REGULATOR PRESSURE ADJUSTMENT – The working range of knob adjustment is designed to permit outlet pressures within their full range. Pressure adjustment beyond this range is also possible because the knob is not a limiting device. This is a common characteristic of most industrial regulators, and limiting...

QIX Series Two & Three Unit Combinations Model Numbers and Dimensions QIX Combinations – C20 / C21 Series • See individual component pages for details. • Gauges included on combinations. D Three-Unit Combo inches (mm) * 1/4 thru 3/4 Inch Port Insert Size ** 1 Inch Port Insert Size Ordering Information Adjustment Type Port Threads — NPT G* BSPP 20 Knob 21 Tee Handle * If ordering BSPP Port Inserts Separately Order “G00” Unit Port Size 02 1/4 Inch Regulator Reduced Pressure Range Engineering Change Designator Will be entered at factory. C 0-125 PSIG D 0-250 PSIG Elements G 5 Micron REGULATOR PRESSURE...
