Overview

This document provides technical specifications and dimensional data for stainless steel bolted wear bars used in industrial machinery, specifically related to basic machine models and their components.

Main Sections

1. Product Description

The document refers to stainless steel bolted wear bars, described in multiple languages (English, German, French, Italian), emphasizing their application in wear protection.

2. Machine Models and Dimensions

Several machine models are listed with corresponding dimensions in millimeters. These include models such as DS 1000, DS 400, DS 2000, DS 3400, DS 4000, and others with detailed measurements for various parameters labeled with letters (P, G, E, A, H, M, L, D, C, B, F).

Key dimensional data include lengths, widths, and heights relevant to inlet and outlet zones, hopper capacity, and other machine parts.

3. Flange Specifications

Flange types and sizes are specified according to UNI standards, with nominal diameters (DN) and pressure ratings (PN10). Examples include DN80PN10, DN100PN10, DN125PN10, DN200PN10, DN250PN10, DN400PN10, and combinations such as 2xDN250PN10.

4. Performance Parameters

The document lists flow rates (in m³/h), installed power (in kW), hopper capacity (in m³), and weight (in kg) for different configurations. For example, flow rates range from 18 to 130 m³/h, installed power from 0.45 to 3.9 kW, hopper capacities from 0.55 to 2.94 m³, and weights up to 1850 kg.

5. Multilingual Terminology

Key terms such as inlet, outlet, flange, delivery, and hopper capacity are provided in English, German, French, and Italian to support international use.

6. Notes and References

Dimensions are provided for reference only, with a recommendation to contact the manufacturer for detailed drawings. The document includes a website link (www.wamgroup.com) and product codes for ordering or identification.

Critical Information and Recommendations

• Dimensions and specifications should be verified with the manufacturer before application.
• Flange sizes and pressure ratings must match system requirements to ensure safety and compatibility.
• Installed power and flow rates should be considered when selecting the appropriate machine model for operational efficiency.
• Weight and hopper capacity are important for installation and handling planning.

Summary

This technical document serves as a reference for stainless steel bolted wear bars and associated machine components, providing essential dimensional data, performance parameters, and multilingual terminology to support international industrial applications. It emphasizes the importance of consulting detailed manufacturer drawings for precise implementation.
