Automatic Spray Guns Save Material – Protect the Environment The Coatings Expert

2 Fulfi ll the highest quality requirements “Automatic spray guns play a key role as the final components of a complete system. For that reason, their quality requirements need to be as high as possible.” Wilhelm W. Schmidts Managing Director Our state-of-the-art precision machines guarantee unsurpassed process reliability and quality standards. We are continuously working on improvements: endurance and performance tests in which the spray guns are opened and closed millions of times are constantly being carried out. Our products save material and protect the environment at the same time....

3 Solutions from a complete system supplier Walther Pilot is responsible for all aspects of spraying, including: ð· Spray guns for manual or automatic operation ð· Material supply using pressure tanks or pumps ð· Control of the spraying process using pneumatic or electronic control units ð· Mountings, mounting plates, etc. for lifting devices, robots, stationary fittings ð· Transporting parts to the spraying facility ð· Overspray filtration systems or special housings for automatic spray guns ð· Drying systems Pressure tanks and agitators in various sizes and models Pneumatic or...

4 Much more than just painting Spraying adhesive media onto cardboard products A wide range of applications Oval rotor with 24 airless guns for latex-coating the inner parts of skiing jackets Lubricant application Marking seams for the production of car seats Coating of small parts – edgedefined coating Robot application of anti-corrosion coating Marking pipes and metal sheets Seal-coating PCBs Final cold-end hardening of glass containers Anti-corrosion coating of handle lug weld points Colouring of flowers Food processing Drum-coating of small parts Laboratory equipment

5 ð® If you require, we can carry out spray tests in our lab to help you find the ideal solution to your coating problem. ð® Whatever the problem, we have the solution, whether it be - conventional spraying - HVLP- and medium pressure - innovative HVLPPlus-technology - Airless and air-assisted Airless ð® WALTHER PILOT automatic spraying equipment can be added to any existing material feed system, either standard or recirculating ð® With WALTHER PILOT-spray guns, servicing and cleaning is made easy. The material duct is straight to prevent deposition of the spraying medium. ð® A wide range...

6 The premium class Schrittgeber 5 x 7 Matrix 4 x 5 Matrix 40 - 200 mm Thanks to the newly developed nozzle/air cap system, HVLPPlus, the PILOT WA 700 automatic spray gun series offers the finest results while at the same time saving material. Depending on the application required, the spray gun is available with internal or external control. Front body and all wetted parts: stainless steel. Material-volume adjustment through notch-type fine adjustment The wide range of versions guarantees optimum product solutions for almost all requirements. PILOT WA 700 Models PILOT WA 700: Standard...

7 With quick-change adapter plate The PILOT WA 800 series offers a large selection of spray guns for almost all job specifi cations. The guns are all fi tted with adapter plates. This allows the spray guns to be quickly exchanged for maintenance purposes. The front body is made entirely of stainless steel. Adapter plate: chemically galvanised aluminium. Stainless steel adapter plates available on request. Innovative packing solutions enable the service life to be extended by up to 30% compared to similar spray guns on the market. The wide range of versions guarantees optimum product...

8 The all-rounders Schrittgeber 5 x 7 Matrix 4 x 5 Matrix 40 - 200 mm PILOT WA 500 Concentrated spraying power This automatic spray gun operates without internal control, i.e. the atomising air is applied continuously. Model WA 400 is ideal for use in continuous operations or where surfaces are to be air-blasted, for example for drying purposes. All wetted parts are made of stainless steel, allowing waterbased paints and other media to be processed without diffi culty. PILOT WA 400 Models PILOT WA 500: Standard version PILOT WA 510-U: Standard version for recirculation systems HVLP version...

9 Fully automatic compact spray guns This space-saving model with a length of just 110 mm and weight of only 355 g is ideally suited for a wide range of coating materials. A total of nine nozzle sizes are available in a range between 0.3 mm and 2.2 mm Ø. Round and wide jet are infi nitely variable. The self-centering nozzle/air cap system guarantees continuously high-quality spraying fi nishes. All wetted parts are made of stainless steel, thus allowing waterborne coatings and aggressive media to be sprayed without problems. PILOT WA 600 Even smaller, even lighter This miniature-sized spray...

10 The heavy-duty specialists Model version with pullbar PILOT WA XV-ND (HVLP) Proven, rugged and affordable This highly popular automatic spray gun with internal control is also available in different versions. It is suitable for all everyday spraying jobs. The front body and all wetted parts are made entirely of stainless steel. PILOT WA XV A comprehensive range of nozzles ensures excellent results with virtually all types of spraying media. Nozzle inserts available: (Ø in mm): 0.3 · 0.5 · 0.8 · 1.0 · 1.2 · 1.5 · 1.8 · 2.0 · 2.2 · 2.5 · 3.0 · 3.5 (Standard size: Ø 1.5 mm) Nozzle sizes for...

11 Perfect results under pressure Compact airless spray gun without nozzle. Max. operating pressure: 350 bar All standard airless nozzles are available. A table of nozzles is available on request. The gun is also available with a stainless steel gun body for use with water-based or aggressive media. PILOT WA 30 is also available as a metering valve with Ø 5.0 mm. The maximum operating pressure is 100 bar. A stainless steel valve version is available on request. Small airless spray gun without nozzle. Max. operating pressure: 120 bar. Gun body: stainless steel. All standard airless nozzles...
