HANDLING AND LIFTING Make use of the force and easy control of the lifting magnets in your company. Magnetic tools will replace ropes, chains or clamps during handling and lifting. Your operations will be more efficient, you will save manpower and enhance safety when handling steel semifinished products, workpieces and finished products in smelting works and steel works, workshops, and in metallurgical material warehouses.

Large hanging welded lug with several times higher load capacity compared to prefabricated lugs Safety factor 3+ We test the load capacity of our air gap magnets for the highest safety Higher lever position - better use for handling profiles or other loads where space for magnet placement is limited 5-year warranty for the magnetic system Load Test - verification of sufficient load capacity of the magnet on a specific load NFC chip - electronic magnet history including service records and test certificate When to choose a Revolift permanent lifting magnet: The Revolift product is an innovative...

5-year warranty for the magnetic system — Large non-magnetic stainless steel suspension lug Fixed magnet body, only 2 recessed screws to attach the lever stop The Air Gap test - a tear-off test is carried out with an air gap - we place emphasis on advanced safety in real operating conditions Easy Switch When to choose a Neo permanent lifting magnet: The Neo magnet is widely used for handling ferromagnetic materials in the metal industry - in workshops, on building sites, in warehouses for semi-finished steel products, and when handling steel workpieces, tools, sheets, metal profiled sections,...

When to choose a Neo Hot permanent lifting magnet: This is a special version of the Neo lifting magnet, designed to handle hot materials up to 180 °C. NOMINAL LIFTING CAPACITY FOR FLAT MATERIAL NOMINAL LIFTING CAPACITY FOR ROUND MATERIAL TEMPERATURE Lifting Other important parameters: Safety factor: 3+ (according to EN 13155) + handling of flat materials + handling of circular materials and profiles Catalog number Workload limit flat materials Workload limit round materials

When to choose the BM lifting magnet: The BM battery lifting magnet complete with remote control is a suitable tool for handling in workstations where it is otherwise difficult to operate a lifting device manually. The remote control operates up to 5 metres away. It is also used for cutters and flame cutting machines when handling metal sheets and loads up to 5000 kg. NOMINAL LIFTING TECHNOLOGY CAPACITY DUTY CYCLE BATTERY LIFE 9 Other important parameters: + lifting a load with a flat surface + as accessories for workshop cranes for handling material on grinding, milling, cutting, and burning...

When to choose a BMP battery-powered lifting magnet: The battery- powered BMP series magnets are easily manageable aids with a high degree of safety. They are designed to handle round and other profiles as well as flat shaped materials. The remote control will facilitate your work in locations with poor accessibility. TECHNOLOGY Electo/battery NOMINAL LIFTING CAPACITY FOR FLAT MATERIAL up to 3600 kg NOMINAL LIFTING CAPACITY FOR ROUND MATERIAL WORKING CYCLE Other important parameters: + handling loads with reduced surface quality + handling tubes, rods, I, H, T, and Z profiles and others + it...

Lockable release lever for comfortable and safe operation The large suspension lugs can be locked to prevent unwanted tipping from horizontal to vertical Easy handling and tilting of loads -from horizontal to vertical and vice Lightweight, compact design When to choose a GP 250 permanent crane magnet: The GP 250 is a permanent crane magnet for handling metal sheets and steel plates from 3 mm thick. Loads up to 250 kg can be manoeuvred horizontally with up to 80 kg vertically. Thanks to its unique pole configuration, it is possible to use this magnet to take individual metal plates from a stack,...

— Magnetic module in a monoblock design Thanks to the optional remote — control, the magnet is easy to operate. Operation is also possible from a crane cab, for example When to choose a Neo EP electropermanent lifting magnet: Neo EP electropermanent lifting magnets are suitable for frequent and repeated workpiece handling and lifting - electrical control of the magnet requires no physical exertion, which is why it saves manpower and enhances work efficiency. MAGNETIC AREA SAFETY FACTOR Other important parameters: handling smaller parts from mass production, blanks, forged pieces, or cast stock...

— Suspension lug with calliper and cotter pin When to choose a Neo HV lifting arm: The Neo HV is a lifting arm which, in combination with a lifting magnet, you can use to easily turn a workpiece from horizontal to vertical and vice versa. You will appreciate this when handling sheets, metal plates and round materials for lathes and horizontal machining centres. APPLICATION Lifting Other important parameters: Additional information: + lifting magnet is not included + the Neo 250, 500, and 1000 belt magnets are designed for Neo HV models + for manoeuvring workpieces to horizontal machining centres...

When to choose an MC hand magnet for manual load handling: Hand magnets are used solely for quick manual handling of sheets, burnt pieces, smaller steel blocks and other smooth steel items. MC hand magnets are also suitable for lifting individual sheets from a stack. The magnet is not intended for use on a crane. APPLICATION TECHNOLOGY LIFTING CAPACITY SHEAR FORCE WEIGHT Important parameters: Application: Manual handling Use: + easy manual lifting of loads which are heavy and difficult to grasp + manual handling of loads such as sheet metal, burnt pieces and other steel objects + suitable, for...
