References-Railway Engineering

References-Railway Engineering

Product catalog summary

Overview: The document provides a comprehensive reference list of railway engineering projects, categorized by locomotives, long-distance traffic, subway and urban traffic, and applications in vehicles and signaling techniques. It includes details about customers, countries, and specific pages for more information.

Locomotives: This section lists locomotive projects, specifying the customer, country, and page number. Notable companies include ABB, Siemens, and Bombardier, with projects in Germany, China, and Hungary.

Long-Distance Traffic: Details projects related to long-distance railway traffic, involving companies like ADtranz, Bombardier, and Hitachi, covering Germany, China, and Japan.

Subway and Urban Traffic: Focuses on subway and urban railway systems with key players like Bombardier, Hyundai Rotem, and Siemens, in countries such as Germany, Korea, and Japan.

Applications in Vehicles and Signaling Techniques: Highlights applications in railway vehicles and signaling technology, mentioning companies like Alcatel, Siemens, and Westinghouse, with projects in Germany, China, and the USA.

CAGE CLAMP® Connection Technique: Describes the CAGE CLAMP® connection technique used since 1978 in railway traffic for low-voltage installations, highlighting its automatic clamping force adjustment and suitability for various conductor types.

Certification: WAGO Kontakttechnik GmbH & Co. KG received a certificate from TÜV SÜD Management Service GmbH, confirming compliance with the International Railway Industry Standard (IRIS) for cabling and cabinets.

X-COM® System: Explains the X-COM® system, a modular connection system for railway applications, emphasizing its simplicity and protection against accidental contact.

Train Models and Applications:

High-Speed Trains: Includes ICE 2, ICE 3, and KTX-II, focusing on control wiring for lighting and panels.
Transrapid Shanghai: Utilizes WAGO products for door control, air conditioning, and emergency power systems.
Passenger Trains: Models like the Pendolino and BPMZ are discussed, highlighting applications in lighting, heating, and air conditioning.
Special Wagons: Includes 400 sealed special wagons for high-altitude operations, focusing on heating, lighting, and door control systems.

WAGO Products:

X-COM®-SYSTEM: Used for various conductor and terminal block configurations, essential for control wiring in trains.
Terminal Blocks: Different series like 280, 281, and 264 are used across various applications, including through terminal blocks and fuse terminal blocks.

Geographical Applications:

Australia: Victorian State Government and Bombardier utilize WAGO products in high-speed trains.
China: Products are used in Transrapid Shanghai and various passenger trains for control systems and power supply.
Denmark: Danish State Railways use WAGO products in city railways and diesel motor coach trains.
Germany: Deutsche Bahn AG employs WAGO products in passenger cars and service wagons for lighting and control systems.

Conclusion: The document highlights the critical role of WAGO products in enhancing the control and operational efficiency of high-speed and passenger trains across different regions, emphasizing their versatility and reliability in various applications.

Specifications: Lists various types of terminal blocks and connectors, specifying the number of conductors, wire size, and series numbers. For example, 4-conductor through terminal blocks (2.5 mm2/AWG 12) from series 280 are frequently mentioned.

Application Areas: Outlines application areas for components, such as control cabinets, control stations, lighting systems, air conditioning systems, door control systems, and complete electrical wiring in different types of trains.

Product Selection: Highlights the selection of WAGO products used in various railway projects, mentioning specific series and types of components like CAGE CLAMP® connectors and diode terminal blocks.

Vehicle Types: References specific train models and projects, such as the ICE 2 and ICE 3 high-speed trains, Regio-Shuttle, and InterRegio driving trailers, detailing the electrical components used in each.

Key Information:

Requirements: Specifies technical requirements for electrical components in railway vehicles, focusing on conductor size and compatibility with different systems.
Parameters: Provides detailed parameters for each component, ensuring compatibility and standardization across different railway projects.
Limitations: Implies limitations based on specified wire sizes and series numbers, critical for ensuring safety and functionality in railway applications.
Best Practices: The use of standardized components like CAGE CLAMP® connectors and specific terminal block series suggests best practices for electrical installations in railway vehicles.

Geographical Applications:

Switzerland and Austria: WAGO products are used in lighting, public address systems, control stations, and door control systems for articulated motor coaches.
United Kingdom: Virgin Rail utilizes WAGO products for complete electrical wiring in diesel-electric multiple units (DEMUs).
China: WAGO products are used in driving apparatus, control stations, and door control systems for metro lines in Guangzhou and Shanghai.
Belgium: Brussels Tram uses WAGO products in switch cabinets, door control systems, and control stations.
Hong Kong: The Airport Express system uses WAGO products for complete electrical wiring.

Key Products and Specifications:

X-COM®-SYSTEM: Widely used for its modularity and ease of use.
Terminal Blocks: Various series such as 280, 281, and 282 are mentioned, highlighting their use in different conductor configurations and sizes.
CAGE CLAMP® Technology: Featured in connectors for secure and reliable connections.

Conclusion: The document emphasizes the versatility and reliability of WAGO products in the railway sector, showcasing their integration in multiple international projects and systems.

Catalog excerpts

Bahntechnik · RBT 2.0 Railway engineering · Génie ferroviaire Referenzen · References · Références

Open the catalog to page 1

1 Lokomotiven / Locomotives / Locomotives Kunde / Customer / Client Land / Country / Pays Seite / Page / Page ABB Österreich Austria 8 Adtranz (Deutschland) GmbH, Kassel Germany, Malaysia 13, 26 CSR Sifang Locomotive & Rolling Stock Co. Ltd., Quingdao China 10 CSR Zhuzhou electric locomotive Co. Ltd. China & SIEMENS China 11 Dresdener Parkeisenbahn Werkstatt Germany 15 GE Transportation Systems Malaysia 26 Kolomensky zavod Russia 28 Krauss-Maffei AG, München Germany 14, 16 MAV Szolnoki Jarmüjavito Kft Hungary 20, 21, 22, 24 MAV Eszaki Jamujanto Kft Hungary 23 SCHÖMA LOKOMOTIVEN Ch. Schöttler...

Open the catalog to page 2

2 Qingdao Sifang Bombardier China 34 Siemens AG - Verkehrstechnik Danmark, Germany 37, 44, 48, 49, 50 Sifang Locomotive & Rolling Stock Co. Ltd, Qingdao China 34, 35 Stadler Bussnang AG Netherlands, Switzerland 58, 66 Talgo, Madrid Spain 62 Tangshan railway vehicles China 35 Transrapid Konsortium (ThyssenKrupp, Siemens), Deutschland China 33 Transtech oy Finnland 39 Metro und Nahverkehr / Subway and urban traffic / Métro et trafic en zone urbaine Kunde / Customer / Client Land / Country / Pays Seite / Page / Page ADtranz (Deutschland) GmbH China, Germany, Malaysia 72, 75, 77, 78, 82, 84, 85,...

Open the catalog to page 3

3 Anwendungen in Fahrzeugen und in der Signaltechnik / Applications in vehicles and the signalling technique / Applications dans des véhicules et la technique de signalisation Kunde / Customer / Client Land / Country / Pays Seite / Page / Page Achermann Luzern AG, Luzern Switzerland 143 ADtranz (Deutschland) GmbH, Mannheim Germany 134 Alcatel Österreich Austria 119 Bombardier Thailand 145 Bombardier Katowice Polen Polen 138 China Railway Signal and Communication Tianjin Engineering Company China 122 DB AG, Bereich Spezialwerke Forschung- und Entwicklung, Blankenburg Germany 126 Guangzhou TOSHIBA...

Open the catalog to page 4

4 WAGO CAGE CLAMP®-Anschlusstechnik Seit 1978 im weltweiten Schienenverkehr. Zum ersten Mal wurde 1978 die CAGE CLAMP®-Anschlusstechnik von der Deutschen Bundesbahn, heute Deutsche Bahn AG, für die gesamte elektrische Niederspannungsanlage, Stromversorgung und Beleuchtung des 2. Klasse-Großraumwagen (BPMZ) zugelassen und eingesetzt. WAGO-Reihenklemmen, Steckverbinder sowie elektronische Interface- Bausteine (Relaisbausteine, Übergabebausteine, usw.) werden seitdem im weltweiten Schienenverkehr in Fahrzeugen, Weichenheizungen, Signalanlagen und stationären Anlagen verwendet. Die nachfolgendend...

Open the catalog to page 5

5 C E R T I F I C A T E awarded to WAGO Kontakttechnik GmbH & Co. KG Hansastraße 27 32423 Minden Germany TÜV SÜD Management Service GmbH confirms, as an IRIS approved certification body, that the Management System of the above organization has been assessed and found to be in accordance with the International Railway Industry Standard (IRIS) Revision 00, March 2006 for the product category Cabling and cabinets Scope of supply Development, production and sales of interconnection components with spring clamp technology, automation components for field bus systems and interface modules for railway...

Open the catalog to page 6

6 Das System Das System ist einfach. Zentrale Bauelemente sind auf Tragschienen TS 35 anreihbare X-COM®-Basisklemmen mit zwei oder vier Anschlüssen. Diese gibt es in zwei Anschlussvarianten – als rein rassige X-COM®-Pin-Klemmen, ausschließlich zur steckbaren Verdrahtung mit X-COM®-Federleisten, oder – als kombinierte CAGE CLAMP®/ X-COM®-Pin-Variante für den Übergang von steckbarer Verdrahtung auf Einzelleiter. Systemergänzende Bauelemente sind X-COM®-Federleisten und Stiftleisten mit CAGE CLAMP®-Anschluss und X-COM®- Stiftleisten mit Einlötstiften (gerade und abgewinkelt) für Leiterplatten. Alle...

Open the catalog to page 7

7 Inhalt Seite Contents Page Sommaire Page Lokomotiven Brennerlok, Typ 1822 8 Lokomotive DF5, Typ SFJ71 9 Lokomotive DF7G 10 Lokomotive DJ4 11 Dieselhydraulische Lokomotive MK 601 12 Mehrzwecklokomotive V 100.4 13 Dieselhydraulische Rangierlokomotive MH 05 14 Elektroakkumulatorenlokomotive - EA 02 15 Lokomotive, Baureihe 152 16 Zweikraftlokomotive, ED 1600 17 Dieselhydraulische Lokomotive Maxima 40 CC 18 4-achige dieselhydraulische Lokomotive G 2000 BB 19 Dieselektrische Lokomotive, Typ M44 20 Dieselektrische Lokomotive, Typ M62 21 Dieselektrische Lokomotive, Typ M41 22 Lokomotive, Typ V43-2000...

Open the catalog to page 8

8 Objekt : 2-System-Lokomotive, Typ 1822 (Brennerlok), 5 Loks als Prototypen 4-Leiter-Durchgangsklemmen; 2,5 mm2; Serie 280 4-conductor through terminal blocks; 2.5 mm2/AWG 12; series 280 Bornes de passage pour 4 conducteurs; 2,5 mm2/AWG 12; série 280 2-Leiter-Durchgangsklemmen; 10 mm2; Serie 284 2-conductor through terminal blocks; 10 mm2/AWG 8; series 284 Bornes de passage pour 2 conducteurs; 10 mm2/AWG 8; série 284 2-Leiter-Durchgangsklemmen; 2,5 mm2; Serie 280 2-conductor through terminal blocks; 2.5 mm2/AWG 12; series 280 Bornes de passage pour 2 conducteurs; 2,5 mm2/AWG 12; série 280 3-Leiter-Durchgangsklemmen;...

Open the catalog to page 9

9 Objekt : Lokomotive DF5, Typ: SFJ71 (8 Zylinder) 4-Leiter-Durchgangsklemmen; 4 mm2; Serie 281 4-conductor through terminal blocks; 4 mm2/AWG 12; series 281 Bornes de passage pour 4 conducteurs; 4 mm2/AWG 12; série 281 China: Chinesische Staatsbahn Sifang Locomotive & Rolling Stock Co. Ltd, Qingdao Eingesetzte WAGO-Produkte / WAGO products used / Produits WAGO utilisés : Objet : Locomotive DF5, type : SFJ71 (8 cylindres) Object : Locomotive DF5, type SFJ71 (8 cylinders) Domaines d'utilisation : Totalité du câblage électrique Application areas : Entire electrical wiring Einsatzgebiete : Komplette...

Open the catalog to page 10

10 X-COM®-SYSTEM X-COM®-SYSTEM China: Chinesische Staatsbahn CSR Sifang Locomotive & Rolling Stock Co. Ltd., Qingdao Auswahl eingesetzter WAGO-Produkte /Selection of WAGO products used /Sélection de produits WAGO utilisés : Einsatzgebiete: Komplette elektrische Verdrahtung Objekt: Lokomotive DF7G 2-Leiter/2-Pin-Basisklemmen; 4 mm2; Serie 769 1-Leiter-Federleisten; 4 mm2; Serie 769 4-Leiter-Durchgangsklemmen; 4 mm2; Serie 281 4-conductor through terminal blocks; 4 mm2/AWG 12; series 281 Bornes de passage pour 4 conducteurs; 4 mm2/AWG 12; série 281 Application areas: Entire electrical wiring Object:...
