Product catalog summary

Connection Types
The document discusses various connection types in marine engineering, focusing on the CAGE CLAMP® system. This system is suitable for solid, stranded, and fine-stranded conductors, with universal applicability from AWG 28 to the terminal block's rated cross-section. Variants include the CAGE CLAMP® COMPACT for cross-sections up to AWG 12 and the CAGE CLAMP® S, which offers universal benefits with push-wire connection advantages, available in two versions for different cross-sections.

Testing and Standards
The CAGE CLAMP® connections have been rigorously tested, including vibration tests to IEC/EN 60068-2-6 and shock tests to IEC/EN 60068-2-27, ensuring they meet high standards for railway and marine applications. These tests confirm their vibration and shock-proof qualities, with maintenance-free connections due to long-term electrical and mechanical stability, verified through voltage drop tests under various stress conditions.

Global Acceptance
WAGO, a pioneer in spring clamp technology since 1951, has established itself as a global leader. The CAGE CLAMP® technology, introduced in 1977, has gained international recognition and approval, proving effective across sectors such as installation and machine engineering, plant automation, automotive, rail, and marine industries.

Overview of WAGO Products
The document provides a detailed overview of WAGO products used in maritime and industrial applications, including specifications and application areas for each product series, focusing on electrical systems, control units, and connection systems.

Specifications
The document lists several WAGO product series, including:

Series 750: MODBUS fieldbus couplers, analog and digital input/output modules, and incremental encoders for utility vessels, ferries, and offshore supply ships.
Series 770: WINSTA® MIDI connectors for lighting installations and on-board power supply in cruise liners and passenger ships.
Series 280-285: Various terminal blocks for electrical installations in submarines, cruise liners, and control cabinets.

Application Areas
The products are used in:

Electrical Systems: Installation and distribution in utility vessels, ferries, and offshore supply ships.
Control and Monitoring: Diesel engines and engine control automation.
Lighting and Power Supply: Cruise liners and passenger ships, ensuring efficient power distribution and lighting control.

Key Products and Their Uses

MODBUS Fieldbus Coupler (Series 750): Facilitates communication between devices in a network, crucial for automation in maritime applications.
WINSTA® MIDI Connectors (Series 770): Provide secure and efficient connections for lighting and power systems in marine environments.
Terminal Blocks (Series 280-285): Essential for safe and reliable electrical connections in various marine and industrial settings.

Conclusion
The document highlights the versatility and application of WAGO products in enhancing the efficiency and safety of electrical and control systems in maritime and industrial environments. The detailed specifications and application areas provide a comprehensive guide for selecting appropriate products for specific needs.

Additional Specifications and Applications
The document also details terminal blocks, fieldbus couplers, and other electrical components, with specifications such as wire size and series numbers. Applications include control and monitoring systems for luxury yachts, ship equipment, crane automation systems, and engine control panels.

Key Products and Series
- Series 280: Double and triple deck terminal blocks, ground terminal blocks, and disconnect terminal blocks.
- Series 750: Fieldbus couplers, analog and digital input/output modules, and filter modules.
- Series 281: Fused disconnect terminal blocks and relay modules.
- Series 285: High-capacity terminal blocks for larger wire sizes.

Critical Information
The document emphasizes the use of WAGO products in high-performance and safety-critical environments, such as marine navigation and control systems, highlighting their reliability and versatility. It also notes the use of CAGE CLAMP® technology for secure and efficient connections.

Recommendations
The document suggests using WAGO products for their reliability, ease of installation, and protection features, making them suitable for complex control and communication systems in various industrial applications.

Contact Information
The document provides extensive contact details for WAGO representatives and distributors across various countries, crucial for procurement and technical support.
