PREVENT THE PROBLEM WITH MOST COMMON TYPE OF INJURIES ERGONOMIC APPLICATIONS MOST COMMON CAUSES OF WORKER INJURIES Worker can be MORE PRODUCTIVE WITH LESS STRAIN MOST COMMON CAUSES OF INJURIES WORKER OVERWEARINESS SAFETY DISTANCES Carry the tool IN TIGHT SPACES WHILE KEEPING WORKERS SAFE

Rover Manipulator RM01 has a maximum load capacity of 100 kg and an interchangeable gripping system based on different needs or types of pieces. The head can be manually rotated or motorized on multiple axes, therefore able to automatically rotate the pieces during the lifting phase. The Rover RM01 becomes a mobile manipulator if equipped with the CSM001 and CSM002 trolley but can also be fixed to the floor or ceiling CUSTOM SYSTcH\

VERTICAL STROKE GRIPPING SYSTEMS OPERATING TEMPERATURE TECHNICAL DATA From 1 to 100 Kg (2,2 - 220 lb) Pneumatic Magnet, Vacuum or Pneumatic Gripper 75 Kg (130 lb)

BRUSHLESS Electric Rover Manipulator RM01-e has a maximum load capacity of 100 kg and an interchangeable gripping system based on different needs or types of pieces. The head can be manually rotated or motorized on multiple axes, therefore able to automatically rotate the pieces during the lifting phase. The Rover RM01-e becomes a mobile manipulator if equipped with the CSM001 and CSM002 trolley but can also be fixed to the floor or ceiling. TECHNICAL From 1 to 100 Kg (2,2 - 220 lb) 1925mm (75,8 in) + Head LIFTING WORKRAY VERTICAL STROKE GRIPPING SYSTEMS WEIGHT POWER SUPPLY SPEED Pneumatic Magnet,...

Rover Manipulator RM02, has a maximum load capacity of 50 kg and an interchangeable gripping system based on different needs or types of pieces. The double articulation represents a unique solution that allows the height of the gripping system to be adjusted before carrying out the manipulation. The Rover RM02 becomes a mobile manipulator if equipped with the CSM001 and CSM002 trolley but can also be fixed to the floor. VERTICAL STROKE GRIPPING SYSTEMS Pneumatic Magnet, Vacuum or Pneumatic Gripper SPEED REGULATION OPERATING TEMPERATURE

ACCESSORIES CSM001: BASEMENT WITH FIXED COLUMN 800X800 mm Total height H= 500 mm. Electric motorized trolley. CM600: ADJUSTABLE LIFTING COLUMN Column H=1060 mm and stroke 600 mm. Handling through brushless motor 400W - 220 V. Arranged for floor fixing Column H=1460 mm and stroke 1000 mm. Handling through brushless motor 400W - 220 V. Arranged for floor fixing

ACCESSORIESCSM002, BASEMENT FOR MANIPULATOR WITH ADJUSTABLE LIFTING COLUM Column H= 1060 mm and stroke 600mm. Handling through brushless motor 400W - 220 V. Piloting by electronic accelerator and up and down buttons. CSM002 mobile unit with electric trolley. Weight: 540 kg (1188 lb) CSM002-2WD-2 CSM002-2WD with compact 750 * 750 mm base frame, featuring 4 integrated adjustable stabilizers and auxiliary ballast.

EAM2 is an advanced mobile manipulator designed to handle loads ranging from 1 to 30 Kg. It is easily transportable thanks to its wheeled trolley and can reach a lifting height of over 2 meters, making it ideal for a variety of applications. The modular gripping system offers versatile options, including pneumatic magnets, suction cups, and hooks, allowing it to adapt to different materials and shapes.

CYLINDRICAL PARTS PLASTIC-GLASS PARTS FLAT PARTS GRIPPING SYSTEM PNEUMATIC MAGNET PNEUMATIC MAGNET + VACUUM GRIPPING CAPACITY ON STEEL FLAT PIECE GRIPPING CAPACITY ON STEEL ROUND PIECE PLASTIC/GLASS/BOX ALUMINUM/ Istainless STEEL /ETC WORKING AREA MIN-MAX LIFTING WEIGHT

CCM001-PNE: TROLLEY WITH PNEUMATIC LIFTING COLUMN Lifting column arm H=2000mm lifting coumn pneumatic piloting integrated with manipulator 4 swivel wheels, 2 with brakes push handle. Lifting column arm H=2000mm movement on linear guide and controllable trapezoidal bar with electric or pneumatic screwdriver 4 swivel wheels, 2 with brakes push handle. CCF001-PNE: PNEUMATIC LIFTING COLUMN H=1850mm Integrated pneumatic control with manipulator Weight 70 Kg (154 lb) Movement on linear guide and trapezoidal bar, can be driven with an electric or pneumatic screwdriver Weight 60 Kg (132 lb)

ACCESSORIES CCF100-EAM: TROLLEY 800X800X30 mm Column with adjustable height 650mm-1050 mm. 4 turning wheels, MANUAL BRAKE WWW.VOLUMEC.COM

mechanical innovations Via Del Mercato 5 - 31020 Sernaglia della Battaglia (TV) - ITALY Phone +39 (0)438 900299 Fax: +39 (0)438 1896510 www.volumec.com - www.easyarm.it - [email protected] JJMECITALY /votumec_itaty
