Technical Specifications and Load Capacities

The document provides detailed specifications for various types of FX components categorized by load capacity ranges and material hardness. The FX types are classified by numerical codes (e.g., FX 0-50, FX 1-60, FX 2-70) corresponding to specific load ranges measured in decanewtons (daN).

Load Categories and Material Hardness

• Normal Compound (MESCOLA NORMALE): Hardness 60° Shore (Sh)
• High Sensitivity Compound (MESCOLA ALTA SENSIBILITA'): Hardness 50° Sh
• High Resistance Compound (MESCOLA ALTA RESISTENZA): Hardness 70° Sh

Each FX type is associated with three load capacities corresponding to these three material hardness levels.

Load Ranges by FX Type

• FX 0 series: 0 - 200 daN
• FX 1 series: 200 - 500 daN
• FX 2 series: 500 - 1,000 daN
• FX 3 series: 1,000 - 4,000 daN
• FX 4 series: 4,000 - 9,000 daN

Dimensional Data

The document lists dimensional parameters for each FX type, including measurements labeled A, B, C, D, E, ØF, ØG, H, I, and L, all in millimeters (mm). These dimensions are provided as indicative and for reference only.

Dimensions vary according to the FX type and load capacity, with larger load capacities generally corresponding to larger dimensions.

Summary of Key Parameters

• Type (TIPO): FX model identifier
• Load (CARICO): Load capacity in daN
• Material Hardness: 50° Sh (High Sensitivity), 60° Sh (Normal), 70° Sh (High Resistance)
• Dimensions: Multiple parameters (A to L) in mm for design and fitting purposes

Important Notes

Dimensions are indicative and meant for reference only, suggesting that actual measurements may vary slightly depending on manufacturing tolerances or specific applications.

The classification by material hardness allows selection based on required sensitivity or resistance characteristics, enabling tailored use in different operational contexts.
