General Catalog - Vibration Products
56Pages

VIBCO • VIBCO • VIBCO • V CO* VIBCO* VIBCO • VIBC O • VIL^O • VIBCO • VIBCO ■

VIBRATION PRODUCTS Established 1962 THIS IS VIBCO Qualified engineers, with over 40 years of experience in the vibrator field, assure you of the latest developments in vibration engineering. Well trained craftsmen put these developments into the most reliable and long lasting vibration equipment available today. OUR MOTTO “ANOTHER FIRST BY VIBCO – QUALITY ENGINEERED PRODUCTS” These patents also applied for in most other countries. QUALITY ENGINEERED PRODUCTS: First in the development of new products, first in using new techniques and materials, and first in following O.S.H.A. and ecology...

VIBCOVIBCOVIBCOV IBCOVIBCOVIBCOVIB We’re C O V I B C O V I B C O V I BThe Vibrator Guys. C and your ONE supply of SILENT Air and Electric Vibrators OVIBCOVIBCOVIBCO NOISE HOW V I B C O–V I BTO O V I B C O V C CONTROL IT IBCOVIBCOVIBCOVIB COVIBCOVIBCOVIBC TABLE OF CONTENTS OVIBCOVIBCOVIBCO VIBCOVIBCOVIBCOV IBCOVIBCOVIBCOVIB COVIBCOVIBCOVIBC OVIBCOVIBCOVIBCO VIBCOVIBCOVIBCOV IBCOVIBCOVIBCOVIB COVIBCOVIBCOVIBC OVIBCOVIBCOVIBCO VIBCOVIBCOVIBCOV IBCOVIBCOVIBCOVIB COVIBCOVIBCOVIBC ® VIBCO’s SILENT TURBINE AIR VIBRATORS REPLACE NOISY BALL, ROLLER & PISTON VIBRATORS SIZE FOR SIZE As a general rule...

“SILENT” Pneumatic “SILENT” “SILENT” BEST BY TEST DBA — NOISE — LIFE CURVE Turbine vibrators maintain 70-75 db’s throughout their entire life, as compared to sharp increases in noise levels of ball roller and piston type vibrators. Turbine sound levels actually reduce after a short “break-in” period and retain a constant low sound level throughout their life. Although ball and roller vibrators start at under OSHA limits, they quickly and steadily increase noise levels to well above OSHA, to beyond bearable range. (See curve.) This is caused by ball or roller jumping and accelerating each...

SILENT TURBINE VIBRATORS USE 50% LESS AIR THAN COMPARABLE PNEUMATIC BALL VIBRATORS AIR CONSUMPTION A ball vibrator draws up to over 50% more air than a turbine vibrator. The ball in a ball vibrator takes up only 1/20 of available space in the housing and the majority of the air pushing the ball around in the ballrace is wasted and exhausted without producing any work. In a turbine vibrator, the turbine fits snugly in the housing and only a very minimal amount of air can escape without producing any work. STANDARD OPERATING RANGE 60 to 80 PSI The turbine vibrator has a high level of...

“SILENT” Pneumatic “SILENT” “SILENT” VS SERIES MODEL VS: BUILT-IN MUFFLER Model VS Turbine Vibrators offer the feature of a BUILT-IN-MUFFLER. Ideal for rough applications or where moving machinery might damage external accessories. Eight sizes with forces up to 900 lbs. Popular for air material-conveying systems, medium size batch hoppers, etc. Available in both aluminum and malleable castings. Built-In Muffler Totally Enclosed Continuous Duty Noiseless Maintenance Free Adjustable Speed Sturdy Cast Housings Heavy Duty Turbine Wheel TECHNICAL DATA Weight*** Model Data obtained on Laboratory...

MODEL BVS: THREADED EXHAUST • Quiet, Meets OSHA As Low As 68 dB at 1 Meter • No Lubrication Required • Easily Repaired - One Moving Part • Patented Design • High Force Output • Outlasts Piston Vibrators 3 to 1 • Oversized Bearings VIBCO offers 10 models in the extra heavy duty BVS series. The use of non-lubricated air supply makes the BVS turbine vibrators perfect for applications in food and pharmaceutical (etc.) industries where oil exhaust would be objectionable. Exhaust port is threaded for piping off of air exhaust in closed, sanitized systems. Extra large amplitudes and wide range of...

“SILENT” Pneumatic “SILENT” “SILENT” SANITARY MLT SERIES MODEL MLT & MHI SANITARY TURBINE MODEL MLTSS & MHISS STAINLESS STEEL • IDEAL FOR SANITARY APPLICATIONS EVEN IN HARSH CHEMICAL ENVIRONMENTS • CONSTRUCTED OF 303 STAINLESS STEEL • MANY DIFFERENT SANITARY FINISHES AVAILABLE The NEW Millennium Line of Sanitary Pneumatic Turbine (MLT/MHI) Vibrators is your solution for all sterile/clean applications. The line consists of the MLT & MHI-130, -190, -250 and 320; all are designed for the most adverse applications. Their extruded aluminum housings, stainless steel shafts, and aircraft aluminum...

Tu r b i n e V i b r a t o r s STAINLESS STEEL TECHNICAL HIGHLIGHTS AND MLT SERIES • Pressure range 30 to 80 PSI • Operating temp. max 250°F, 120°C • Decibel level as low as 68 dB on A-scale at 1 meter • Air consumption 50% less than comparable ball vibrators • Bearings are prelubricated for life TECHNICAL DATA WEIGHT * Vibrations per minute N = Centrifugal force in Newtons *** Test data are close to actual performance data of the unit on a typical application. The data obtained on a heavy laboratory test block cannot be duplicated on a typical application. We feel it is more important for...

“SILENT” Pneumatic “SILENT” “SILENT” CC SERIES MODEL CC HEAVY DUTY • QUIET • MEETS OSHA STANDARDS • EASILY REPAIRED IN THE FIELD • PATENTED DESIGN The only unit on the market to offer high force and absolutely quiet operation. Six units available. They all work on the patented turbine principle. Compressed air drives a specially designed turbine wheel, allowing the air to be channeled through the unit, then exhausting through muffler pads, making them virtually noiseless. None of these units need lubrication, all are prelubricated for life. Oversized bearings give the units years of...

Tu r b i n e V i b r a t o r s HEAVY DUTY SERIES Female Brackets Weight Model Data obtained on Laboratory test block. Frequency and force will decrease on less rigid mount. Note: Dimensions & data subject to change without notice. * Decibel from A-scale at 1 meter and 80 PSI. N = Centrifugal force in Newton. ** Rule of thumb for sizing “One lb. Vibrator Force” to each 10 lbs. of Bin Content” at 80 PSI. DIMENSIONS Model VSP-510 on burial vault forms
