VEROTEC Electronics Packaging VEROTEC Cases

Verotec Case – Value Added Services from Verotec… Custom Verotec Cases TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to Verotec Cases, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special Verotec Case requirements, please contact our sales office. Engineering Services: Complete review of commercial, electro-mechanical, environmental...

Verotec Case - Introduction INTRODUCTION The Verotec case offer an excellent combination of technical competence and aesthetic design, making it an ideal packaging solution for high-end electronic instruments. The superior design provides an upgrade path from a basic unit to a high-EMC, IP54 rated enclose that meets the demands of many environmental requirements. The main assembly screws are hidden discretely beneath clip-in mouldings, meaning there are no visible fixings and your product can be both secure and visually clean. “Cases” are available in 1U, 2U, 3U & 6U heights in both 10.5” & 19”...

VEROTEC CASES : Technical Specification MATERIAL SPECIFICATION Covers & Side Panels: 0.9mm Galvanised Steel Sheet Corner Extrusions: Aluminium Alloy M4 x 16 Csk Head; M4 x 6 Cheese Head ABS UL94-V0 Light Grey R AL 7035 or Anthracite RAL 7016 THERMAL MANAGEMENT Verotec Cases have the option to be supplied with ventilation holes in the base, allowing cool air to be drawn into the case, by natural convection. Vented rear panels may be specified promoting a “through flow” of cool air over the equipment. In both the base panel and the rear panel the matrix of holes has been design such that in minimises...

VEROTEC CASES & CASEFRAMS : Overview OVERVIEW Verotec Cases & Caseframes have been designed to offer electronics designers an attractive enclosure with the maximum amount of flexibility for an increased number of applications. As well as 3U and 6U sizes for cases and caseframes, (which tends to be the industry standard for eurocard based products), the Verotec case is also available in 1U and 2U heights, which are ideally suited to smaller bespoke instruments. Finally a key feature of the Verotec Case is its ability to be “upgraded” to give an improved EMC and IP rating. This is achieved by adding...

Verotec Case: 1U & 2U Cases Verotec Cases offer an excellent combination of technical competence and aesthetic design. Equipment can be housed in a standard full width (19inch) or half width (10.5 inch) envelope either 1U & 2U high and up to 300mm deep. The Verotec case is ideally suited to desktop or workbench mounting. With the extruded corners, cover mouldings and tilt feet it is readily stacked for multi instrument applications. The tilt feet provide an excellent facility for viewing front panel displays and can be easily raised or lowered as required. The Verotec case is available in a range...

Verotec Case: 3U & 6U Cases Verotec Cases offer an excellent combination of technical competence and aesthetic design. Equipment can be housed in a standard full width (19inch) or half width (10.5 inch) enveloped either 3U or 6U high and up to 500mm deep. The Verotec case is ideally suited to desktop or workbench mounting. With the extruded corners, cover mouldings and tilt feet it is readily stacked for multi instrument applications. The tilt feet provide an excellent facility for viewing front panel displays and can be easily raised or lowered as required. The Verotec case is available in a...

Verotec Case: 3U Caseframes 42 & 84 hp Verotec Caseframes offer an excellent combination of technical competence and aesthetic design. Eurocards can be housed in a standard 84 hp or 42 hp width either 3U or 6U high and up to 500mm deep. The Verotec caseframe is ideally suited to desktop or workbench mounting. With the extruded corners, cover mouldings and tilt feet it is readily stacked for multi instrument applications. The tilt feet provide an excellent facility for viewing front panel displays and can be easily raised or lowered as required. The Verotec caseframe range is available in two...

Verotec Case: 6U Caseframes 42 & 84 hp Verotec Caseframes offer an excellent combination of technical competence and aesthetic design. Eurocards can be housed in a standard 84 hp or 42 hp width either 3U or 6U high and up to 500mm deep. The Verotec caseframe is ideally suited to desktop or workbench mounting. With the extruded corners, cover mouldings and tilt feet it is readily stacked for multi instrument applications. The tilt feet provide an excellent facility for viewing front panel displays and can be easily raised or lowered as required. The Verotec caseframe range is available in two...

Verotec Case: Handles & Trims Verotec Cases offer 5 front trim options depending upon the application they are being used for: Option 1 – No front trims – this would be used when a Verotec plain front panel is used in Verotec case. In this application the front panel fixings are visible, but this option offers the ability to be able to quickly remove the front panel without removing the top cover of the case. Option 2 – Front Cover Trims – These can be fitted with or without a Verotec front panel and would cover the panel fixings. The covers are made up of two extrusions which slide together...

Verotec Case: Front & Rear Panels Verotec Case: has its own range of dedicated front and rear panels. Most cases will require a rear panel, which can be either ventilated or not. Aluminium front panels are available and allow the fitment of optional trims and handles to the front of the case. Front Panels for the Verotec case are supplied in anodised aluminium and are designed to provide an aesthetic front finish for the case. The front panels are manufactured from 2.5mm thick aluminium sheet which is readily modified to accept switches, displays and other front panel mounting components The...
