KM6-II Subracks – Value Added Services from Verotec… Custom KM6-II Subracks TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to KM6-II subracks, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special Subrack requirements, please contact our sales office. Engineering Services: Complete review of commercial, electro-mechanical, environmental...

KM6-II Subrack with accessories Features Strong and versatile Two screw fixing of tie bars Conforms to IEC 60297-3 Total versatility permits wide range of configurations Available in kit or piece-part form Accurate location for first time assembly Rugged construction Pre-tapped holes and machine screws throughout EMC conversion (see pages 23 – 27) No location mouldings required With or without front handles Provision for fitting 19” angles front or rear Fully compatible with DIN 41494 part 5 and IEC 60297-3, KM6-II subracks are strong, versatile and easy to assemble making them well suited to...

KM6-II Subrack, backplane mounting Ordering information Height Order code Order code with handles Rear tie bar (inc tapped strips) Notes: 1. In order to maintain the correct geometry between the front panels and backplane connectors a suitable backplane spacer is required. Either insulating or conductive types (1mm thick) may be used, and must be located between the rear tie bar and the backplane - refer to page 34. End plate 2. Backplane mounting tie bars can be converted to accept DIN 41612 connectors by fitting adaptor kits or rails - refer to page 34. KM6-II Subrack, DIN 41612 connector mounting...

KM6-II Subracks – EMC Conversion / Closing Kits 1 KM6-II subracks can be retrospectively EMC screened or closed by the addition of covers and a suitable front and rear panel. Two Basic types of screening cover are available: OVERALL, (Fig. 1) which provide a screen over both the card area and the rear connector/backplane area. In this version, the rear of the subrack is completed by the addition of conventionally fixed panels, either full width or in combinations of lesser width front panels. PCB AREA ONLY (Fig. 2) This application requires a motherboard/backplane which is specifically designed...

KM6-II Subracks – EMC Conversion / Closing Kit EMC Conversion kits – overall depth This kit contains the parts required to convert an 84HP subrack for EMC. Notes: 1. EMC front and rear panels and EMC fingers should be ordered separately to suit requirements – please refer to page 1.20-1,22. 2. 42HP and 84HP card frames can be effectively screened by ordering the individual covers and rear closing angles featured on pages 1.21, together with the EMC finger strip detailed below. Contents of kit Description Plain tie bars Tapped strips Rear closing angles Top and bottom covers (either ventilated...

KM6-II Subracks – EMC Conversion / Closing Kits 1 KM6-II EMC Conversion: Top and Base covers – overall depth The ‘Overall’ EMC conversion kits are also available in their constituent parts. In addition to the 84HP versions, a small range of ventilated overall covers is available in 42HP and 60HP widths. In order to fit these, it is necessary to order reduced width front extrusions and tapped strips, M4 fixing screws and rear closing angles. Contents of kit Description Qty. Material/Finish Covers 2 0,9mm aluminium alloy, conductive clear chromate All fixings Ordering Information Width Ventilated...

KM6-II Subracks – EMC Conversion / Closing Kits Figure 4 Board area only EMC cover kits Board area only EMC cover kits (Fig.4) For use in situations where the backplane forms the rear EMC screen, these ventilated covers fit between the front, and backplane, extrusion only. EMC Cover for board area only Backplane forms rear section Select by board depth and subrack width (84HP only); end plate depth is not a consideration. Contents of kit Description Top and Bottom Covers (ventilated) Fixings Qty. Materials/Finish 2 0,9mm Aluminium alloy conductive clear chromate Ordering information Description...

KM6-II Subrack kit - Piece parts 1 KM6-II Subrack – Piece Parts. KM6-II subrack kits as detailed on pages 1.17 / 1.18 may be ordered by their constituent parts. This allows special configurations to be achieved including 4U and 7U subracks which can only be ordered from piece parts. All subrack kits contain the following parts which are detailed in the following four pages: Page Side Plates Front Tiebars – Bottom Rear Tiebars - Top & Bottom Rear Tiebars – Centre Assembly Screws Tapped Strips Order separately Product EMC conversion, covers & closing kits Front & rear EMC closing panels Backplane...

KM6-II Subrack kit - Piece parts KM6 Subracks KM6 side plates are punched on a 12mm pitch along their length to enable tie bars to be mounted to suit customer applications. SIDE Plates On 300mm and deeper versions there is also a pattern of intermediate holes to permit the fixing of a chassis or support system. Identifications are stamped on the side plate to assist in tie bar location. Side plates are sold singly (i.e. 2 required for each subrack). Ordering information Description: Side plates Material: 2,0 or 2,5mm Aluminium BS1470 5251-H24 (NS4 H6), conductive clear chromate finish For 4U...

KM6-II Subracks kit - Piece parts 1 KM6-II front tie bars feature a screw fixing system using a unique dowelscrew arrangement which ensures accurate location and subrack rigidity. An additional slot is provided which, when fitted with a tapped strip, enables pcb and module guides to be secured using M2,5 x 5mm screws, thereby offering greater security and strength (see figure 8). Provision is also made for the fitting of dust/EMC covers, without the need for additional seals, whilst still maintaining a high level of EMC screening. Normal front extrusions have slot identification printed along...
