Integrated Systems – Value Added Services from Verotec… CUSTOM INTEGRATED SYSTEMS TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to integrated systems, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special integrated system requirements, please contact our sales office ENGINEERING SERVICES: Complete review of commercial, electro-mechanical,...

Integrated Systems - Introduction INTRODUCTION Verotec offer a number of standard COTS (Commercial off-the-shelf) integrated systems to address the needs of today’s varied industrial computing demands. For VME64/VPX and CompactPCI platforms, we offer our Type H, Type D, Type V chassis’, each with its own unique form-factor and configuration options. For desktop VPX software & hardware development we offer our TecSYS chassis and for next-generation carrier grade telecoms applications we offer the A6R ATCA system. Designed for the horizontal mounting of 6U cPCI or VME64x boards, the range consists...

H12 - 1U Compact PCI / VME64x Chassis INTRODUCTION Designed for use in either 19” rackmount or desktop applications, the H12 chassis is Verotec’s slimmest horizontal chassis. Fully compliant to IEEE 1101.10/11, the chassis is ideal for housing either VME64x or CompactPCI cards in low board count applications while still maintaining a full width rear transition capability. It is ideal for development or target/deployable systems requiring minimum space with its robust yet cost-effective design. System cooling is optimised for efficiency with a push-pull configuration, providing sufficient cooling...

482.6mm /19" with rackmount ears ORDERING INFORMATION Material & Finish Outer - Steel (Powder coated in black-textured finish) EMC Gasket- Beryllium / Copper Subrack - Aluminium alloy (Iridite NCP) CUSTOMIZING OPTIONS Please Note-With a wide range of options available, it would be impossible to list every combination. Should your application require a different specification such as backplane, cooling or power supply variants, please contact us to discuss. Operating Temperature Storage Temperature Power Supply * Total combined power 110W Electronics Packaging

H24 - 2U Compact PCI / VME64x Chassis INTRODUCTION The H24 chassis is designed as a 2U x 19” x 300mm deep rackmount or desktop enclosure offering 4 x 6U horizontal 4HP slots along with provision for a full width rear transition area making it ideal for either CPCI or VME64x applications. Fully compliant with the IEEE 1101.10/11 specification, the flexibility of this design means it can be configured with a wide range of power supply options. These range from a single 250W embedded power supply or up to two pluggable PICMG 2.11 compliant 300W AC/DC or DC/DC power supplies with hot-swap capability,...

SPECIFICATION Dimensions Width Depth Height Weight 6 Kg / 13.3 lbs (Typical, chassis + backplane + single PSU) Material & Finish Outer - Steel (Powder coated in black – textured finish) EMC Gasket – Beryllium / Copper Subrack - Aluminium alloy (Iridite NCP) Environmental (Pluggable PSU) Operating Temperature -50C to +550C (PSU de-rating above) Storage Temperature -10 0C to +70 0C Pluggable 200W (each) Pluggable 300W (each) 90 – 264 V @ 50-60 Hz POWER - INPUT AC Operation DC Operation (48V) POWER - OUTPUT Single 250W embedded 1 Single 200W pluggable 2 Double 200W pluggable 3 Single pluggable 4...

H36 - 3U Compact PCI / VME64x Chassis INTRODUCTION The H36 chassis is designed as a 3U x 19” x 300mm deep rackmount or desktop enclosure offering 6 x horizontal 4HP slots along with provision for a full width rear transition area making it ideal for either CPCI or VME64x applications. Fully compliant with the IEEE 1101.10/11 specification, the flexibility of this design means it can be configured with a wide range of power supply options. These range from a single 250W embedded power supply or up to 3 x pluggable PICMG 2.11 compliant 300W AC/DC or DC/DC power supplies with hot-swap capability,...

SPECIFICATION Dimensions Width or Depth Height Weight 7.0 Kg / 15.4 lbs (Typical, chassis + backplane + single PSU) Material & Finish Outer - Steel (Powder coated in black – textured finish) EMC Gasket – Beryllium / Copper Subrack - Aluminium alloy (Iridite NCP) Environmental Operating Temperature Storage Temperature FANS Fixed 2 Removable (Hot swap) 3 Removable (Hot swap) + filtered 4 POWER - INPUT AC Operation 1 DC Operation (48V) 2 POWER - OUTPUT Single embedded 1 250W Single pluggable 2 200W Double 200W pluggable 3 Single pluggable 4 300W Double pluggable 5 300W BACKPLANE VME64x Extensions...

D10 – Desktop 10 slot (Half-width) System INTRODUCTION Designed as a 9U, half width x 422mm deep desktop enclosure, the D10 chassis offers up to 10 vertically mounted 6U x 160mm CPCI or VME64x slots with space to the rear of the backplane for I/O connection. The chassis is not only ideal for use in the development environment, but also for demonstration or target systems. The core of the system is based on the IEEE1101.10/11compliant KM6-RF subrack, housed in the versatile and stylish DIPLOMAT caseframe, resulting in a system that is compact but still provides easy access. Based around Verotec...

D10 – Desktop 10 slot (Half-width) System 445.76 428.52 Front View Side View Rear View ORDERING INFORMATION Width Depth Height Material & Finish Diplomat chassis - Top, bottom, rear & side infill covers – All other parts – KM6-RF Subrack - Front infill – Steel (Textured electrostatic epoxy finish) Light Grey BS 4800 00A01 Mid Grey BS4800 00A05 Aluminium alloy (Iridite NCP) Aluminium alloy (Anodised) POWER – OUTPUT 500W Pluggable 700W Embedded BACKPLANE VME64x Extensions (With P0) Standard CompactPCI (PICMG 2.0 R.3) CPCI + Computer Telephony H110 (PICMG 2.5) CPCI + Packet Switching (PICMG 2.16)...
