VEROTEC Electronics Packaging 4 Diplomat Cases Diplomat Cases & Caseframes UK +44 (0)2380-246900 US+1-603-821-9921 [email protected] [email protected]

Diplomat – Value Added Services from Verotec… CUSTOM DIPLOMAT CASES AND CASEFRAMES TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to Diplomat cases and caseframes, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special Diplomat requirements, please contact our sales office. ENGINEERING SERVICES: Complete review of commercial, electro-mechanical,...

Diplomat Cases and Caseframes INTRODUCTION Verotec’s DIPLOMAT metal enclosure range is recognised worldwide as one of the leading products in its field having evolved around a number of international standards and in response to a number of trends. These cases are strong, yet lightweight and provide an inherent level of EMC protection due to their overall metal construction. Available as cases, and caseframes, DIPLOMAT provides a tough, yet aesthetically pleasing packaging solution which is equally effective in workshop, laboratory or office environments. Why would you choose to use a DIPLOMAT...

DIPLOMAT Case Cooling NEW AND IMPROVED COOLING PERFORMANCE The DIPLOMAT range of enclosures has improved cooling performance in both the standard and fan plinth versions. The fan plinth version has a wider plinth with an increased ventilation surface area to increase the volume of air flow. The plinth can either act as a chamber for air collection when fans are mounted on the rear panel of the unit (pull through air flow) or can be used to mount fans directly hence employing a push method of cooling. Fans can be mounted in the plinth and on the rear panel employing a push-pull method of cooling....

DIPLOMAT Case EMC and IP Sealing DIPLOMAT SHIELDING EFFECTIVENESS RESULTS The shielding effectiveness results shown have been measured in Verotec’s EMC test facility using a generic test procedure adapted for smaller enclosures. SHIELDING EFFECTIVENESS FOR 3U x 422 DIPLOMAT 19" CASE 130 The graph shows typical attenuation figures achieved for a 3U 19" DIPLOMAT case, which has been fitted with standard front and rear panels. The performance achieved shows that in both the E and the H field the unit will provide fairly high levels of attenuation across a broad frequency band. The DIPLOMAT range...

DIPLOMAT Cases: Overview and accessories index DIPLOMAT 19” AND 10½” CASES DIPLOMAT 19” and 10½” cases are designed to provide stylish, robust, yet economical solutions for housing electronic systems in either a desktop or floor standing environment. Built-in (die cast) panel mounts front and rear house standard caged nuts that allow industry standard 19” equipment, panels or subracks (to IEC 297-1 and DIN 41494) to be securely mounted. The die-cast & extruded aluminium frame together with steel covers mean they are strong and lightweight, with inherent EMC and an IP rating of 30. A fan plinth...

DIPLOMAT Cases 3U and 4U horizontal versions HORIZONTAL CASES WITH OR WITHOUT PLINTH The standard horizontal DIPLOMAT cases are available in four heights, two widths and four depths, and are supplied ready assembled. Material/Finish 0.9mm Zintec coated steel 0.9mm Zintec coated steel Aluminium alloy extrusion Aluminium alloy extrusion Aluminium alloy castings ABS plastic Textured electrostatic epoxy paint Light grey BS4800-00A01 Mid grey BS4800-00A05 Contents of kit Description Qty Top cover 1 Bottom cover (or plinth) 1 Handle extrusion 2 Side extrusions (4U only) 4 Bezels 2 Feet (2 tilting)...

DIPLOMAT Cases 3U and 4U vertical versions Contents of kit Description Qty Material/Finish Handle 1 Aluminium alloy extrusion Vertical feet assemblies 2 ABS plastic/aluminium extrusion Ventilated side covers 2 9mm Zintec coated steel Handle extrusions 2 Aluminium alloy extrusion Side extrusions (4U) 4 Aluminium alloy extrusion Handle infill 1 0 9mm Zintec coated steel Bezels 2 Aluminium alloy castings Finish Textured electrostatic epoxy paint Colour: Side covers Light grey BS4800-00A01 Front and rear bezels, Mid grey BS4800-00A05 side handles and extrusions, infills and feet DIPLOMAT 19” Cases...

DIPLOMAT Cases 6U and 9U horizontal versions 6U and 9U horizontal cases are available in either standard or plinth versions. Typical cooling performance characteristics for a loaded case can be found on page 4, which also demonstrates the likely air flow path in this scenario. Contents of kit Description Qty Material/Finish Top cover 1 0.9mm Zintec coated steel Bottom cover (or plinth) 1 0.9mm Zintec coated steel Handle extrusions 2 Aluminium alloy extrusion Side extrusions 2 Aluminium alloy extrusion Bezels 2 Aluminium alloy casting Side infills 2 0.9mm Zintec covers,coated steel Feet (2 tilting)...

DIPLOMAT Cases accessories TRANSPARENT DOORS Manufactured from strong yet lightweight materials this new transparent door design offers not only security but styling to the DIPLOMAT 19" enclosure. All doors are lockable and allow sufficient space inside to mount components on front panels without causing interference. All doors are supplied with an integral colour highlight strip. Flammability rating - BS476 class 3/UL94-HB Contents of kit Description Door assembly Highlight trim Lock trim Plain trim Set of keys Set of fixings Qty. Material/Finish 1 3mm Acrylic panel (tint 901) with mid grey...

DIPLOMAT Cases accessories FEATURE FRONT PANELS Available in addition to the range of standard 19" front panels, these are unique to the DIPLOMAT case. Manufactured in 3mm etched and anodised aluminium with a high quality surface finish they provide a clean and very attractive frontal appearance. They may be used both on the front and rear of the case and are fitted into the bezel in place of the trims, and in front of the 19" fixing facilities. Ordering information Case Size Panel dimensions Width Feature front panels 10½” AND 19” FRONT PANELS Standard 19" (IEC 297-1, DIN 41494 pt1) front panels...
