19” Rack Cases – Value Added Services from Verotec… CUSTOM 19” RACK CASES TecServ+ is the vehicle by which Verotec delivers its value added services. These fall within 5 main categories and are described below. When it comes to 19” rack cases, we’ve worked with many customers in the past to design, manufacture and help bring to market modified and custom versions of our standard products – a small selection of these are pictured below. If you have any special 19” rack case requirements, please contact our sales office. ENGINEERING SERVICES: Complete review of commercial, electro-mechanical, environmental...

19” Rack Cases – Standard STANDARD RACKCASES 19” rack cases are designed to offer a simple solution to many 19” mounting applications. The design allows numerous combinations to be assembled according to the application and hence offers total flexibility for the design engineer, using common piece parts. It also allows the case to be presented in a number of attractive finishes for individual product tailoring of 19” mounting applications. Standard 1U-4U Rackcase components may be ordered separately; alternatively 1U-6U Rackcases can be configured in which case they are supplied fully assembled....

19” Rack Cases – Standard HOW TO CONFIGURE THE RACK CASE Since it is generally accepted that the case will consist of a top, base, front and rear, the following example illustrates how to select the configuration which best suits you. This is available in 3 depths of 250mm, 350mm and 450mm in a ventilated and unventilated version and is simply attached to the case by means of two fasteners at the front. For 1U, 2U, 3U and 4U versions, either black or grey plastic / extruded aluminium handles may be selected. They are supplied with grey highlight strips and are secured to the case using four fixing...

19” Rack Cases – Standard CONFIGURED RACKCASES So that specific permutations can be provided, the below charts should be used to configure exact requirements. Each digit of the ordercode represents an available option for example, part number 519-110113 represents a 1U rack case, 250mm deep with a plain top cover and base, clear anodised front panel and grey handles. Configured units are shipped assembled. 5U & 6U versions are subject to a 5 piece MOQ. * Note: Grey and Black handles only available on 1U-4U Rackcase. 5U&6U versions fitted with chrome bar handles. ORDERING INFORMATION – 1U, 2U...

19” Rack Cases – Veroshield VEROSHIELD RACK CASE The Veroshield case is designed for applications that demand a high level of EMC screening, protection against ingress of dust / water and a cosmetic appeal without compromising on strength and usability. The enclosure is constructed from 0.9 mm galvanised steel to maintain electrical conductivity throughout the unit; an additional 19” aluminium front panel, external to the screened enclosure, is provided to improve the appearance when the unit is mounted in a rack or desktop case. The Veroshield case has been designed to meet the requirements...

19” Rack Cases – Veroshield EXPLODED VIEW TOP COVER REAR PANEL INNER FRONT PANEL BASE HANDLE ASSEMBLY ALUMINIUM FRONT PANEL DIMENSIONAL DETAIL 406.00 INSIDE FLANGES REAR VIEW PANEL SPACE PLAN VIEW 'D' OUTSIDE REAR PANEL TO INNER FRONT 'B' INSIDE REAR PANEL TO INSIDE INNER FRONT SIDE VIEW Combined front panel thickness FRONT VIEW Order Code

9" Rack Cases - Eurocaru EUROCARD RACK CASE The Eurocard rack case allows any size of standard Eurocard PCB to be mounted horizontally in 1U or 2U of 19" rack-space. Ideal for applications where only a small number of PCBs are required (perhaps only 1), and where 19" rack-space is at a premium, this enclosure provides a cost effective packaging solution to the alternative option of vertically mounting cards in a subrack, where up to 9U could be required. The base and cover are punched with a universal hole pattern that allows tiebars to be positioned in various places, allowing numerous configurations...

19” Rack Cases - Eurocard ISOMETRIC VIEW SHOWING CONFIGURATION OPTIONS Tapped strip Rear Tiebar Card Guide Centre Rear Support Bar Handle Rear Gland Plate Blanking Panel IEEE Front Tiebar IEC Front Tiebar Front Panel ORDERING INFORMATION Due to the numerous possible configurations, Eurocard rackcases are sold in their constituent parts as detailed below. Should you require them assembled, please contact our sales office. EUROCARD RACKCASE BASES & GLAND PLATES The base encompasses the vented sides and rear panel but does not include the rear gland plate which must be ordered separately. The rear...

19” Rack Cases - Eurocard ORDERING INFORMATION Due to the numerous possible configurations, Eurocard rackcases are sold in their constituent parts as detailed below. Should you require them assembled, please contact our sales office. EUROCARD RACKCASE TIEBARS, TAPPED STRIPS, SPACERS & DIN ADAPTORS Tiebars are ordered singly as required. IEEE types include the punched lip for use with injector / extractor handles found with VME64x, CPCI etc. A tapped strip is required in each tiebar and optional DIN connector mounting adaptors should be used for securing DIN 41612 connectors directly to rear tiebars....
